BARCO PROJECTION SYSTEMS
K
E
IT
NGINE
ELM
R1306981K(R12)
R1306991K(G10)
INSTALLATION MANUAL
Replacement of the DLP UHB (Engine) in the
ELM series projectors
Date: 29.05.2001
Rev: 00
Art. No.: R5976199

Advertisement

loading
Need help?

Need help?

Do you have a question about the R1306981K(R12) and is the answer not in the manual?

Questions and answers

Summary of Contents for Barco R1306981K(R12)

  • Page 1 BARCO PROJECTION SYSTEMS NGINE R1306981K(R12) R1306991K(G10) INSTALLATION MANUAL Replacement of the DLP UHB (Engine) in the ELM series projectors Date: 29.05.2001 Rev: 00 Art. No.: R5976199...
  • Page 2 Produced by BARCO NV, May 2001. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visite Barco at the web : http://www.barco.com Printed in Belgium...
  • Page 3 UV radiation. An evaluation of the workplace is advised) PRODUCT CARE Installation Kit: - The Engine is designed for use ONLY with the BARCO ELM series projectors. Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replacement parts or authorized replacement parts which have the same characteristics as the BARCO original part.
  • Page 4 R5976199 MAN INS G10/R12ELM ENGINE Illustration R818727 Remark In the following chapters we will (for practical reasons) refer to DLP (S)XGA UHB as Engine. Warning ATTENTION OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC DISCHARGE SENSITIVE DEVICES BARCO ——————————————————— 4 ————————————— Projection Systems...
  • Page 5 Slide the clevis pin out of the stud. 1&2 Remove the 4 bolts (E) holding top cover to main frame. Remove the metal top cover. Illustrations Image 2 Image 1 to be continued on next page BARCO ——————————————————— 5 ————————————— Projection Systems...
  • Page 6 Flip the bottom of the side cover (B) a little towards you and pull it downwards to remove. Do the same for the other side cover (bolts C on image 3) Illustrations Image 1 Image 2 BARCO ——————————————————— 6 ————————————— Projection Systems...
  • Page 7 Remove the 3 bolts (A) fixating each stud to main frame Remove the bolt (B) fixating the wrist band (C) to cross bar. Remove both studs and crossbar. Illustrations Picture 1 Picture 2 Picture 3 To be continued on next page BARCO ——————————————————— 7 ————————————— Projection Systems...
  • Page 8 Remove the bolt (B) fixating the wrist band (C) to frame. Disconnect the connectors (D) of the 2 FANS assuring top cooling for the engine. Remove the box cover now. Illustrations Image 1 Image 2 To be continued on next page BARCO ——————————————————— 8 ————————————— Projection Systems...
  • Page 9 Depending on the projector the picture may not always coincide with the reality (metallic frame slightly different etc,...). However, the procedure for removing the Engine re- mains the same for every G10 or R12 ELM projector. BARCO ——————————————————— 9 ————————————— Projection Systems...
  • Page 10 Picture Push for each flexfoil connector the lock clips (A) outside to unlock. Carefully unplug the 3 flexfoil connectors (B) from module Unlock the module by pulling upwards both module locks Illustrations Picture 1 BARCO ——————————————————— 10 ————————————— Projection Systems...
  • Page 11 Depending on the projector, these cables can be fixed under or above the metallic frame ( see 2&3) Remove the 8 connectors (C) on the module 4(next page) Illustrations Image 1 Picture 2 Picture 3 To be continued on next page BARCO ——————————————————— 11 ————————————— Projection Systems...
  • Page 12 Removing the Cables (Continued) Illustrations Picture 4 BARCO ——————————————————— 12 ————————————— Projection Systems...
  • Page 13 Insert the 3 flexfoil connectors in the slots (D) of the support plate and tie each of them with the cable ties (F). 4&5(next Illustrations Image 1 Image 2 To be continued on next page BARCO ——————————————————— 13 ————————————— Projection Systems...
  • Page 14 Removing the Engine (Continued) Illustrations Image 3 Image 4 Image 5 BARCO ——————————————————— 14 ————————————— Projection Systems...
  • Page 15 (inclined arrows on image 2). page) Tighten the 3 screws (B). 4(next For the third screw located on the backside handle as page) explained in chapter ‘Removing the Engine’. Illustrations Image 1 To be continued on next page BARCO ——————————————————— 15 ————————————— Projection Systems...
  • Page 16 Mounting the Engine (Continued) Illustrations Image 2 Image 3 Image 4 BARCO ——————————————————— 16 ————————————— Projection Systems...
  • Page 17 Lock each plug by pushing the plug clips (D) to the inside. Slide the module fully downwards until the module seats. Lock the module in its frame by pushing the 2 module locks (B) downwards. Illustrations Picture 1 to be continued on next page BARCO ——————————————————— 17 ————————————— Projection Systems...
  • Page 18 Formatter Module Connection (Continued) Illustrations Image 2 Image 3 BARCO ——————————————————— 18 ————————————— Projection Systems...
  • Page 19 Tighten the cables on the frame by locking the clips (C). 3&4(next Depending on the projector these cables can be fixed page) under or above the metallic frame ( see Image 3&4) Illustrations Image 1 Picture 2 To be continued on next page BARCO ——————————————————— 19 ————————————— Projection Systems...
  • Page 20 Replacing the Cables (Continued) Illustrations Picture 3 Picture 4 BARCO ——————————————————— 20 ————————————— Projection Systems...
  • Page 21 After adjustment, re-seal the adjusted screws with Loctite Verni-Stop. Illustrations F olding M irro r D M D & Image 1 Image 2 Image 3 BARCO ——————————————————— 21 ————————————— Projection Systems...
  • Page 22 Reinstall the wrist strap between cover and main frame. Reinstall the crossbar with the studs. Reinstall the wrist strap between cover and crossbar. Reinstall the side covers. Reinstall the top cover. Reinstall the clevis and linch pin BARCO ——————————————————— 22 ————————————— Projection Systems...
