Lippe Lift T80 Maintenance Instruction

Inclined stair lifts
Hide thumbs Also See for T80:

Advertisement

Quick Links

Download this manual
Maintenance instructions for T80 inclined stair lifts
The work is to be carried out by qualified technical personnel only!
The following work may be carried out by qualified personnel only:
Installation
Adjustments and settings
Maintenance work
Fault finding/rectification
Qualified personnel are persons who
-
know how the machine works
-
have received instruction on how it works
-
have read and understood the operating, installation and service manuals
-
are aware of the dangers posed by the machine (and also its components)
-
know and understand the interrelationships between the mechanical components
-
know and understand the interrelationships between the electrical components
-
have the appropriate tools/measuring instruments and know how to use them
-
have a sufficient understanding of the German or English language respectively
When carrying out any work on the machine, please note:
-
Do not allow other persons to access the machine when there is an increased danger potential
(covers removed, safety devices disabled etc.).
-
Avoid the risk of tripping up due to the open machine, tools lying around, electrical cables etc.
-
The potential dangers of the machine may not have been increased after conclusion of the work on
the machine
-
Parts of the machine that are not yet firmly connected to the building/running rail are to be secured
against falling over
The safety instructions in the operating manual are to be observed!!
Original parts and accessories are specially designed for our platform lifts. We expressly draw your
attention to the fact that parts and accessories not supplied by us have also not been tested and approved
by us. The installation and/or use of such products can therefore, under certain circumstances, negatively
affect the constructive specified characteristics of the lift and impair the active and/or passive travelling
safety as a result. The manufacturer accepts no liability whatsoever for damage caused by the use of non-
original parts and accessories.
Maintenance instructions T80 chair lift
1 / 9
10 / 2024
