Lippe Lift LL12 Operation Manual

Platform lifts for the transport of wheelchair users

Advertisement

Quick Links

Operation of the LL12 stair lift
Contents
1
General...............................................................................................................
1.1
Technical data.....................................................................................................
1.2
Ambient conditions.............................................................................................
1.3
Testing obligations..............................................................................................
2.
Use as intended................................................................................................... 5
2.1
Transport profiles................................................................................................
2.2
Inappropriate use.................................................................................................
2.3
Operator qualification.........................................................................................
2.4
Product description..............................................................................................
2.5
General overview of the platform lift..................................................................
3
Safety................................................................................................................... 8
4
Operation............................................................................................................
4.1
Main switch.......................................................................................................... 10
4.2
Deep discharge protection and charging..............................................................
4.3
Checking the loading / overload protection...................................................
4.4
Battery charger.....................................................................................................
4.5
Fetching and sending the platform lift.................................................................
4.5.1 Folding procedure..............................................................................................
4.6
Travelling with the platform lift..........................................................................
4.7
What to do in the event of an unexpected standstill............................................
4.7.1 Hand wheel operation....................................................................................
4.7.2 Evacuation ..................................................................................................... 15
5
Options / Extras.................................................................................................. 16
5.1
Lateral drive-on ramp........................................................................................... 16
5.2
Folding seat...................................................................................................... 16
6
In the event of a malfunction............................................................................. 17
7
Acoustic warning signals.................................................................................... 17
8
Services performed on your platform lift at a glance...................................... 18
Please read the operating manual before using the lift.
Also make sure that each user of the lift has read and understood the operating manual.
No rights whatsoever can be derived from this operating manual.
Operating manual LL12
This is a translation of the original German operating instructions
! Important !
1/18
Version 1.6
(01/2017)
Page
3
5
5
5
6
6
6
6
7
10
10
10
10
11
12
13
13
13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LL12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lippe Lift LL12

  • Page 1: Table Of Contents

    This is a translation of the original German operating instructions Operation of the LL12 stair lift Contents Page General....................... Technical data..................... Ambient conditions..................... Testing obligations....................Use as intended....................5 Transport profiles....................Inappropriate use....................Operator qualification..................Product description....................General overview of the platform lift..............
  • Page 2  The following notified body: TÜV AUSTRIA SERVICES GMBH (IDF no.: 0408) was employed for: EU type testing, test report no..: TÜV-A/MHF/MG 13-05307 Responsible for the documentation: Lippe Lift- und Anlagenbau GmbH (Documentation Dept.) Weststrasse 48, D-32657 Lemgo Lemgo, 03/09/2009 _______________________ F.-W.
  • Page 3: General

    The rating plate provides the most important information about the platform lift. Type of machine Type designation Year of manufacture Serial number Load-carrying capacity of the platform Dead weight of the platform Manufacturer Field for details of the importer/dealer Operating manual LL12 3/18 Version 1.6 (01/2017)
  • Page 4 The LL12 platform lift is equipped with many sensitive surfaces. Here is an overview: RED = integrated in the safety circuit (further travel is not possible if activated) GREEN = direction-related power-off (the lift can travel in the opposite direction) If one of the direction-related switching surfaces (item 2 / green) is activated, the platform stops moving and an acoustic warning signal is activated.
  • Page 5: Technical Data

    Interior area Testing obligations Whether or not the LL12 platform lift is subject to an obligatory test depends on the respective national regulations and is the user’s responsibility. These regulations must be checked and adhered to. In Germany, a test is obligatory for systems with a lifting height of ≥ 3 m.
  • Page 6: Transport Profiles

    In the case of longer distances covered, the number of start-ups should be reduced accordingly (and linearly). The LL12 chair lift may be only operated if danger due to falling objects (such as flower pots) is ruled out.
  • Page 7: General Overview Of The Platform Lift

    Left-hand drive-on ramp Contact base Lateral drive-on ramp (option) Plug seal charging fuse Lamp: main switch ON Lamp: overload – load capacity exceeded Bolted connection – platform hood (4x) Bolted connection – front cladding (4x) Operating manual LL12 7/18 Version 1.6 (01/2017)
  • Page 8: Safety

    (Residual danger: falling from the platform) Stop the drive command immediately if there are obstacles or articles in or on the track or platform or in the driving area. (Residual danger: crushing) Operating manual LL12 8/18 Version 1.6 (01/2017)
  • Page 9 The load-bearing equipment and track must be sufficiently well lit by daylight or electric lighting. The electric lighting must be independent of timer circuits. Minimum 50 lux at the entry and exit points or in accordance with the national employee protection regulations. Operating manual LL12 9/18 Version 1.6 (01/2017)
  • Page 10: Operation

    The batteries do not require any care. All LL12 platform lifts are equipped with an acoustic deep discharge protector. This acoustic signal generator is intended to protect the batteries against deep discharge.
  • Page 11: Fetching And Sending The Platform Lift

    Fetching and sending the platform lift (standard version) Before each journey, make sure that the acoustic warning signal works. The LL12 platform lift can be fetched from or sent to another station from any station. To do this, the key switch must be inserted at the respective station, turned in the appropriate direction and held in this position.
  • Page 12: Folding Procedure

    4.5.1 Folding procedure In the case of the LL12 platform the base folds up and down electrically and the safety barriers raise and lower electrically. This is performed by means of an UP or DOWN command issued from a station (see also paragraph 4.5), or via the internal controller in the case of special version 2.
  • Page 13: Travelling With The Platform Lift

     After driving the platform, insert the key and turn it to position -I-: ! In the case of the LL12 platform, the safety barrier closes electrically when the button is pressed and held in the desired direction of travel. The platform lift begins to move once the barrier has closed.
  • Page 14 UP direction (until the lift has moved approx. 5 cm along the rail), after which the hand wheel can be turned in the DOWN direction. Prop Brake venting lever Operating manual LL12 14/18 Version 1.6 (01/2017)
  • Page 15: Evacuation

     The operator can now be helped out at the uphill side. The platform must be folded up by hand so that the lift does not block the staircase (see 4.5.2). Operating manual LL12 15/18 Version 1.6 (01/2017)
  • Page 16: Options / Extras

    Options / extras Depending upon requirements, the LL12 platform lifts are also equipped with the following extras. Lateral drive-on ramp In some cases (staircases) it is not possible to drive onto the platform over the two standard drive-on ramps due to the space in front of the first step.
  • Page 17: In The Event Of A Malfunction

    Shift centre of gravity closer to the rail overloading or reduce the weight Note: The acoustic warning signal can be suppressed by pressing the emergency stop button; the charging procedure is maintained (exception: continuous tone). Operating manual LL12 17/18 Version 1.6 (01/2017)
  • Page 18: Services Performed On Your Platform Lift At A Glance

    Services performed on your Konstanz stair lift at a glance Installed on: Serial no.: Installed by: TÜV acceptance on: Date Service performed Signature Operating manual LL12 18/18 Version 1.6 (01/2017)
