Rotabroach CM/330C Operating Instructions Manual page 10

Issue 9
[8] PARTS LIST – CM/330/C
Item Component
1 Motor packing
2 Magnet
4 Motor
6 Housing
8 Slide
9 Motor Bracket
10 Rack
11 Fixed gib strip
12 Adjustable gib strip
13 Gib support strip
14 Spirol pin
15 Bearing bracket spacer.
16 Thrust washer
17 Bearing
18 Arbor sleeve
19 Bearing bracket
20 External circlip
21 Key
22 M5 shakeproof washer
23 M6 shakeproof washer
24 M6 socket head cap screw
25 M5 socket head cap screw
26 M6 stud
27 M4 shakeproof washer
28 M4 pan head screw
29 M8 washer
30 M8 shakeproof washer
31 M6 nut
32 M6 washer
35 M8 bolt
39 Capstan pinion shaft
40 Pinion shaft sleeve
41 Bearing
Original Version
Part No. Item
RD33117 42 M6 spring washer
RD43100 43 M6 socket head cap screw
RD43105 44 Capstan arm
RD33124 45 Plastic knob
RD33125 46 M6 socket screw
RD3357 47 Tension pin
RD33097 48 Name plate
RD33103 49 Information plate
RD33104 54 Screw
RD33105 53 Face plate
RA353 55 Guard
RD3324 56 Guard bracket
RD4519 60 Spring plunger
RD4518 62 3/8" BSP elbow
RD33100 63 3/8" BSP ball valve
RD33122 64 Silencer
RD43095 65 Hex adaptor
RD3355 66 Ratchet handle *
RD4092 67 M6 socket head cap screw
RD4096 68 M6 washer
RD4394 71 Button
RD4325 72 Spring
RD4340 73 Arbor
RD4069 74 Circlip
RD4077 75 M8 socket screws
RD4078 77 M5 countersunk screw
RD4079 78 M8 socket screws dog point
RD4087 79 M12 grub screw
RD4095 80 PG16 plastic insert
RD4319 81 Washer
RD33088 82 Pole piece set
RD33090 83 Magnet Washer
RD33092
10
December 2011
Component Part No.
RD4207
RD4098
RD33089
RD43091
RD4312
RD4102
RD4301
RD4362
RD43092
RD33116
RD33120
RD33118
RD43097
RD43020
RD43021
RD4355
RD4389
RD43104
RD4156
RD33030
RA354
RA355
RD3384
RD4056
RD4066
RD4347
RD43135
RD4081
RD43138
RD43136
RD43047
RD33030
