FX Configurator-FP
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi FX3UC Series

Summary of Contents for Mitsubishi FX3UC Series

  • Page 1 FX Configurator-FP OPERATION MANUAL...

  • Page 3: Safety Precautions

    Safety Precautions (Read these precautions before using.) Before installing, operating, maintenance or inspecting this product, thoroughly read and understand this manual and the associated manuals. Also pay careful attention to handle the module properly and safety. This manual classifies the safety precautions into two categories: Indicates that incorrect handling may cause hazardous conditions, resulting in death or severe injury.
  • Page 4 • Do not disassemble or modify the PLC. Doing so may cause failures, malfunctions or fire. For repair, contact your local Mitsubishi Electric distributor. • Before connecting or disconnecting any extension cable, turn off power. Failure to do so may cause unit failure or malfunctions.
  • Page 5 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
  • Page 6 • Since the examples indicated by this manual, technical bulletin, catalog, etc. are used as a reference, please use it after confirming the function and safety of the equipment and system. Mitsubishi Electric will accept no responsibility for actual use of the product based on these illustrative examples.

  • Page 7: Table Of Contents

    FX Configurator-FP Operation Manual Table of Contents Table of Contents SAFETY PRECAUTIONS ....................(i) Functions and Use of This Manual ..................6 Associated Manuals........................7 Generic Names and Abbreviations Used in Manuals ............8 Reading of the Manual ......................10 Included items .........................
  • Page 8 FX Configurator-FP Operation Manual Table of Contents 5. Data set 5.1 User unit and Converted pulse data....................38 5.1.1 User unit ............................38 5.1.2 Converted pulse data ........................38 5.1.3 Rotation and operation speed of servo motor (Converted pulse data).......... 38 5.2 Setting positioning parameters......................
  • Page 9 FX Configurator-FP Operation Manual Table of Contents 10. Edit function in data setting 10.1 Cut / Copy / Paste / Select all ..................... 92 10.1.1 Cut/Copy............................92 10.1.2 Paste ............................93 10.1.3 Select all ............................94 10.2 Cursor jump..........................94 10.3 Initializing rows/columns ......................

  • Page 10: Functions And Use Of This Manual

    FX Configurator-FP Operation Manual Functions and Use of This Manual Functions and Use of This Manual FX Configurator-FP is the setting/monitor tool for use with a personal computer. FX Configurator-FP is a setting/monitor tool for the FX -20SSC-H positioning block and the servo amplifier applicable to SSCNETIII can perform the parameter setup, the table information setting, the monitor, and the test.

  • Page 11: Associated Manuals

    FX Configurator-FP Operation Manual Associated Manuals Associated Manuals For detailed explanation of FX Configurator-FP Configuration Software, refer to this manual. For the hardware information and instruction on the PLC main unit, other special function unit/block, etc., refer to it's respective manual. For acquiring required manuals, contact the distributor from who you have purchased the product.

  • Page 12: Generic Names And Abbreviations Used In Manuals

    FX Configurator-FP Operation Manual Generic Names and Abbreviations Used in Manuals Generic Names and Abbreviations Used in Manuals Generic name or Description abbreviation series Generic name for FX Series PLC PLC or main unit Generic name for FX Series PLC main unit series Generic name for FX Series PLC...
  • Page 13 FX Configurator-FP Operation Manual Generic Names and Abbreviations Used in Manuals Generic name or Description abbreviation Setting/Monitoring Tool Setting/monitoring tool or Abbreviated name of FX Configurator-FP Setting/Monitoring Tool FX Configurator-FP Indicator GOT1000 series Generic name for GT16, GT15, GT14, GT11 and GT10 GOT-900 series Generic name for GOT-A900 series and GOT-F900 series GOT-A900 series...

  • Page 14: Reading Of The Manual

    FX Configurator-FP Operation Manual Reading of the Manual Reading of the Manual Indexes the chapter number. Shows the manual title. Shows the title of the chapter and the title of the section. This area shows the The right side of each page This area shows the title of the chapter and the manual title for the page indexes the chapter number...

