VisionNet M505N User Manual

Adsl2+ / ethernet wan residential gateway
Hide thumbs Also See for M505N:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual

User Manual

Model Number:
M505N
Product Description:
To Contact VisionNet for Tier 2 Support:
DQ Technology, Inc. / VisionNet
ADSL2+ / Ethernet WAN Residential Gateway featuring:
Qty 4 10/100 Ethernet Port
Qty 1 USB 2.0
802.11b/g/n 2T2R
Voice:
Email:
Online:
Page 1
+ 1 925 730 3940
support@visionnetusa.com
http://www.visionnetusa.com/ticketportal
M505N User Manual Revision 3.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M505N and is the answer not in the manual?

Questions and answers

Related Manuals for VisionNet M505N

Summary of Contents for VisionNet M505N

  • Page 1: User Manual

    Model Number: M505N Product Description: ADSL2+ / Ethernet WAN Residential Gateway featuring: Qty 4 10/100 Ethernet Port Qty 1 USB 2.0 802.11b/g/n 2T2R To Contact VisionNet for Tier 2 Support: Voice: + 1 925 730 3940 Email: support@visionnetusa.com Online: http://www.visionnetusa.com/ticketportal DQ Technology, Inc.

  • Page 2: Table Of Contents

    SECTION 6: SECURITY CONFIGURATION Port Forwarding Port Triggering DMZ Host UPnP Algorithm Enable / Disable WAN Access Control (Parental Control) URL Filtering (Parental Control) IP Filtering Bridge Access Control DQ Technology, Inc. / VisionNet Page 2 M505N User Manual Revision 3.2...
  • Page 3 Wireless Configuration 10.4 Global Settings 10.5 MAC Filtering 10.6 Wireless Bridge SECTION 11: PRODUCT DEPICTIONS AND BEHAVIOR 11.1 LED Behavior 11.2 Product Depiction SECTION 12: Troubleshooting 12.1 Port Mirroring DQ Technology, Inc. / VisionNet Page 3 M505N User Manual Revision 3.2...

  • Page 4: Section 1: Gui Access

    Once the modem responds, you will be challenged for a User Name and Password Remote Access Privileged Username: support Password: ISP Specific Restricted Username: techsupport Password: ISP Specific Local Access Privileged Username: admin Password: ISP Specific Restricted Username: enduser Password: password DQ Technology, Inc. / VisionNet Page 4 M505N User Manual Revision 3.2...
  • Page 5 You will be directed to the Main GUI Page PLEASE NOTE: ONLY the End User Login should be given to End Users. NEVER RELEASE ANY OTHER LOGIN INFORMATION. DQ Technology, Inc. / VisionNet Page 5 M505N User Manual Revision 3.2...

  • Page 6: Section 2: Troubleshooting

    Protocol: ISP Specific WHAT THESE STATISTICS MEAN: This page will verify that the WAN connection is operating correctly, and that the modem has obtained a WAN IP Address DQ Technology, Inc. / VisionNet Page 6 M505N User Manual Revision 3.2...

  • Page 7: View Wan Details

    WHAT THESE STATISTICS MEAN: This page will verify that data is being received and transmitted. You will also be able to view detailed IPV4, IPV6, and Configuration Settings DQ Technology, Inc. / VisionNet Page 7 M505N User Manual Revision 3.2...

  • Page 8: View Dsl Statistics

    Then, In the left-hand frameset, select “xDSL WHAT THESE STATISTICS MEAN: This page will verify DSL Link, and will provide information regarding line characteristics and capacities. DQ Technology, Inc. / VisionNet Page 8 M505N User Manual Revision 3.2...

  • Page 9: View Atm Statistics

    Then, In the left-hand frameset, select “ATM” WHAT THESE STATISTICS MEAN: This page will verify ATM Operation, and specify the type of packets being sent DQ Technology, Inc. / VisionNet Page 9 M505N User Manual Revision 3.2...

