VisionNet M505 End User Manual

Adsl2+ ethernet broadband gateway 802.11b/g/n 4 port ethernet usb 2.0

Advertisement

Quick Links

M505N
ADSL2+ Ethernet Broadband Gateway
802.11b/g/n 4 Port Ethernet USB 2.0
End User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M505 and is the answer not in the manual?

Questions and answers

Summary of Contents for VisionNet M505

  • Page 1 M505N ADSL2+ Ethernet Broadband Gateway 802.11b/g/n 4 Port Ethernet USB 2.0 End User Manual...
  • Page 2: Table Of Contents

    Manual Ver1.0 Table of Contents INTRODUCTION ..................................4 ................................... 4 EATURES ..............................4 YSTEM EQUIREMENTS INSTALLATION ..................................5 ....................................5 RONT ANEL ...................................... 6 ANEL ................................6 ONNECTING THE ARDWARE Step 1. Connect the ADSL cable and optional telephone......................6 Step 2.
  • Page 3 Manual Ver1.0 DNS ................................. 19 YNAMIC USB STORAGE (DLNA) ................................20 IPSEC ......................................21 10. WIRELESS ....................................24 10.1 SSID ....................................27 10.2 ................................27 ECURITY ETTINGS 10.3 WPS....................................32 10.4 MAC F ................................32 ILTERING 10.5 ................................. 33 RIDGING 10.6 ................................
  • Page 4: Introduction

    Manual Ver1.0 1. Introduction Congratulations on becoming the owner of the VisionNet M505N 802.11N ADSL2+ Broadband Gateway. You will now be able to access the Internet using your high-speed ADSL/2+ connection. The Master series of ADSL2+ modems has the following major features.
  • Page 5: Installation

    Manual Ver1.0 2. Installation In addition to this document, your M505N should arrive with the following: • One power adapter One Ethernet cable with RJ-45 connector • One Telephone cable with RJ-11 connector • Product Installation CD • • Installation Guide Front Panel The Front panel LED light indicates the status of the unit.
  • Page 6: Rear Panel

    Manual Ver1.0 Flashing Green – Attempting WPS association Green – USB storage connected DLNA Green - No device detected Rear Panel The connectors located at the rear panel have the following functions. M505N Interface Function Switch(Push Button) Power switch on/off Power Connects to the power adapter cable Reset Button...
  • Page 7: Step 3. Attach The Power Connector

    Manual Ver1.0 connect the other end to your PCs network adaptor (NIC). If you are connecting a LAN to the Master series, attach one end of the Ethernet cable to a regular hub port and the other end to the LAN port on the M505N.
  • Page 8: Configuration

    Manual Ver1.0 3. Configuration 3.1 - Setup Connect your M505N and PC with an RJ-45 Ethernet cable. Turn on the M505N. The default IP address of M505N is 192.168.1.254. 3.2 - Establish the Connection Enter the IP address (default: 192.168.1.254) of M505N in the address line of your web browser.
  • Page 9: Quick View

    Manual Ver1.0 4. Quick View Quick View allows you to view all the major statistics and information of your VisionNet M505N Gateway from one easy location on the WEB interface. The following information is provided: 1. Device Info – Information such as Software revision and Driver version 2.
  • Page 10: Lan

    Manual Ver1.0 5. LAN The LAN (Local Area Network) section allows the following settings to be configured on the VisionNet M505N Gateway: LAN Setup IPv6 LAN Settings 5.1 - LAN Input the IP Address and Subnet Mask of your M505N.
  • Page 11 Manual Ver1.0 5.1.2 – Static IP Leasing This function allows you to reserve an IP Address for clients connected to the gateway via the client’s MAC address. Click the “Add new entries” Form, enter the MAC address of the client you wish to reserve an IP address to.
  • Page 12: Security

