Models:
HO-4-6S-CER-T
HO-4-6NF-CER-T
For your convenience, we recommend to attach
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE
Installation
and Operating
Instructions
the serial number label HERE.
727626042013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HO-4-6S-CER-T and is the answer not in the manual?

Questions and answers

Related Manuals for Parmco HO-4-6S-CER-T

Summary of Contents for Parmco HO-4-6S-CER-T

  • Page 1 For your convenience, we recommend to attach the serial number label HERE. As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE...
  • Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to nd out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...

  • Page 3: Safety Warnings

    Safety Warnings 1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons. 2. This product is intended for indoor use only. 3. Power line connection:The power cord should be connected in compliance with the relevant New Zealand standard, to an 3×20A omni-polar circuit breaker.
  • Page 4 12. If the surface is cracked, switch off the appliance and contact Parmco Appliances. To avoid the possibility of electric shock do not continue to use a damaged hob.
  • Page 5 Safety This hob was specially designed for domestic use. In our constant search to improve our products, we reserve the right to modify any technical, program, or aesthetic aspects of the appliance at any time. Excessive Heat Protection Sensors mounted in the hob itself monitor the temperature on each hotplate. Should excessive heat occur under any circumstances, your ceramic hob will automatically disconnect the elements and cease the power supply.

  • Page 6: Installation

    Installation Selection of Installation Equipment Cut out a hole in the table surface according to the sizes shown in the diagram. For the purpose of installation and use, a minimum of 50mm space must be preserved around the hole. Be sure the thickness of the table surface is at least 30mm. Please select heat-resistant table material to avoid larger deformation caused by the heat radiation from the hotplate.

  • Page 7: Power Line Connection

    Note: The safety distance between the ceramic hob and the ventilation system should be at least 650mm. When installing the hob over drawers, a board must be installed 10mm underneath the hob. The board must be made of suitable heat resistant properties.

  • Page 8: Glass Plate

    220-240V 220-240V 220-240V connect to the main power supply connect to the main power supply 220-240V~ 220-240V 2+2N~ Figure (3) · If the power cable is damaged, cease using the appliance immediately. · If the hob is connected directly to the mains, an omnipolar circuit breaker must be installed with a minimum opening of 3mm between contacts.

  • Page 9: Instructions For Use

    Schematic Diagram of the Control Panel Child Lock Timer On/Off Double zone Power Instructions for Use Preparation before using When the power is switched on, the alarm will sound once, all the indicator lights will turn on for one second. Once the lights have gone out, the hob is active and in standby mode.

  • Page 10: Timer Function

    When the cooking zone is in double zone working mode, the double zone indicator will show P . You can select the size of the cooking zone according to the size of the pot. Timer function Cooking timer First select the cooking zone by pressing the - or + of the relevant cooking zone.

  • Page 11: Safety And Maintenance

    Safety and Maintenance Do not put any detergents or Never use the ceramic hob A dedicated power flammable materials in the in high temperature protection airswitch must be equipment installed under environments such as near used. the ceramic hob. a gas or kerosene stove. Metallic objects such as For sealed foods such as If the supply cord is damaged,...

  • Page 12: Cleaning And Maintenance

    Maintain a regular cleaning DISPOSAL: Do not dispose Indoor use only. routine to ensure best this product as unsorted performance. Failure to do municipal waste. Collection so will result in reduced of such waste separately for performance and possible special treatment is damage.

  • Page 13: Warranty

    • If proof of date of purchase is not supplied, except at the sole discretion of Parmco Sales. Proof of purchase can be for the product itself, or if installed • This warranty is offered as an extra benefi t, and does with a kitchen or house then proof of purchase can be from a Parmco not affect other legal rights, which can not be modifi...
