VLT ® HVAC DRIVE High Power
Instruction Manual
Frame size
IP
NEMA
Cardboard
box size
Shipping
dimensions
Drive
dimensions

3.4. Mechanical Installation

Preparation of the mechanical installation of the adjustable frequency drive must be done carefully
to ensure proper results and to avoid additional work during installation. Start by taking a close
look at the mechanical drawings at the end of this instruction manual to become familiar with the
space demands.

3.4.1. Tools Needed

To perform the mechanical installation, the following tools are needed:
•
•
•
•
•
•
•
•
Mechanical dimensions, E Enclosures
Height
Width
Depth
Height
Width
Depth
Max weight
Drill with 0.39 or 0.47 in [10 or 12 mm] drill.
Tape measure
Wrench with relevant metric sockets (7-17 mm)
Extensions to wrench
Sheet metal punch for conduits or cable glands in IP 21 and IP 54 units
Lifting bar to lift the unit (rod or tube Ø 0.75 in [20 mm]) able to lift minimum 880 lbs
[400 kg].
Crane or other lifting aid to place the adjustable frequency drive in position
A Torx T50 tool is needed to install the E1 enclosure in IP 21 and IP 54 enclosure types.
MG.11.F1.22 - VLT ® is a registered Danfoss trademark.
E1
450-600 hp [315-450 kW]
(380-480 V)
500-750 hp [355-560 kW]
(525-600 V)
21 54
Type 12 Type 12
33.1 in [840 mm] 33.1 in [840 mm] 32.7 in [831 mm]
86.5 in [2197 mm] 86.5 in [2197 mm]
29 in [736 mm] 29 in [736 mm]
78.7 in [2000 mm] 78.7 in [2000 mm] 59 in [1499 mm]
23.6 in [600 mm] 23.6 in [600 mm]
19.5 in [494 mm] 19.5 in [494 mm] 19.5 in [494 mm]
690 lbs [313 kg] 690 lbs [313 kg]
3. How to Install
E2
450-600 hp
[315-450 kW]
(380-480 V)
500-750 hp
[355-560 kW]
(525-600 V)
00
Chassis
67.1 in [1705
mm]
29 in [736 mm]
23 in [585 mm]
611 lbs [277 kg]
21
3
