Condensation
In some cases there will be condensation inside the antenna. Ventilation holes in the bottom
of the EXPLORER 325 antenna are designed to lead any water away from the antenna.
Make sure these ventilation hole are not blocked.
Important
See To mount the antenna fixed on the vehicle roof on page 8.
2.3.3 To mount the antenna
The antenna can now be installed on the roof of the vehicle. You may choose between these
methods:
• Attach the antenna using the magnets underneath the antenna. The magnetic force will
keep the antenna fixed to the vehicle roof. Note that this method requires a vehicle roof
made of magnetizable material.
• Mount the antenna directly on the roof of the vehicle. This method requires that you drill
holes in the roof of the car. Remember to leave min. 10 mm space between the antenna
and the roof.
Refer to the Safety summary on page iii.
98-131306-B
Make sure there is always a distance of min. 10 mm
between any part of the antenna bottom and the
mounting surface. If the magnets are not used, use 10
mm spacers (or higher if necessary) at each bolt.
To install the antenna
Chapter 2: To install the system
6