  • Page 10: View Dhcp Statistics

    This page will provide the IP Addresses assigned by the modem’s DHCP server, the MAC addresses of dynamically assigned devices, and the amount of time that the device has spent on the network. DQ Technology, Inc. / VisionNet Page 10 M505N User Manual Revision 3.2...

  • Page 11: View Arp Statistics

    This page will provide the MAC Addresses of all recognized devices connected to the modem. A device will only be recognized once it has requested data from the modem. DQ Technology, Inc. / VisionNet Page 11 M505N User Manual Revision 3.2...

  • Page 12: View Lan Statistics

    “Gateway Statistics” tab located within the left-hand frameset. Then, In the left-hand frameset, select “LAN” WHAT THESE STATISTICS MEAN: This page will verify that LAN Devices are communicating. DQ Technology, Inc. / VisionNet Page 12 M505N User Manual Revision 3.2...

  • Page 13: Verify Connectivity Via Ping

    TO TEST REMOTE WAN IP ADDRESSES: Enter the WAN IP Address and select “Ping Request” ie: 4.2.2.4 TO TEST REMOTE WAN DOMAIN NAMES: Enter the Domain Name and select “Ping Request” Ie: www.bing.com DQ Technology, Inc. / VisionNet Page 13 M505N User Manual Revision 3.2...
  • Page 14 The modem can access the internet, but this does not necessarily mean that DNS resolution is operational If you can Ping a WAN Domain Name The modem can access the internet correctly DQ Technology, Inc. / VisionNet Page 14 M505N User Manual Revision 3.2...

  • Page 15: Verify Connectivity Via Trace Route

    This test will show you the path of the data being sent to the internet This path includes resolving the Domain Name with a DNS Server DQ Technology, Inc. / VisionNet Page 15 M505N User Manual Revision 3.2...
  • Page 16 DQ Technology, Inc. / VisionNet Page 16 M505N User Manual Revision 3.2...

  • Page 17: Remote / Local System Log Recording

    Step 1: Access the GUI to begin SysLog Configuration Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “System Log” Select the “Configure System Log” Button DQ Technology, Inc. / VisionNet Page 17 M505N User Manual Revision 3.2...
  • Page 18 This must match the IP of the computer running Kiwi Server IP Address: VisionNet suggests that the computer running Kiwi be statically assigned to 192.168.1.239 Server UDP Port: Select “Save/Apply” DQ Technology, Inc. / VisionNet Page 18 M505N User Manual Revision 3.2...

  • Page 19: Ppp Debug System Logging

    Edit the PPP Authentication Page PPP DEBUG Enabled Proceed through the remainder of the edit section. PLEASE NOTE: THIS IS TEMPORARY ONLY, AND MUST NOT BE LEFT AS A PERMANENT CONFIGURATION DQ Technology, Inc. / VisionNet Page 19 M505N User Manual Revision 3.2...

  • Page 20: Nat Inspection Via Command Line Interface

    Point the Telnet Client at the IP Address of the CPE LOCAL: Use the private IP Address REMOTE: Use the public IP Address Login using the appropriate username and password Enter the following command: cat /proc/net/nf_conntrack DQ Technology, Inc. / VisionNet Page 20 M505N User Manual Revision 3.2...

  • Page 21: Section 3: Wan Configuration

    SECTION 3: WAN CONFIGURATION Section 3.1 – Changing DSL Parameters VisionNet modems come pre-configured with the following DSL Settings DSL Protocol Status G.DMT Enabled G.Lite Enabled T1.413 Enabled ADSL2 Enabled ADSL2+ Enabled Annex L Enabled Annex M Disabled Bitswap Enabled...

  • Page 22: Wan Logic Overview

    → Create WAN Interface Create WAN Service associated with WAN Interface TEARING DOWN (REMOVING) A WAN SERVICE → Delete WAN Service associated with WAN Interface Delete WAN Interface DQ Technology, Inc. / VisionNet Page 22 M505N User Manual Revision 3.2...

