Rotabroach CM/330C Operating Instructions Manual page 12

Issue 9
[9] ATLAS-COPCO MOTOR
Three-stage gear unit - for A0030
-
Ref No.
39 (40-42)
40
41
42
43
44
45
46
47
48 (49-50)
49
50
67
68
69
113(114-120)
114
117
118
119
120
121
122
123 (124-127)
124
125
126
127
128
129
96 (97-98)
97
98
106
107
111
112
Part No Qty
4430 0563 80 1
- 1
4090 0704 00 1
0335 3508 01 1
4430 0559 00 1
0666 8003 05 1
0337 2622 00 1
0502 3304 00 1
4430 0562 00 1
4430 0492 80 1
- 1
4090 0588 00 1
4430 0554 00 1
4170 0505 00 1
0663 9026 00 1
4430 0547 80 1
- 1
4210 2214 00 1
0517 0100 05 48
4210 2213 00 6
4210 2215 00 3
0502 1504 00 1
4210 2220 00 1
4430 0549 80 1
- 1
4430 0467 00 3
0515 1103 01 3
0517 0100 11 3
0502 1103 00 1
4430 0557 00 1
4430 0484 80 1
- 1
0517 0100 13 3
0515 0100 13 3
4430 0475 00 3
4430 0556 00 1
4430 0474 00 1
Original Version
Description
Gear rim complete
Gear rim (z = 47)
Lubricating nipple
Circlip (SB45)
Front part
Seal ring (G30 x 37 x 4)
Key (R6 x 6 x 30)
Ball bearing (6304-Z)
Nut
Gear rim complete
Gear rim (z = 45)
Circlip (BR35)
Washer
Cup spring
O Ring (40 x 1.78)
Planetary gear complete (i = 4.62)
Planet shaft (Ø19mm)
Gear wheel (z = 15)
Bearing needle (1.5 x 13.8)
Washer (6.3/9.1 x 0.5)
Axle pin (6.22h6 x 23.5)
Ball bearing (16004)
Bushing
Planetary gear complete (i = 4.46)
Planet shaft (z = 13)
Gear wheel (z = 15)
Needle bearing (K5 x 8 x 10 TN)
Bearing roller (NRB 5.0 x 19.8)
Ball bearing (6003)
Washer
Planet shaft complete (i = 3.25)
Planet shaft (z = 13)
Bearing roller (NRB 3.0 x 17.8)
Needle bearing (K3 x 5 x 9 TN)
Gear wheel (z = 12)
Washer
Gear wheel (z = 11/20)
12
December 2011