    Manual Ver1.0 6. Security The Security section allows the following setting to be configured on the VisionNet M505N Gateway: IP Filtering Rules URL Filtering Port Forwarding Port Triggering DMZ Host WAN Access Control 6.1 – IP Filtering Rules Two functions are supported in the IP Filter function of the M505N Gateway: Outgoing IP Filtering and Incoming Filtering.
  • Page 13 Manual Ver1.0 The screen allows you to create a filter rule to identify incoming IP traffic by specifying a filter name and at least one of the conditions below. All of the specified conditions in this filter rule must be satisfied for the rule to take effect. Click “Save/Apply” to save and activate the filter.
  • Page 14: Url Filtering

    Manual Ver1.0 activate the filter. 6.2 – URL Filtering Rules The M505N Gateway allow user to block or allow access to specific URL for clients connected. Setup the URL filters by: Choose “Create New Rule” to add URL (Web Address) - 14 -...
  • Page 15: Port Forwarding

    Manual Ver1.0 6.3 – Port Forwarding Port Forwarding allows you to direct incoming traffic from WAN side (identified by Protocol and External port) to the internal server with private IP address on the LAN side. The Internal port is required only if the external port needs to be converted to a different port number used by the server on the LAN side.
  • Page 16: Port Triggering

    Manual Ver1.0 To delete the configured rule(s), check the “Remove” box of the specific rule(s) and click on “Remove”. 6.4 – Port Triggering Some applications require that specific ports in the Router's firewall be opened for access by the remote parties. Port Trigger dynamically opens up the “Open Ports” in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the “Triggering Ports”.
  • Page 17: Dmz Host

    Manual Ver1.0 Click on “Create New Rule” to enter the configuration page to add your own rule(s). You can configure the port settings from this screen by selecting an existing application or creating your own (Custom application) and click “Save/Apply” to add it. To delete the configured rule(s), check the “Remove”...
  • Page 18: Wan Access Control

    Manual Ver1.0 6.6 – WAN Access Control WAN Access Control allows users to create time of day restrictions to a specific LAN device connected to the Router. Click “Create New Rule” to configure restriction rules. To remove, check the item and click “Remove”. - 18 -...
  • Page 19: Dns

    Manual Ver1.0 To create a new WAN Access Control Rule: 1. Give the rule a name that can be easily be identified 2. The “Browser’s MAC Address” will show the MAC address of the client currently connected to the gateway WEB Interface. Either select this option if you want the rules to apply to the PC in use or check the Other MAC address radio box and enter the MAC address of the client you wish for the rules to apply to 3.
  • Page 20: Usb Storage (Dlna)

    Manual Ver1.0 Select your Dynamic DNS service provider from ‘D-DNS provider’, and enter your registration information. Click “Submit Dynamic DNS Service” to save the configuration. 8. Network Access Storage (DLNA) The M505N have the ability to share content of an USB storage device to Windows based PC’s connected on the LAN.
  • Page 21: Ipsec

    Manual Ver1.0 9. IPSEC The M505N also have the ability to create a VPN (Virtual Private Network) tunnel using IPSec as the security measure. VPN allows user to remotely connect to a network using their Broadband connection. Click on the “Create New Tunnel” to create new IPSEC connection - 21 -...
  • Page 22 Manual Ver1.0 Enter the following critical information in the VPN Tunnel Settings: 1. Enter a name for this IPSec connection. 2. Enter the Public IP address of the remote gateway in the next field. 3. Select “Subnet” for Tunnel access from local IP addresses. 4.
  • Page 23 Manual Ver1.0 - 23 -...
  • Page 24: Wireless