  • Page 23: Selecting A Wan Interface To Create

    Section 3.3 – Selecting a WAN Interface to Create The VisionNet modem comes pre-configured. Unless you have VLAN Mux Enabled, you can only use one interface per physical port. Hence, do not attempt to build a new interface until you have removed any conflicting interfaces.

  • Page 24: Creating A Dsl Interface

    Step 1: Selecting the WAN Interface to Create Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”DSL Interfaces” Select “Add” DQ Technology, Inc. / VisionNet Page 24 M505N User Manual Revision 3.2...
  • Page 25 Use multiple service configurations IE: Data PVC – 1/8 IE: IPTV PVC – 1/1 Select “Apply Save” You will see the Interface reflected in the updated Interface Table DQ Technology, Inc. / VisionNet Page 25 M505N User Manual Revision 3.2...

  • Page 26: Creating A Ptm Interface

    Step 1: Selecting the WAN Interface to Create Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”PTM Interfaces” Select “Add” DQ Technology, Inc. / VisionNet Page 26 M505N User Manual Revision 3.2...
  • Page 27 Standard for single service config Select ISP QoS Weighted Fair Queuing Use multiple service configurations Select “Apply Save” You will see the Interface reflected in the updated Interface Table DQ Technology, Inc. / VisionNet Page 27 M505N User Manual Revision 3.2...
  • Page 28 Step 1: Selecting the WAN Interface to Create Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”Ethernet Interfaces” Select “Add” DQ Technology, Inc. / VisionNet Page 28 M505N User Manual Revision 3.2...
  • Page 29 Default Mode Standard (Single Service) Select Connection Mode: VLAN MUX Multiple VLANs over a single Select “Apply Save” You will see the Interface reflected in the updated Interface Table DQ Technology, Inc. / VisionNet Page 29 M505N User Manual Revision 3.2...

  • Page 30: Creating An Ipoe Wan Service

    Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”Ethernet Services” Select “Add” Select the desired WAN Interface DQ Technology, Inc. / VisionNet Page 30 M505N User Manual Revision 3.2...
  • Page 31 Automatically Only if specified Options 55 to by your Network Ops Manager Use the Enter appropriate following information Static IP 1500 unless specified by your Network Operations Manager DQ Technology, Inc. / VisionNet Page 31 M505N User Manual Revision 3.2...
  • Page 32 You may prioritize the Dynamic DNS Servers You may specify static DNS Servers When complete you may approve the settings. You will see the service populated in the “WAN Services” table DQ Technology, Inc. / VisionNet Page 32 M505N User Manual Revision 3.2...
  • Page 33 Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”Ethernet Services” Select “Add” Select the desired WAN Interface DQ Technology, Inc. / VisionNet Page 33 M505N User Manual Revision 3.2...
  • Page 34 Bridge PPPoE Clients to tunnel through Frames the firewall to create a second PPPoE Session Disabled unless specified MultiCast Proxy otherwise by Network Operations Routing – Default Gateway DQ Technology, Inc. / VisionNet Page 34 M505N User Manual Revision 3.2...
  • Page 35 You may prioritize the Dynamic DNS Servers You may specify static DNS Servers When complete you may approve the settings. You will see the service populated in the “WAN Services” table DQ Technology, Inc. / VisionNet Page 35 M505N User Manual Revision 3.2...

  • Page 36: Creating A Bridge Wan Service

    Select the “WAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select the appropriate WAN Interface ”Ethernet Services” Select “Add” Select the desired WAN Interface DQ Technology, Inc. / VisionNet Page 36 M505N User Manual Revision 3.2...
  • Page 37 VLAN Mux Services) -1 Untagged 802.1Q Tag (Only Otherwise, choose appropriate for VLAN Mux Services) Select “Next” to complete the Bridge WAN Service Select “Apply / Save” DQ Technology, Inc. / VisionNet Page 37 M505N User Manual Revision 3.2...