  • Page 15: Included Items

    FX Configurator-FP Operation Manual Included items Included items Type Product Name Quantity (model name) FX Configurator-FP Version 1(1-license product) (CD-ROM) END-USER SOFTWARE LICENSE AGREEMENT FX Configurator-FP (SW1D5C-FXSSC-E) License Certificate FX Configurator- FP Operation Manual (this manual)

  • Page 16: Introduction

    FX Configurator-FP 1 Introduction Operation Manual 1.1 Product Outline Introduction Product Outline The FX Configurator-FP is a personal computer software for FX -20SSC-H and servo amplifiers, applicable to SSCNET ΙΙΙ. • Setting, monitoring and testing the parameters and table information of FX -20SSC-H.

  • Page 17: System Configuration

    FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration System Configuration 1.3.1 System Configuration The personal computer can be connected to the FX -20SSC-H in three ways. 1) Direct PLC connection The personal computer is connected to the PLC main unit directly. 2) Connection via Ethernet adapter Only Ethernet directly connect is supported.
  • Page 18 FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration 1) The equipment for RS-422 connection Converter/Cable Personal Computer PLC Connector Converter RS-232C Cable RS-422 Cable Connector (interface) Built-in dedicated programming -232CAB-1[3m(9'10")] FX-422CAB0[1.5m(4'11")] connector of the FX-232AWC-H main unit -422-BD D-SUB 9Pin (D-SUB 9Pin (D-SUB 25Pin...
  • Page 19 FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration Cautions on communication setting Do not change the communication settings for outside modules via parameters or sequence program. If changed, a communication error occurs between FX Configurator-FP and PLC (20SSC-H). 4) Check that the format of the communication connector to be used is correct. (D8120, D8400, D8420 = K0) Also, with peripheral devices, check that parameters for communication setting are correct.
  • Page 20 FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration 3. Connection via GOT This subsection shows the system configurations for Connection via GOT. → For the connection equipment for the personal computer, GOT1000 Series and PLC, refer to the GOT1000 series Manual. -20SSC-H 1) Connection to GOT via RS-232C...

  • Page 21: Applicable Models

    FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration 1.3.2 Applicable models • FX -20SSC-H type positioning module • Servo amplifier, applicable to SSCNET III (up to 2pcs) -20SSC-H via SSCNET ΙΙΙ. Connect these servo amplifiers to the FX 1.3.3 Operating System Requirements Item Description...
  • Page 22 FX Configurator-FP 1 Introduction Operation Manual 1.3 System Configuration Item Description ® ® 64MB or more • Microsoft Windows ® ® 64MB or more • Microsoft Windows ® ® 64MB or more • Microsoft Windows Millennium Edition: ® ® 64MB or more •...

  • Page 23: Installation, Uninstallation, Startup And Exit

    FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.1 Installation Installation, Uninstallation, Startup and Exit Installation Insert the FX Configurator-FP CD-ROM into the CD-ROM drive. Execute SETUP.EXE in the CD-ROM. Follow the guidance on the PC display to complete the installation. Caution FX Configurator-FP requires the following version of GX Developer (SW D5C-GPPW-E) or later: FX Configurator-FP must be reinstalled if it was first installed prior to the applicable version of GX Developer.

  • Page 24: Starting Fx Configurator-Fp

    FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.3 Starting FX Configurator-FP Starting FX Configurator-FP To start up FX Configurator-FP, follow the 3 procedures below. 2.3.1 Starting FX Configurator-FP from the start menu. → [All Programs] → [MELSOFT Application]. Click [Start] Select [FX Configurator-FP].