    Manual Ver1.0 Wireless Some basic understanding of 802.11b/g/n wireless technology and terminology is useful when you are setting up the Router or any wireless access point. If you are not familiar with wireless networks please take a few minutes to learn the basics. Wireless client requirements All wireless client adapters compliant to 802.11n, 802.11g and/or 802.11b can communicate with the M505N Wireless LAN environment.
  • Page 25 Manual Ver1.0 Wireless Range Range should not be a problem in most homes or small offices. If you experience low or no signal strength in some areas, consider positioning the Router in a location between the WLAN devices that maintains a roughly equal straight-line distance to all devices that need to access the Router through the wireless interface.
  • Page 26 Manual Ver1.0 Regulatory Domain Allowed Radio Channels China 1 to 13 Europe 1 to 13 Israel 5 to 8 Japan 1 to 14 Jordan 10 to 13 Thailand 1 to 14 USA / Canada 1 to 11 Wireless Security Various security options are available on the M505N including open or WEP, 802.1x, WPA, WPA-PSK, WPA2 and WPA2-PSK.
  • Page 27: Ssid

    Manual Ver1.0 10.1 - SSID This page allows you to configure basic features of the wireless LAN interface. You can enable or disable the wireless LAN interface, hide the network from active scans (no broadcasting of your network name), set the wireless network name (also know as SSID), and restrict the channels based on nation’s requirements.
  • Page 28 Manual Ver1.0 26 hexadecimal digits for 128-bit encryption keys. Enter 5 ASCII characters or 10 hexadecimal digits for 64-bit encryption keys. Select which key (1 ~ 4) to use from “Current Network Key”. Click “Save/Apply” to save the configuration. 802.1X 802.1X addresses the WEP weakness by adding user authentication, via RADIUS server.
  • Page 29 Manual Ver1.0 WPA/WPA2 WPA (Wi-Fi Protected Access) is the strongest wireless security provided by the M505N. Like 802.1X, WPA must co-work with RADIUS server as well. To enable WPA, select the following items step by step: Network Authentication: WPA/WPA2 WPA Group Rekey Interval: in seconds. Default: 0 (no re-keying). RADIUS Server IP Address/Port/Key: must match your RADIUS server.
  • Page 30 Manual Ver1.0 WPA/WPA2-PSK WPA-PSK lets you take advantage of WPA without the hassle of setting up your own RADIUS server. To enable WPA-PSK, select “WPA-PSK” in “Network Authentication”. Enter 8 to 63 ASCII codes or 64 hexadecimal (0~9, A~F) digits in “WPA Pre-Shared Key”. Click “Save/Apply”...
  • Page 31 Manual Ver1.0 - 31 -...
  • Page 32: Wps

    Manual Ver1.0 10.3 – WPS (Wireless Security Settings) This page is used to configure the settings for WPS (Wi-Fi Protected Setup). It uses a push-button or a 4- or 8-digit personal identification number (PIN) to simplify the secure network setup. With WPS, M505N can automatically set the SSID or network name as part of the setup process and provide strong encryption keys to client devices.
  • Page 33: W I F I Bridging

    Manual Ver1.0 10.5 – Wireless Bridging Wireless Bridge (also known as Wireless Distribution System) can bridge data between two APs, which is particularly useful while wired cabling is not available. Note: only APs in same channel can be bridged. AP Mode: Wireless Bridge- listens and answers other APs only Access Point- Wireless Bridge also with AP functionality Bridge Restrict: Disabled- any AP will be granted access Enabled- only selected APs (Max.
  • Page 34: Global Settings

    Manual Ver1.0 10.6 – Global Settings System In most cases, M505N work well with wireless default settings. Modification is not recommended unless you are very familiar with these parameters. Channel: Select the appropriate channel from the provided list to correspond with your network settings.
  • Page 35 Manual Ver1.0 - 35 -...
  • Page 36: System Diagnostic

    Manual Ver1.0 11. System Diagnostic The System Diagnostic section allows the tools for troubleshooting purpose System Diagnostic Inbound Toolkit Outbound Toolkit 11.1 – System Diagnostic The System Diagnostic function will run a test for Physical Port connectivity, DSL status, and Internet WAN connection status. The test takes a few second to complete.
  • Page 37: Inbound Toolkit