  • Page 38: Wan Interface Prioritization

    Section 3.10 – WAN Interface Prioritization You may wish to support either the DSL or ATM Interface. You may choose the WAN Interface priority for your VisionNet gateway. Step 1: Access the GUI to find the WAN Interface Page Select the “WAN”...

  • Page 39: Gateway Prioritization

    Section 3.11 – Gateway Prioritization The VisionNet modem is designed to utilize each WAN specific gateway for it’s intended purpose. You may specify which WAN Services are used for outbound traffic, and in which order, through Gateway Prioritization Step 1: Access the GUI to find the Gateway Page Select the “Routing”...

  • Page 40: Universal Static Gateway Service

    “Routing” tab located within the left-hand frameset. Then, In the left-hand frameset, select “Default Gateway” Check “Enable Static Gateway IP Address” Enter the desired Static Gateway Select “Save” DQ Technology, Inc. / VisionNet Page 40 M505N User Manual Revision 3.2...

  • Page 41: Dns Prioritization

    Step 1: Access the GUI to find the DNS Server Page Select the “DNS” tab located within the left-hand frameset. Then, In the left-hand frameset, select “DNS Server” Select “Select DNS Server Interfaces from available WAN Interfaces” DQ Technology, Inc. / VisionNet Page 41 M505N User Manual Revision 3.2...
  • Page 42 Prioritize WAN Interfaces from Top to Bottom Select “Apply / Save” and then reboot the modem DQ Technology, Inc. / VisionNet Page 42 M505N User Manual Revision 3.2...

  • Page 43: Universal Static Dns Service

    Section 3.14 – Universal Static DNS Addresses The VisionNet Modem may be assigned different DNS addresses for each WAN Service. In the event that Static IPs are to be used, you may update and change the settings with the following procedure.
  • Page 44 Enter the Primary and Secondary WAN DNS Addresses Select “Apply / Save” and then reboot the modem DQ Technology, Inc. / VisionNet Page 44 M505N User Manual Revision 3.2...

  • Page 45: Section 4: Public Wan Ip Address Allocation

    Step 1: Select the appropriate WAN Service for modification Create the desired WAN Interface Enter the required Public IP Information Ensure the following settings NAT must be DISABLED Firewall must be DISABLED IGMP must be DISABLED DQ Technology, Inc. / VisionNet Page 45 M505N User Manual Revision 3.2...
  • Page 46 Enter ISP WAN Gateway You may also specify the static DNS Page by access “DNS” and then “DNS SERVER” You may enter the Static DNS Information Select “Save / Apply” DQ Technology, Inc. / VisionNet Page 46 M505N User Manual Revision 3.2...
  • Page 47 Reserve IP Address Unnecessary Configure Secondary IP Unchecked Address: Once complete, select “Save/Reboot” PLEASE NOTE THAT LAN DEVICES MUST BE REBOOT PRIOR TO OBTAINING NEW, PUBLIC, IP ADDRESSES DQ Technology, Inc. / VisionNet Page 47 M505N User Manual Revision 3.2...

  • Page 48: Public Ip Allocation - Virtual Public Subnet (Wan Interface Not Within Subnet)

    Why Virtual IP Allocation You may wish to allocate IP Addresses, directly to devices, that are assigned to the customer; but not the primary WAN Interface of the Gateway DQ Technology, Inc. / VisionNet Page 48 M505N User Manual Revision 3.2...
  • Page 49 In the left-hand frameset select “WAN” Then select “WAN Services” Choose the appropriate WAN Service, and select “Edit” Disable “Firewall” ONLY “ENABLE NAT” SHOULD BE ENABLED!!! Review the WAN Setup Summary DQ Technology, Inc. / VisionNet Page 49 M505N User Manual Revision 3.2...
  • Page 50 Configure the Second IP Address and Subnet Mask for LAN Interface Enter the first usable Host within the desired subnet Enter the Subnet Mask (255.255.255.248) Select “Apply Save” DQ Technology, Inc. / VisionNet Page 50 M505N User Manual Revision 3.2...
  • Page 51 EACH HOST MUST BE CONFIGURED WITH THE FOLLOWING SETTING IP ADDRESS: Usable Host Subnet Mask: 255.255.255.248 Gateway: First Usable Host (CPE LAN IP Address) DNS Address: Choose appropriate Birch DNS Servers DQ Technology, Inc. / VisionNet Page 51 M505N User Manual Revision 3.2...

