VisionNet M504 End User Manual
Adsl2+ ethernet broadband gateway
4 port ethernet usb 2.0
Hide thumbs
Also See for M504:
- Quick start manual (3 pages) ,
- Product manual (62 pages) ,
- Manual (9 pages)
Table of Contents
Related Manuals for VisionNet M504
Summary of Contents for VisionNet M504
- Page 1 M504 ADSL2+ Ethernet Broadband Gateway 4 Port Ethernet USB 2.0 End User Manual...
-
Page 2: Table Of Contents
Step 2. Connect the Ethernet cable ...............................6 Step 3. Attach the power connector ...............................7 Step 4. Turn on the M504 and power up your systems ........................7 Step 5. Configure the M504 through the WEB interface........................7 Step 6. Save the configurations and Reboot ..........................7 CONFIGURATION ..................................8... - Page 3 Manual Ver1.0 DNS .................................. 20 YNAMIC USB STORAGE (DLNA) ................................21 ..................................22 IPSEC 10. SYSTEM DIAGNOSTIC ................................24 10.1 ............................... 24 YSTEM IAGNOSTICS 10.2 ................................25 NBOUND OOLKIT 10.3 ................................25 OUTBOUND OOLKIT 11. GATEWAY STATISTICS ................................26 11.1 xDSL ....................................
-
Page 4: Introduction
TR-069 compliant for automatic modem update through your high speed Internet access This End User Manual will guide you through the installation and configuration of your M504 modem. System Requirements Before installing your M504 modem, make sure that you have the following: ... -
Page 5: Installation
Manual Ver1.0 2. Installation In addition to this document, your M504 should arrive with the following: One power adapter One Ethernet cable with RJ-45 connector One Telephone cable with RJ-11 connector Product Installation CD Installation Guide Front Panel The Front panel LED light indicates the status of the unit. -
Page 6: Rear Panel
Step 1. Connect the ADSL cable and optional telephone Connect one end of the phone cable to the RJ-11 connector on the rear panel of the M504. Connect the other end to the ADSL outlet provided by your service provider (normally MODEM port of the included splitter). -
Page 7: Step 4. Turn On The M504 And Power Up Your Systems
Step 5. Configure the M504 through the WEB interface Please refer to Chapter 3. Step 6. Save the configurations and Reboot Save the changes you made on the M504 and it will automatically reboot to make the settings permanent. - 7 -... -
Page 8: Configuration
The default IP address of M504 is 192.168.1.254. 3.2 - Establish the Connection Enter the IP address (default: 192.168.1.254) of M504 in the address line of your web browser. A Dialogue Box will pop up to request the user to login. (Figure 1) Figure 1. -
Page 9: Quick View
Manual Ver1.0 4. Quick View Quick View allows you to view all the major statistics and information of your VisionNet M504 Gateway from one easy location on the WEB interface. The following information is provided: 1. Device Info – Information such as Software revision and Driver version 2. -
Page 10: Lan
IPv6 LAN Settings 5.1 - LAN Input the IP Address and Subnet Mask of your M504. (Default: 192.168.1..254) Check the box if you want to enable IGMP Snooping. Disable/Enable DHCP Server, and change the starting and ending IP address of your server pool if needed. - Page 11 Manual Ver1.0 5.1.2 – Static IP Leasing This function allows you to reserve an IP Address for clients connected to the gateway via the client’s MAC address. Click the “Add new entries” Form, enter the MAC address of the client you wish to reserve an IP address to.
-
Page 12: Security
WAN Access Control 6.1 – IP Filtering Rules Two functions are supported in the IP Filter function of the M504 Gateway: Outgoing IP Filtering and Incoming Filtering. Incoming IP Filtering When the firewall option is enabled on a WAN or LAN interface, all incoming IP traffic from the WAN is BLOCKED. - Page 13 Manual Ver1.0 The screen allows you to create a filter rule to identify incoming IP traffic by specifying a filter name and at least one of the conditions below. All of the specified conditions in this filter rule must be satisfied for the rule to take effect. Click “Save/Apply” to save and activate the filter.
-
Page 14: Url Filtering
Manual Ver1.0 activate the filter. 6.2 – URL Filtering Rules The M504 Gateway allow user to block or allow access to specific URL for clients connected. Setup the URL filters by: Choose “Create New Rule” to add URL (Web Address) -
Page 15: Port Forwarding
Click on “Create New Rule” to enter configuration page to add your own rule(s). Some common used servers (Web, FTP, Mail, etc.) are already pre-defined for the M504. User can simply select the desired pre-defined application from the pull-down menu and assign the IP address of the local PC for the ports to be forwarded to. -
Page 16: Port Triggering
Manual Ver1.0 To delete the configured rule(s), check the “Remove” box of the specific rule(s) and click on “Remove”. 6.4 – Port Triggering Some applications require that specific ports in the Router's firewall be opened for access by the remote parties. Port Trigger dynamically opens up the “Open Ports” in the firewall when an application on the LAN initiates a TCP/UDP connection to a remote party using the “Triggering Ports”. -
Page 17: Dmz Host
Manual Ver1.0 Click on “Create New Rule” to enter the configuration page to add your own rule(s). You can configure the port settings from this screen by selecting an existing application or creating your own (Custom application) and click “Save/Apply” to add it. To delete the configured rule(s), check the “Remove”... -
Page 18: Wan Access Control
Manual Ver1.0 6.6 – WAN Access Control WAN Access Control allows users to create time of day restrictions to a specific LAN device connected to the Router. Click “Create New Rule” to configure restriction rules. To remove, check the item and click “Remove”. - 18 -... - Page 19 Manual Ver1.0 To create a new WAN Access Control Rule: 1. Give the rule a name that can be easily be identified 2. The “Browser’s MAC Address” will show the MAC address of the client currently connected to the gateway WEB Interface. Either select this option if you want the rules to apply to the PC in use or check the Other MAC address radio box and enter the MAC address of the client you wish for the rules to apply to 3.
