2.3.5 To mount the antenna fixed on the vehicle roof
The antenna may be fixed on the roof of your car, using three M5 bolts and mounting plates.
This solution requires that you drill three holes in the roof of the car and remove the magnets
from the antenna.
To mount the antenna, do as follows:
1. Unscrew the 3 magnets from underneath the antenna and remove them.
2. Use mounting plates that, as a minimum, cover the 4 raised areas around each of the 3
mounting bushings. See the drawing below,
Example:
Important
98-131306-B
You can use 3 mounting plates with a shape and size similar to the magnets
provided with the antenna, i.e. approximately ø90 mm x 10 mm.
Do not mount the antenna without mounting plates!
To install the antenna
Chapter 2: To install the system
8