  • Page 52: Public Ip Allocation - 1:1 Nat Public Subnet

    Why 1:1 NAT (Multi-NAT) Multi-NAT will allow you to forward traffic, destined for a WAN IP Address within the assigned subnet, to an internal Host assigned with a private LAN IP. DQ Technology, Inc. / VisionNet Page 52 M505N User Manual Revision 3.2...
  • Page 53 Step 1: Edit an existing WAN Connection In the left-hand frameset select “WAN” Then select “WAN Services” Choose the appropriate WAN Service, and select “Edit” Disable “Firewall” ONLY “ENABLE NAT” SHOULD BE ENABLED!!! DQ Technology, Inc. / VisionNet Page 53 M505N User Manual Revision 3.2...
  • Page 54 Step 2: Apply Static LAN IPs to Devices to that will have direct WAN Access Please see section 4.2 for further instruction Step 3: Configure 1:1 NAT In the left-hand frameset select “Security” Then select “Multi-NAT” DQ Technology, Inc. / VisionNet Page 54 M505N User Manual Revision 3.2...
  • Page 55 One to One Choose appropriate WAN Use Interface: Interface Choose LAN IP Address – Internal AddrStart 192.168.1.200 Choose WAN IP Address External AddrStart – ie: 172.20.111.147 Review the NAT Table DQ Technology, Inc. / VisionNet Page 55 M505N User Manual Revision 3.2...

  • Page 56: Public Ip Allocation - Pppip Extension (Single Public Ip)

    Step 1: When creating a WAN Connection 1.A PPP Configuration PPPIP Extension must be enabled NAT must be DISABLED Full Cone NAT must be DISABLED Firewall must be DISABLED DQ Technology, Inc. / VisionNet Page 56 M505N User Manual Revision 3.2...
  • Page 57 The LAN Section will be modified automatically DQ Technology, Inc. / VisionNet Page 57 M505N User Manual Revision 3.2...

  • Page 58: Section 5: Lan Configuration

    WAN DNS Address Leased Time (hour): All other settings Unnecessary Configure Second IP Address: Unchecked Select “Apply / Save” Section 5.2 – Reserving an IP Address Within the DHCP Server DQ Technology, Inc. / VisionNet Page 58 M505N User Manual Revision 3.2...

  • Page 59: Reserving A Public Ip Address

    “DHCP Static IP Lease” Page Enter the MAC Address of the intended LAN Host, and the IP Address that you would like to permanently allocate to that host. Select “Apply Save” DQ Technology, Inc. / VisionNet Page 59 M505N User Manual Revision 3.2...

  • Page 60: Igmp Force

    Step 1: Direct Your Browser to the LAN Configuration Page Select the “LAN” tab located within the left-hand frameset. Then, In the left-hand frameset, select “IGMP Force” Make desired changes Select “Apply Save” DQ Technology, Inc. / VisionNet Page 60 M505N User Manual Revision 3.2...

  • Page 61: Section 6: Security Configuration

    SECTION 6: SECURITY CONFIGURATION Section 6.1 – Port Forwarding VISIONNET MODEMS ARE PRE-CONFIGURED FOR THE FOLLOWING APPLICATIONS: XBOX: UPnP will resolve most XBOX issues, however should you need to do further trouble-shooting the following Port Forwarding Rules may be enabled...
  • Page 62 Please Note: If the port to be assigned is already specified in the existing Port Forwarding Table, you must remove the rule containing this port prior to creating a new one. DQ Technology, Inc. / VisionNet Page 62 M505N User Manual Revision 3.2...
  • Page 63 For this rule to work properly, the LAN device must have either a Static IP, or a Reserved IP The LAN Device, and modem, may should be reset to ensure that this rule continues to work correctly DQ Technology, Inc. / VisionNet Page 63 M505N User Manual Revision 3.2...