  • Page 25: Starting Fx-Configurator-Fp From The Tool Menu In Gx Developer

    FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.3 Starting FX Configurator-FP 2.3.2 Starting FX-Configurator-FP from the tool menu in GX Developer. Select [Tools] at the menu bar in GX Developer, click [FX special function utility] → [FX Configurator-FP] to start FX Configurator-FP. FX Configurator-FP starts up.
  • Page 26 FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.3 Starting FX Configurator-FP When the "New Module" dialog box appears, set "Module Type", "Module Name" and "Module No.". Click the [OK] button. The module set in "Special Module (Intelligent Function Module)" in the Project view is added. Added...
  • Page 27 FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.3 Starting FX Configurator-FP Select [Special Module (Intelligent Function Module)] in the Project view, and double-click [(Module)]. FX Configurator-FP starts up. Note • The special module of FX series is displayed as an intelligent function module in GX Works2. •...

  • Page 28: Closing Fx Configurator-Fp

    FX Configurator-FP 2 Installation, Uninstallation, Startup and Exit Operation Manual 2.4 Closing FX Configurator-FP Closing FX Configurator-FP Note When closing files or the application while online, i.e. Monitor Mode, Test Mode, the message bellow appears. Close the application while offline. Select [File] →...

  • Page 29: Window Configuration And Basic Operation

    FX Configurator-FP 3 Window configuration and basic operation Operation Manual 3.1 Window configuration Window configuration and basic operation Window configuration Title bar Menu bar Screen minimize button Toolbar Screen maximize button Online toolbar Drop-down menu Exits FX Configurator-FP Test toolbar File data list Window Status bar...
  • Page 30 FX Configurator-FP 3 Window configuration and basic operation Operation Manual 3.2 Menu configuration 3) View Shows /hides the tool bar, status bar and file data list. 4) Online Reads/Writes/Verifies, monitors and tests the module data, etc. 5) Tool Enables Error check and data initialization. 6) Window Cascades multiple windows and arranges icons.

  • Page 31: Tool Menus And Tool Button List

    FX Configurator-FP 3 Window configuration and basic operation Operation Manual 3.3 Tool menus and tool button list Tool menus and tool button list The tool bar has the menus below. Click the toolbar to show (checked)/hide (unchecked). Shows the file data list Shows the tool bar Shows the online tool bar Shows the test tool bar...

  • Page 32: Shortcut Key List

    FX Configurator-FP 3 Window configuration and basic operation Operation Manual 3.4 Shortcut key list Shortcut key list Item Shortcut key New (N) Ctrl + N Open (O) Ctrl + O File Save (S) Ctrl + S Print (P) Ctrl + P Cut (T) Ctrl + X Copy (C)

  • Page 33: Basic Operations In Dialog Box

    FX Configurator-FP 3 Window configuration and basic operation Operation Manual 3.6 Help 3.5.2 Basic operations in dialog box 1) Tab Click to switch the items. 1)Tab 2) Radio button Click < > to select 1 out of multiple items. 3) Check box Click <...

  • Page 34: Creating Files

    FX Configurator-FP 4 Creating files Operation Manual Creating files FX Configurator-FP sets and controls the data in the table below. Data Description Positioning Parameters for positioning operations, i.e. pulse rate, feed rate and maximum speed of parameter 20SSC-H Table information Setting data for table operations of X/Y/XY-axis Data to be transferred from 20SSC-H to servo amplifiers, including servo amplifier series, gain/ Servo parameter...

  • Page 35: Creating A New File

    FX Configurator-FP 4 Creating files Operation Manual 4.1 Creating a new file Creating a new file 4.1.1 Creating a new file This subsection shows how to create a new file. Caution When creating a new file while other files are opened, the following messages appear. 1) When the opened file is not changed •...

  • Page 36: Creating A New File With The Data Inside 20Ssc-H

    FX Configurator-FP 4 Creating files Operation Manual 4.1 Creating a new file 4.1.2 Creating a new file with the data inside 20SSC-H. Creating a new file with the data stored in 20SSC-H. Create a new file. → For the details, refer to Subsection 4.1.1. Connect FX PLC with Personal Computer.