    Manual Ver1.0 11.2 – Inbound Toolkit This function allows you to ping device locally in your network. Type in the URL or IP address of the device you would like to ping. If there is a Ping reply, that verify that the connection is up and not block.
  • Page 38: Gateway Statistics

    Manual Ver1.0 12. Gateway Statistics The Gateway Statistics section allows viewing of the following category statistics: xDSL Host Wireless Clients Route Table DHCP 12.1 – xDSL This will display all DSL statistics of the modem. 12.2 – ATM This will display ATM statistics of the current active WAN connection: - 38 -...
  • Page 39: Wan

    Manual Ver1.0 12.3 – WAN Statistics The WAN Statistics page is broken into 2 parts: 1. WAN Overview – Information concerning the WAN protocol currently in used by the M505N to connect to the Internet. In the figure below: The modem is currently in IPoE mode, IGMP option is disabled, PVC 0/35, the connection is Up and the WAN IP address that the modem receives from the Internet Service Provider Equipment.
  • Page 40: Lan

    Manual Ver1.0 12.4 – LAN This will display all LAN statistics of the M505N: 12.5 – Host This will display all Host/ARP statistics of the M505N: 12.6 – Wireless Clients This will display all devices that it currently connected to the M505N via the Wireless connection.
  • Page 41: Route

    Manual Ver1.0 12.7 – Route table This will display all current Route table of the M505N: 12.8 – DHCP This will display all DHCP Clients connected to the M505N - 41 -...
  • Page 42: Management

    Manual Ver1.0 13. Management 13.1 – Settings This page allows backup the current configuration, restore the modems from a configuration file or restore the modem to its default configuration. If you wish to erase the running the configuration from the gateway and revert back to the modem default settings: click on the “Restore Default Settings”.
  • Page 43 Manual Ver1.0 Select the Check box “Automatically synchronize with Internet time server” box. Choose the NTP Server from the dropdown list Finally, select the Timezone from the dropdown list. Click the “Apply/Save” button for apply this function. - 43 -...
  • Page 44: Management Accounts

    Manual Ver1.0 13.3 – Management Account This page allows you to modify the log-in password to the management interface of the gateway. 13.4 – Warm Reboot Click “Warm Reboot” button to reboot M505N. - 44 -...
  • Page 45: Appendix A - Specifications

    Manual Ver1.0 14. Appendix A – Specifications A1. Hardware Specifications Local Interface Four 10/100BaseT Ethernet port (IEEE 802.3, RJ-45 connector) • Two Removable External Wireless Antenna (Supports B/G/N mode) • USB 2.0 Type A Interface • WAN ADSL Line Interface Complies with G.dmt (G.992.1) Annex A •...
  • Page 46 Manual Ver1.0 • RFC2684 (RFC1483) Routed • DNS relay • UPnP • IGMP-Proxy Configuration and Network Management • DHCP server for IP management • HTTP (Web Server) for configuration and firmware upgrade • TFTP Server • FTP Server Firewall • NAT ALG •...
  • Page 47: Appendix B - Warranties

    Manual Ver1.0 15. Appendix B – Warranties DQ Technology adheres to the strictest Quality Assurance processes to ensure that our products are free from defects prior to shipping. DQ Technology provides a standard 1 year limited warranty for all products and provides an extended warranty option for North American customers.
  • Page 48: Appendix C - Regulations

    Manual Ver1.0 Appendix C – Regulations C1. FCC Part 68 Statement This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the back of this equipment is a label that contains, among other information, a product identifier in the format US: DQ1DL01BM505N.
  • Page 49 Manual Ver1.0 C2. FCC Part 15 Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 50: Contact Information

    Manual Ver1.0 Contact Information You can help us to serve you better by sending us your comments and feedback. Listed below are the addresses, and telephone and fax numbers of our offices. You can also visit us on the World Wide Web at www.dqusa.com for more information.