  • Page 64: Port Triggering

    Port Triggering is ideal for portable devices (ie:laptops, PDAs, etc) which require port forwarding, but for which a Static LAN IP would be antithetical to the device’s common usage. DQ Technology, Inc. / VisionNet Page 64 M505N User Manual Revision 3.2...
  • Page 65 Please Note: If the port to be assigned is already specified in the existing Port Triggering Table, you must remove the rule containing this port prior to creating a new one DQ Technology, Inc. / VisionNet Page 65 M505N User Manual Revision 3.2...
  • Page 66 It may be difficult to determine which ports must be used for a particular application. It is best to specify the LAN device as the DMZ host to see if this resolves the issue. DQ Technology, Inc. / VisionNet Page 66 M505N User Manual Revision 3.2...
  • Page 67 If port triggering does not work, then further research should be done to identify the behavior of the communication between the LAN device and the Server. DQ Technology, Inc. / VisionNet Page 67 M505N User Manual Revision 3.2...

  • Page 68: Dmz Host

    This is the IP Address of the LAN Device which will receive all non-specified traffic. This device should have either a Static IP or Reserved IP Select the “Save/Apply” Button. DQ Technology, Inc. / VisionNet Page 68 M505N User Manual Revision 3.2...

  • Page 69: Upnp

    Then, In the left-hand frameset, select “UPnP” Select “Enable UPnP” You may enable / disable UPnP by toggling the checkbox. Select “Apply Save” DQ Technology, Inc. / VisionNet Page 69 M505N User Manual Revision 3.2...

  • Page 70: Algorithm Enable / Disable

    Section 6.5 – Algorithm Enable / Disable Algorithms Defined The VisionNet gateway can open ports, based on industry standards and conventions, when certain traffic is detected. You must enable or disable these algorithms to adjust operation. These algorithm port conventions are only honored when the Firewall is enabled...

  • Page 71: Wan Access Control (Parental Control)

    Section 6.6 – WAN Access Control (Parental Controls) WAN Access Control The VisionNet Gateway can allow / disallow WAN Access to LAN hosts by a weekly time schedule. MAC Addresses are used to identify devices. Step 1: Direct Your Browser to the WAN Access Control Page Select the “Security”...

  • Page 72: Url Filtering (Parental Control)

    Section 6.7 – URL Filtering (Parental Controls) URL Filtering The VisionNet Gateway can allow / disallow access to certain URLs. Step 1: Direct Your Browser to the WAN Access Control Page Select the “Security” tab located within the left-hand frameset.

  • Page 73: Ip Filtering

    Then, In the left-hand frameset, select either: Inbound IP Filtering Outbound IP Filtering Define IP Filtering Define at least one condition for identification of traffic Select “Apply Save” DQ Technology, Inc. / VisionNet Page 73 M505N User Manual Revision 3.2...

  • Page 74: Bridge Access Control

    Bridge Access Control Forwarded: Everything forwarded except defined traffic Blocking: Everything Blocked except defined traffic Define Restrictions Define at least one condition for identification of traffic Select “Apply Save” DQ Technology, Inc. / VisionNet Page 74 M505N User Manual Revision 3.2...

  • Page 75: Section 7: Quality Of Service

    You may Enable QoS Unless specified otherwise, do not change the Default DSCP Mark This will enable QoS rules within the device Select “Save / Apply” DQ Technology, Inc. / VisionNet Page 75 M505N User Manual Revision 3.2...

  • Page 76: Qos Interface Configuration

    Enable / Disable Rules You must enable a rule for it to take precedence. You may also create Queue precedence for interfaces within this section Select “Apply Save” DQ Technology, Inc. / VisionNet Page 76 M505N User Manual Revision 3.2...