-
Page 20: Dns
– Dynamic DNS The Dynamic DNS service allows you to give a dynamic IP address a static hostname in any of the domains. This function allows your M504 to be more easily accessible from various locations on the Internet. Choose “Create New Client Service” to configure Dynamic DNS. -
Page 21: Usb Storage (Dlna)
Manual Ver1.0 8. Network Access Storage (DLNA) The M504 have the ability to share content of an USB storage device to Windows based PC’s connected on the LAN. To utilize this function: connect a USB storage device (External Hard drive, USB Thumb Drive, etc.) to the USB port of the M504 gateway. -
Page 22: Ipsec
Manual Ver1.0 9. IPSEC The M504 also have the ability to create a VPN (Virtual Private Network) tunnel using IPSec as the security measure. VPN allows user to remotely connect to a network using their Broadband connection. Click on the “Create New Tunnel” to create new IPSEC... - Page 23 Manual Ver1.0 15. Configure the remote IPSec gateway in the same manner. However, the local ip parameters will be remote ip parameters. 16. Once established, you can connect to clients in the remote network using their local IPs. - 23 -...
-
Page 24: System Diagnostic
Manual Ver1.0 10. System Diagnostic The System Diagnostic section allows the tools for troubleshooting purpose System Diagnostic Inbound Toolkit Outbound Toolkit 10.1 – System Diagnostic The System Diagnostic function will run a test for Physical Port connectivity, DSL status, and Internet WAN connection status. -
Page 25: Inbound Toolkit
Manual Ver1.0 10.2 – Inbound Toolkit This function allows you to ping device locally in your network. Type in the URL or IP address of the device you would like to ping. If there is a Ping reply, that verify that the connection is up and not block. -
Page 26: Gateway Statistics
Manual Ver1.0 11. Gateway Statistics The Gateway Statistics section allows viewing of the following category statistics: xDSL Host Route Table DHCP 11.1 – xDSL This will display all DSL statistics of the modem. 11.2 –... -
Page 27: Wan
1. WAN Overview – Information concerning the WAN protocol currently in used by the M504 to connect to the Internet. In the figure below: The modem is currently in IPoE mode, IGMP option is disabled, PVC 0/35, the connection is Up and the WAN IP address that the modem receives from the Internet Service Provider Equipment. -
Page 28: Lan
11.4 – LAN This will display all LAN statistics of the M504: 11.5 – Host This will display all Host/ARP statistics of the M504: 11.6 – Route table This will display all current Route table of the M504: - 28 -... -
Page 29: Dhcp
Manual Ver1.0 11.7 – DHCP This will display all DHCP Clients connected to the M504 - 29 -... -
Page 30: Management
Manual Ver1.0 12. Management 12.1 – Settings This page allows backup the current configuration, restore the modems from a configuration file or restore the modem to its default configuration. If you wish to erase the running the configuration from the gateway and revert back to the modem default settings: click on the “Restore Default Settings”. - Page 31 Manual Ver1.0 Select the Check box “Automatically synchronize with Internet time server” box. Choose the NTP Server from the dropdown list Finally, select the Timezone from the dropdown list. Click the “Apply/Save” button for apply this function. - 31 -...
-
Page 32: Management Accounts
Manual Ver1.0 12.3 – Management Account This page allows you to modify the log-in password to the management interface of the gateway. 12.4 – Warm Reboot Click “Warm Reboot” button to reboot M504. - 32 -... -
Page 33: Appendix A - Specifications
Manual Ver1.0 13. Appendix A – Specifications A1. Hardware Specifications Local Interface Four 10/100BaseT Ethernet port (IEEE 802.3, RJ-45 connector) USB 2.0 Type A Interface WAN ADSL Line Interface Complies with G.dmt (G.992.1) Annex A ... - Page 34 Manual Ver1.0 DNS relay UPnP IGMP-Proxy Configuration and Network Management DHCP server for IP management HTTP (Web Server) for configuration and firmware upgrade TFTP Server FTP Server Firewall NAT ALG ...
-
Page 35: Appendix B - Warranties
Manual Ver1.0 14. Appendix B – Warranties DQ Technology adheres to the strictest Quality Assurance processes to ensure that our products are free from defects prior to shipping. DQ Technology provides a standard 1 year limited warranty for all products and provides an extended warranty option for North American customers. -
Page 36: Appendix C - Regulations
Manual Ver1.0 15. Appendix C – Regulations C1. FCC Part 68 Statement This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On the back of this equipment is a label that contains, among other information, a product identifier in the format US: DQ1DL01BM504. - Page 37 Manual Ver1.0 C2. FCC Part 15 Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 38: Contact Information
Manual Ver1.0 Contact Information You can help us to serve you better by sending us your comments and feedback. Listed below are the addresses, and telephone and fax numbers of our offices. You can also visit us on the World Wide Web at www.dqusa.com for more information.