  • Page 37: Opening A Stored File

    FX Configurator-FP 4 Creating files Operation Manual 4.2 Opening a stored file Opening a stored file Opening a stored file. Caution When opening a stored file while other files are opened, the following messages appear. 1) When the opened file is not changed •...
  • Page 38 FX Configurator-FP 4 Creating files Operation Manual 4.2 Opening a stored file Select a file to open. Item Description Look in Select a file location File name Enter the file name to open Select the files of type to open Files of type FX Configurator-FP FILE (*.fsn) : opens data for FX Configurator-FP Click [Open].

  • Page 39: File Storage

    FX Configurator-FP 4 Creating files Operation Manual 4.3 File storage File storage Storable information • Versions of files • Module type • Positioning parameters • Servo parameters • Table information • Connection Destination Messages Messages Conditions The allowable No. of characters has been The total amount of the character in the file path and exceeded.

  • Page 40: Saving As Files

    FX Configurator-FP 4 Creating files Operation Manual 4.3 File storage 4.3.2 Saving as files Saving newly created files, and stored files in different names. Select [File] → [Save as]. The dialog box to save as files appears. Select a file location and file name to save as. Item Description Look in...

  • Page 41: Closing Files

    FX Configurator-FP 4 Creating files Operation Manual 4.4 Closing files Closing files Closing currently opened files. Select [File] → [Close]. A message appears depending on the situation. Follow the message. 1) When the opened file is not changed • Click <Yes> to close the current file. •...

  • Page 42: Data Set

    FX Configurator-FP 5 Data set Operation Manual 5.1 User unit and Converted pulse data. Data set This chapter explains the procedures to set and error-check Positioning parameters, Servo parameters and Table information. → For the detail on Positioning parameters and Table information, refer to -20SSC-H user's manual.

  • Page 43: Setting Positioning Parameters

    FX Configurator-FP 5 Data set Operation Manual 5.2 Setting positioning parameters Setting positioning parameters Setting parameters (positioning parameters) for positioning control. Double-click [File name] → [Edit] → [Positioning parameters] in the file data list. An edit window for positioning parameters appears. Set the items for positioning parameters.
  • Page 44 FX Configurator-FP 5 Data set Operation Manual 5.2 Setting positioning parameters Item Description Default value Sets the system of units for positioning for the X/Y-axis. 0: Motor (PLS, Hz) 1: Mechanical (µm, cm/min) 2: Mechanical (0.0001inch, inch/min) System of unit 0: Motor (PLS, Hz) 3: Mechanical (mdeg, 10deg/min) 4: Composite (µm, Hz)
  • Page 45 FX Configurator-FP 5 Data set Operation Manual 5.2 Setting positioning parameters Item Description Default value Sets the maximum speed for the X/Y-axis. Set the speed at or below the maximum rotation speed servo motor. Maximum speed 4,000,000Hz Setting range : 1~2,147,483,647 [User unit] Set the value within 1~50,000,000Hz in the converted pulse data.
  • Page 46 FX Configurator-FP 5 Data set Operation Manual 5.2 Setting positioning parameters Item Description Default value Sets the software limit (lower) address for the X/Y-axis. Setting range : -2,147,483,648~2,147,483,647 [User unit] Software limit (lower) Set the value within -2,147,483,648~ 0 PLS 2,147,483,647PLS in the converted pulse data.
  • Page 47 FX Configurator-FP 5 Data set Operation Manual 5.2 Setting positioning parameters Item Description Default value Sets the Zero signal count start timing for the X/Y-axis. Zero signal count start 0: Backward end of DOG 0: Backward end of DOG timing 1: Forward end of DOG Sets the Zero signal count for the X/Y-axis.