  • Page 77: Qos Classification

    Then, In the left-hand frameset, select: QoS Classification Create a new QoS Classification You may identify and modify QoS tagging within this table Select “Apply Save” DQ Technology, Inc. / VisionNet Page 77 M505N User Manual Revision 3.2...

  • Page 78: Section 8: Service Grouping

    The Service Group Operates similarly to port mapping of the past. A WAN interface may provide service, to particular Interfaces, independent of other services. The key difference between Service Grouping, and Port Mapping of the past, is that the VisionNet device supports multiple NAT Sessions, DHCP Servers, and Network Conventions between Service Grouping.

  • Page 79: Service Group Creation

    WAN services. These will operate independently of the primary gateway operation. You may also group clients by DHCP Vendor IDs (Boot P Classification) Select “Apply Save” DQ Technology, Inc. / VisionNet Page 79 M505N User Manual Revision 3.2...

  • Page 80: Service Group Lan Management

    Then, In the left-hand frameset, select: LAN IP Management Select the appropriate GroupName You may configure the Service Group LAN Settings independent of the Primary Service Group Select “Apply Save” DQ Technology, Inc. / VisionNet Page 80 M505N User Manual Revision 3.2...

  • Page 81: Section 9: Configuration Settings

    SECTION 9: CONFIGURATION SETTINGS Section 9.0 – Configuration File Logic Device Reset Behavior DQ Technology, Inc. / VisionNet Page 81 M505N User Manual Revision 3.2...

  • Page 82: Save Backup Configuration

    Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “Settings” Select “Backup Settings” and choose your download location via your browser’s download tool. DQ Technology, Inc. / VisionNet Page 82 M505N User Manual Revision 3.2...

  • Page 83: Over-Writing The Default Configuration

    ONLY UPDATE THE DEFAULT CONFIGURATION WITH APPROVAL FROM A SUPPORT MANAGER. The VisionNet modem comes with a pre-configured default configuration. In the event that you would like to access the original configuration, please ask the customer to hold the reset button for 5 seconds.

  • Page 84: Update The Running Configuration

    Then, In the left-hand frameset, select “Settings” Select “Browse” button and choose your file location via your browser’s upload tool. Select the “Update Settings” button DQ Technology, Inc. / VisionNet Page 84 M505N User Manual Revision 3.2...

  • Page 85: Restoring The Default Settings

    It is possible that the modem will obtain a new IP Address upon reboot. Restoring the Default Settings via the Reset Button DQ Technology, Inc. / VisionNet Page 85 M505N User Manual Revision 3.2...
  • Page 86 Press the Reset Button and hold down for 5 seconds Wait for the modem to reboot DQ Technology, Inc. / VisionNet Page 86 M505N User Manual Revision 3.2...

  • Page 87: Updating The Modem Firmware

    Select the “Browse” button and select the firmware file on your PC Once you have specified the firmware, select the “Update Software” button. The modem will reset itself. DQ Technology, Inc. / VisionNet Page 87 M505N User Manual Revision 3.2...

  • Page 88: Rebooting The Modem

    “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “Warm Reboot” Select the “Reboot” button. The modem will reset itself with the running configuration DQ Technology, Inc. / VisionNet Page 88 M505N User Manual Revision 3.2...
  • Page 89 Step 1: Access the GUI and find the SNMP Configuration Page Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “SNMP” Enter the appropriate information, and the select “Save/Apply” DQ Technology, Inc. / VisionNet Page 89 M505N User Manual Revision 3.2...

  • Page 90: Acs Configuration

    Step 1: Access the GUI and find the ACS Configuration Page Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “ACS Client” Enter the appropriate information, and the select “Save/Apply” DQ Technology, Inc. / VisionNet Page 90 M505N User Manual Revision 3.2...

