5.3.1Menu Bar

Menu Bar: Live, Replay, Configuration, Local Setting and Logout
5.3.1.1Live Display
Log in the Web Application Manager, system will be defaulted to enter into <Live>
interface shown as Picture 5-3. You can click [Play] button to Open/close live images,
on-spot record, capture, and many live display modes.
Buttons on a single live interface：
：Volume switch
：Record switch: the remote record switch of client. Record will be automatically
saved to a specified position on PC after the function is enabled.
： Snapshot: Capture the selected live image and save it to a specified position on
PC. The image is saved as *.bmp format.
: Open or close the images on Live window.
Or click the right key of mouse on each <Live> window to pop up channel
operation menu as shown in Picture 5-4
Picture 5-4
Show bit rate: Tick Show Bit rate to show IPC bit rate in current window.
：Switch display mode in channel window
：Open all the Live channels.
：Close all the Live channels
：Display previous group of channels
：Display next group of channels
： Click to maximize the current window to full screen. Right click to pop up menu
option and select Exit Full Screen.
5.3.1.2 Video Control
Picture 5-5