  • Page 48: Setting Servo Parameters

    FX Configurator-FP 5 Data set Operation Manual 5.3 Setting servo parameters Setting servo parameters Setting the parameters (servo parameters) to transfer from 20SSC-H to servo amplifiers via SSCNET III. Double-click [File name] → [Edit] → [Servo parameters] in the file data list. An edit window for servo parameters appears.
  • Page 49 FX Configurator-FP 5 Data set Operation Manual 5.3 Setting servo parameters...
  • Page 50 FX Configurator-FP 5 Data set Operation Manual 5.3 Setting servo parameters Display colors of the servo parameters edit window Display colors of the servo parameters edit window have meanings as follows. Display color of the Description characters and frame Blue Default settings.

  • Page 51: Setting Table Information

    FX Configurator-FP 5 Data set Operation Manual 5.4 Setting table information Setting table information 5.4.1 The common items in table information. Setting the table information at X, Y, XY-axis. Set the contents below for each axis. → For table information details, refer to the FX -20SSC-H user’s manual.

  • Page 52: Setting X/Y-Axis Table Information

    FX Configurator-FP 5 Data set Operation Manual 5.4 Setting table information 5.4.2 Setting X/Y-axis table information Setting X/Y-axis table information Double-click [File name] → [Edit] → [X-axis table information] or [Y-axis table information] in the file data list. The selected X or Y-axis table information edit window appears. Set each item for the table information.

  • Page 53: Setting Xy-Axis Table Information

    FX Configurator-FP 5 Data set Operation Manual 5.4 Setting table information 5.4.3 Setting XY-axis table information Setting XY-axis table information. Double-click [File name] → [Edit] → [XY-axis table information] in the file data list. XY-axis table information edit window appears. Set each item for the table information.

  • Page 54: Error Check

    FX Configurator-FP 5 Data set Operation Manual 5.5 Error check Error check Checking the consistency and the incomplete settings in positioning parameters, servo parameters and table information. Select [Tool] → [Error check]. Error check dialog box appears. Select the item to be checked. Error check result Item Description...

  • Page 55: Setting The Connection Destination

    FX Configurator-FP 6 Setting the connection destination Operation Manual Setting the connection destination Setting the connection destination (COM port, transmission speed and the 20SSC-H module No.). Cautions on communication • When connecting the personal computer interfaces to the same COM port in FX Configurator-FP and GX Developer, set the same baud rate for both.
  • Page 56 FX Configurator-FP 6 Setting the connection destination Operation Manual Item Description Default setting Module Sets the module No. for 20SSC-H. Sets the module No. for 20SSC-H. Module No. Setting range: 0 to 7 Sets the timeout determination time. Unit: second Time check 5 seconds Setting range: 1 to 9999 seconds...

  • Page 57: Read / Write / Verify / Initialize

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.1 Data type and storage location Read / Write / Verify / Initialize Reading, Writing and Verifying the data (positioning parameters, servo parameters and table information) for each axis, and initializing the 20SSC-H. Caution When reading or writing data, use the FX Configurator-FP version that is the same as or later than the FX Configurator-FP used to write data to the 20SSC-H.
  • Page 58 FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.1 Data type and storage location 2. Data flow FX Configurator-FP: Setting/Monitoring tool for 20SSC-H GX Developer : Programming software for PLC -20SSC-H Buffer Memory (BFM) - Positioning parameters - Servo parameters Sequence - Table information...
  • Page 59 FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.1 Data type and storage location How to transfer (write) servo parameters to servo amplifiers When the power is turned ON or when the system is reset , servo parameters stored in the flash ROM are transferred to the buffer memory.

  • Page 60: Reading [Positioning/Servo Parameters And Table Information]

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.2 Reading [positioning/servo parameters and table information] Reading [positioning/servo parameters and table information] Reading [positioning/servo parameters and table information] from the 20SSC-H BFM. Operate any of the following procedures •...

  • Page 61: Writing [Positioning/Servo Parameters And Table Information]

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.3 Writing [positioning/servo parameters and table information] Writing [positioning/servo parameters and table information] Data writing procedures comprise of [Write to module] and [Flash ROM write]. 7.3.1 Writing to the BFM Writing [positioning parameters, servo parameters table information] to the 20SSC-H BFM.