  • Page 91: Ntp Configuration

    Step 1: Access the GUI and find the SNMP Configuration Page Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “NTP” Enter the appropriate information, and the select “Save/Apply” DQ Technology, Inc. / VisionNet Page 91 M505N User Manual Revision 3.2...

  • Page 92: Ip Restriction (Management Acls)

    IPs BEFORE YOU ENABLE THE ACL. IF YOU ENABLE THE ACL WITHOUT THIS TABLE BUILT, YOU WILL NEED TO DEFAULT THE UNIT Enter the appropriate information, and the select “Save/Apply” DQ Technology, Inc. / VisionNet Page 92 M505N User Manual Revision 3.2...

  • Page 93: Remote Access

    Section 9.11 – Remote Access The VisionNet modems come pre-configured to allow remote management access. Step 1: Access the GUI to find the Remote Access Tool Select the “Management” tab located within the left-hand frameset. Then, In the left-hand frameset, select “Access Control”...

  • Page 94: Section 10: Wi Fi

    1, 6, and 11 tend to operate the best. Other Channels to consider are 3 and 9. Once you have selected the new channel, select “Save/Apply” at the bottom of the screen. Select the “Save/Apply” Button. DQ Technology, Inc. / VisionNet Page 94 M505N User Manual Revision 3.2...

  • Page 95: Ssid Configuration

    United States is the support module Limits the amount of devices that can Max Clients connect 1.C Guest / Virtual SSIDs Select the “Save/Apply” Button. Section 10.3 – WIRELESS ENCRYPTION DQ Technology, Inc. / VisionNet Page 95 M505N User Manual Revision 3.2...

  • Page 96: Wireless Configuration

    Group Rekey interval AES is preferable WPA Encryption Some devices may require TKIP+AES Select the “Click Here to Display” Button; and verify your encryption key. Select the “Save/Apply” Button. DQ Technology, Inc. / VisionNet Page 96 M505N User Manual Revision 3.2...

  • Page 97: Global Settings

    Section 10.4– GLOBAL SETTINGS When to change the GLOBAL SETTINGS Some devices offer very specific support for Wireless. Listed below are the items that may be changed; along with VisionNet suggested settings Step 1: Direct Your Browser to the Global Settings Page Select the “Wireless”...
  • Page 98 Disabled – some devices may Acknowledgement not support this This is a WMM Power save that WMM APSD replaces the RX Chain power save options Select the “Save/Apply” Button. DQ Technology, Inc. / VisionNet Page 98 M505N User Manual Revision 3.2...

  • Page 99: Mac Filtering

    Disabled: Means that the MAC Filtering table is not applied Select the appropriate SSID, and then select Add You may now add a MAC Address to be filtered DQ Technology, Inc. / VisionNet Page 99 M505N User Manual Revision 3.2...

  • Page 100: Wireless Bridge

    Disabled if you are using Bridging; If Bridge Restrict enabled other APs will not be allowed to connect Remote The MAC Addresses of the allowed Bridges Bridges Select “Apply / Save” DQ Technology, Inc. / VisionNet Page 100 M505N User Manual Revision 3.2...

  • Page 101: Section 11: Product Depictions And Behavior

    SECTION 11: PRODUCT DEPICTIONS AND BEHAVIOR Section 11.1 - Product Depictions M505N LED VIEW M505N REAR VIEW DQ Technology, Inc. / VisionNet Page 101 M505N User Manual Revision 3.2...

  • Page 102: Led Behavior

    Flashing Green – Device has WAN IP Address and IP Traffic is passing through device Red – Device attempted initiate session, either authentication or to obtain an IP Address, and failed. DQ Technology, Inc. / VisionNet Page 102 M505N User Manual Revision 3.2...

  • Page 103: Port Mirroring

    Select the Ethernet Port for Mirroring Please note that number begins with “O”. Hence Eth0 = Port 1 Eth1 = Port 2 Eth2 = Port 3 Select “Apply / Save” . DQ Technology, Inc. / VisionNet Page 103 M505N User Manual Revision 3.2...
