Before you start

page page
Read the safety rules on page page page 4 before you start.

Mechanical installation

Item 1 Drilling template (enclosed in box)
For sizing and drilling of holes you can use the
enclosed Drilling Template.
Ensure min. 100 mm (10 cm) free air space
above and below the VLT frequency converter. This
also applies when a module has been mounted.
Make sure that the ambient temperature does not
exceed 40°C.
Item 2 Side by side mounting
VLT frequency converters can be mounted side by
side, without any space between them.
Item 3 Module
If you want to use a module (to be placed underneath)
you must take the physical dimensions into account.

Electrical installation

Item 1 Prefuses
Choose the right prefuses:
Mains supply 1 x 220/230/240 V
3 x 208/220/230/240 V
VLT 2010 Max. 10A
VLT 2015 Max. 16 A
VLT 2020 Max. 20 A
VLT 2030 Max. 20 A
VLT 2040 Max. 20 A
VLT 2050 Max. 25 A
See Special conditions: Cut-in current
6
VLT ® 2000 Series
That I have done
That I have done
Mains supply 3 x 380-460 V
VLT 2020 Max. 16 A
VLT 2025 Max. 16 A
VLT 2030 Max. 16 A
VLT 2040 Max. 16 A
VLT 2050 Max. 16 A
VLT 2060 Max. 20 A
MG.20.B6.02 – VLT is a registered Danfoss trademark