  • Page 62: Writing To The Flash Rom

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.3 Writing [positioning/servo parameters and table information] 7.3.2 Writing to the Flash ROM Storing [positioning parameters, servo parameters and table information written beforehand in the 20SSC-H BFM] in the Flash ROM. After setting up and adjusting the system, it is handy when storing [positioning parameters, servo parameters and table information] in the BFM.

  • Page 63: Verifying [Positioning Parameters, Servo Parameters Table Information]

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.4 Verifying [positioning parameters, servo parameters table information] Verifying [positioning parameters, servo parameters table information] Verifying the following FX Configurator-FP data with the 20SSC-H BFM. • Positioning parameters •...
  • Page 64 FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.4 Verifying [positioning parameters, servo parameters table information] Click <OK>. The verification result of selected data appears. When the verification result agrees. When the verification result disagrees. Item Description Verify Displays the special function unit/block name of verifying destination...

  • Page 65: Initializing The Bfm And Flash Rom

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.5 Initializing the BFM and Flash ROM Initializing the BFM and Flash ROM Initializing [positioning parameters, servo parameters and table information] in the 20SSC-H BFM and Flash ROM. Select [Online] →...

  • Page 66: Execute System Reset Of The 20Ssc-H

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.6 Execute system reset of the 20SSC-H Execute system reset of the 20SSC-H → r more details on system reset details, R efer to the FX -20SSC-H User's manual. Operate any of the following procedures •...

  • Page 67: The Displayed Messages And Countermeasures

    FX Configurator-FP 7 Read / Write / Verify / Initialize Operation Manual 7.8 The displayed messages and countermeasures The displayed messages and countermeasures This section explains the countermeasures for error messages. Displayed Message Description Cannot communicate with the PLC. Execute again after A communication error has occurred.

  • Page 68: Debug In The Positioning

    FX Configurator-FP 8 Debug in the positioning Operation Manual Debug in the positioning DESIGN PRECAUTIONS • Provide a safety circuit on the outside of the PLC so that the whole system operates to ensure the safety even when external power supply trouble or PLC failure occurs. Otherwise, malfunctions or output failures may result in an accident.
  • Page 69 • Do not disassemble or modify the PLC. Doing so may cause failures, malfunctions or fire. For repair, contact your local Mitsubishi Electric distributor. • Before connecting or disconnecting any extension cable, turn off power. Failure to do so may cause unit failure or malfunctions.

  • Page 70: Monitor

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor Monitor 8.1.1 Monitoring the operation Monitoring the operation status along each axis. Double-click [File name] → [Monitor] → [Operation monitor] in the file data list. [Operation monitor] dialog box appears. Item Description Displays the present address of X/Y-axis...
  • Page 71 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor Item Description Displays the X/Y-axis error code Error code Displays 0 with no error Displays the X/Y-axis ON-state m code m code Displays -1 with no ON-state m code Flash ROM write count Displays the writing count to Flash ROM Opens the signal monitor window, available only while monitoring...

  • Page 72: Signal Monitor

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor 8.1.2 Signal monitor Monitoring the status information and servo status information. Double-click [File name] → [Monitor] → [Operation monitor] → [Signal] in the file data list. [Status signal] tab in [Signal] dialog box appears. Click the status tab to be monitored.

  • Page 73: Operation Status Monitor

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor 8.1.3 Operation status monitor Monitoring the detailed operation status along X/Y-axis. Double-click [File name] → [Monitor] → [Operation monitor] → [X-axis Opera- tion status] / [ Y-axis Operation status] in the file data list. [Axis control data] tab in [X/Y-axis Operation status] dialog box appears.
  • Page 74 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor 2. Axis monitor data tab This window displays [X-axis Operation status] dialog box. Item Description Real current value monitor Displays the Real current value monitor Real current address Displays the Real current address [Unit : User unit Received target value Displays the Received target value monitor monitor...
  • Page 75 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor → Refer to Section 5.1. 4. Servo monitor tab This window displays [X-axis Operation status] dialog box. Item Description Servo status Displays Servo status Deviation counter value Displays the deviation counter value [Unit : PLS] Motor revolution number Displays the motor revolution number [Unit : 0.1r/min] Motor current value Displays the motor current value [Unit : 0.1%]...

