Issue 9
[10] OPTIONAL EXTRAS
ROTABROACH CUTTING FLUID
Specially formulated for maximum cutter life.
Available in three sizes:
1 litre RD208
5 litre RD229
Chuck adaptor.
RD33025
Enables the existing arbor to be replaced to utilize twist drill chucks.
To fit adaptor, remove socket set screws RD4368 (item No 78) and arbour RD3384 (item No 73).
Insert adaptor RD33025 onto end of motor spindle and lock into position.
Chuck Kit.
RD4189
1/2" capacity chuck + key
RD4190
Chuck key
RD324
Chuck spacer
To fit chuck, replace existing chuck adaptor (as described above) and screw chuck onto adaptor.
Original Version
13
December 2011