  • Page 76: Monitoring Table Information

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.1 Monitor 8.1.4 Monitoring table information Monitoring the table information in execution, from the table information edit window. Caution Monitor mode doesn't allow each item to change. Change/set the value after switching the window into the edit mode.

  • Page 77: Testing The Operation

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Testing the Operation STARTUP AND MAINTENANCE PRECAUTIONS • Do not touch any terminal while the PLC's power is on. Doing so may cause electrical shock or malfunctions. •...

  • Page 78: Operation Test In The Positioning (Except Jog/Mpg)

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.2 Operation test in the positioning (except JOG/MPG) Testing the operation in the 20SSC-H positioning (except into JOG/MPG) by test mode. → For the procedure to switch into test mode, refer to Subsection 8.2.1. Follow any of the procedures below when switching the test mode into monitor mode.
  • Page 79 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Item Description X/Y-axis Sets the positioning operation along X/Y-axis Ticks off to start X and Y-axis simultaneously Sync start [Operation test X-axis] dialog box displays the check box in the Y-axis item [Operation test Y-axis] dialog box displays the check box in the X-axis item Sets/displays the operation pattern Available in [X-axis operation test] only...
  • Page 80 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Click <Start> 20SSC-H starts the table operation with the pre-set contents.

  • Page 81: Changing The Present Value

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.3 Changing the present value Changing the present value the 20SSC-H's present value by test mode. → For the procedure to switch into test mode, refer to Subsection 8.2.1. Follow any of the procedures below.
  • Page 82 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Item Description Displays present address, Operation speed present value, status information and Error Monitor item code Present address Displays the present address [Unit : User unit Operation speed present Displays the operation speed present value [Unit : User unit value Displays status information...

  • Page 83: Speed Change

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.4 Speed change Changing the operation speed and speed override setting in the following operations, by test mode. → For the procedure to switch into test mode, refer to Subsection 8.2.1. →...
  • Page 84 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Item Description Displays present address, Operation speed present value, status information and Error Monitor item code Present address Displays the present address [Unit : User unit Operation speed present Displays the operation speed present value [Unit : User unit value Displays status information...

  • Page 85: Zero Return

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.5 Zero return Executing the mechanical zero return by the OPR mode specified in test mode. → For the procedure to switch into test mode, refer to Subsection 8.2.1. Follow any of the procedures below.
  • Page 86 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Item Description Displays present address, Operation speed present value, status information and Error Monitor item code Present address Displays the present address [Unit : User unit Operation speed present Displays the operation speed present value [Unit : User unit value Displays status information...

  • Page 87: Jog/Mpg

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.6 JOG/MPG Executing the JOG/MPG in test mode, also confirming the following operations, by JOG/MPG in the positioning control debug. → For the procedure to switch into test mode, refer to Subsection 8.2.1. •...
  • Page 88 FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation Item Description Displays present address, Operation speed present value, status information and Error Monitor item code Present address Displays the present address [Unit : User unit Operation speed present Displays the operation speed present value [Unit : User unit value Displays status information...

  • Page 89: Turning Off M Codes

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.7 Turning OFF m codes Turning off the m code while monitor/test mode. → For the procedure to switch into test mode, refer to Subsection 8.2.1. Follow any of the procedures below. •...

  • Page 90: 8.2.10 Servo On/Off

    FX Configurator-FP 8 Debug in the positioning Operation Manual 8.2 Testing the Operation 8.2.10 Servo ON/OFF Executing servo ON/OFF while test mode. By servo ON/OFF, the servo motor turns into the state in the following table. → For the procedure to switch into test mode, refer to Subsection 8.2.1. The servo motor state Servo ON Locks servo motors and turns them into the standby state...

  • Page 91: Print

    FX Configurator-FP 9 Print Operation Manual 9.1 Setting the printer Print Setting the printer Setting the printer, paper and orientation. Select → [File] → [Printer setup]. [Print Setup] dialog box appears. Set each item for the print setup. → For print setup details, refer to the OS manual to be used. →...

  • Page 92: Printing

    FX Configurator-FP 9 Print Operation Manual 9.2 Printing Printing 9.2.1 Setting the item to print Printing the positioning parameters, servo parameters and table information. Follow any of the procedures below. • Click [Print]. • Select [File] → [Print]. The [Print] dialog box appears. Set the item to print.
  • Page 93 FX Configurator-FP 9 Print Operation Manual 9.2 Printing 2. [Servo parameters] tab Item Description Servo parameters Specifies the axis data to print All item Prints X, Y and XY-axis data Prints the ticked items • Servo amplifier series • Basic setting parameters Item specification •...
  • Page 94 FX Configurator-FP 9 Print Operation Manual 9.2 Printing 3. [Table information] tab Item Description Table information No. Specifies the axis data to print All range Prints all range of the table information Sets the table information printing range for each axis Each axis setting range : 0 to 299 Range specification •...

  • Page 95: Printing Examples

    FX Configurator-FP 9 Print Operation Manual 9.2 Printing 9.2.2 Printing examples 1. Positioning parameters printing examples 2. Servo parameters printing examples 3. Table information printing examples...

  • Page 96: 10. Edit Function In Data Setting

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.1 Cut / Copy / Paste / Select all 10. Edit function in data setting 10.1 Cut / Copy / Paste / Select all Partially cutting/copying/pasting the positioning parameter settings. Also Cutting/copying the value in a table ®...

  • Page 97: 10.1.2 Paste

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.1 Cut / Copy / Paste / Select all 10.1.2 Paste Select cells to paste. Follow any of the procedures below. • Click [Paste]. • Right-click to select [Paste]. • Select [Edit] → [Paste].

  • Page 98: 10.1.3 Select All

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.2 Cursor jump 10.1.3 Select all Cutting/copying all range of table information, and pasting. The data items inconsistency between axis disables all-range-paste. Select [Edit] → [Select all]. Paste the all range data. →...

  • Page 99: Initializing Rows/Columns

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.3 Initializing rows/columns 10.3 Initializing rows/columns Initializing the rows/columns selected in the table information edit window. Multiple rows/columns are selectable to initialize. Select the part of rows/columns to initialize. Follow any of the procedures below. •...

  • Page 100: Delete Row

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.5 Delete row 10.5 Delete row Delete rows by the number of rows selected on the table information edit window. Select cells to Delete row. Follow any of the procedures below. •...

  • Page 101: Initializing Data

    FX Configurator-FP 10 Edit function in data setting Operation Manual 10.6 Initializing data 10.6 Initializing data Initializing the positioning parameters, servo parameters and table information along each axis. Select [Tool] → [Initialize data]. [Initialize data] dialog box appears. Set the data to initialize. Item Description Initializes the positioning parameters along the ticked axis...
  • Page 102 FX Configurator-FP 10 Edit function in data setting Operation Manual 10.6 Initializing data MEMO...

  • Page 103: Warranty

    Mitsubishi. of applications. Any other failure found not to be the responsibility However, in certain cases, some applications may be of Mitsubishi or that admitted not to be so by the possible, providing the user consults their local user. Mitsubishi...

  • Page 104: Revised History

    FX Configurator-FP Operation Manual Revised History Revised History Date Revision Description 12/2005 First Edition 1/2007 Added items for Ver.1.10 Supports FX -20SSC-H (Ver.1.10) • Ring counter setting was added. • Servo parameter transfer mode selection was added. • Mode selection added to the Interrupt stop at 1-step speed •...
