Lippe Lift T80 Operating Instructions Manual
Inclined stair lift - chairlift
Hide thumbs
Also See for T80:
- Installation instructions manual (29 pages) ,
- Assembly manual (25 pages) ,
- Operation manual (21 pages)
Table of Contents
Advertisement
Quick Links
Contents
1
General.............................................................................
1.1
Technical data.....................................................................
1.2
Ambient conditions...............................................................
1.3
Testing obligations...............................................................
2
Intended purpose of use........................................................
2.1
Transport profiles..................................................................
2.2
Inappropriate use..................................................................
2.3
Operator qualification............................................................
2.4
Product description...............................................................
2.5
General sketch of the T80 chair................................................
3
Safety..............................................................................
4
Operation.........................................................................
4.1
Main switch........................................................................
4.2
Deep discharge protector.........................................................
4.3
Battery charger....................................................................
4.4
Fetching and sending the chair..................................................
4.5
Travelling with the chair.........................................................
4.6
What to do in the event of an unexpected standstill..........................
4.6.1
Manual operation.................................................................
5
Options/extras.....................................................................
5.1
Visual warning signal............................................................
6
In the event of a malfunction .................................................
7
Acoustic warning signals.......................................................
8
Services............................................................................
Please read the operating instructions before using the lift.
Also make sure that everyone who uses the lift has read and understood the operating
No rights whatsoever can be derived from the operating instructions.
Operating manual chair STG
This is a translation of the original German operating instructions
Operation of the T80 chair lift
! Important !
instructions.
1/15
Page
3
5
5
5
5
5
6
6
6
7
8
10
10
10
10
11
11
12
12
13
13
14
14
15
Version: 12.0 (02/2010)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lippe Lift T80
Summary of Contents for Lippe Lift T80
-
Page 1: Table Of Contents
This is a translation of the original German operating instructions Operation of the T80 chair lift Contents Page General………………………………………………………………….. Technical data…………………………………………………………… Ambient conditions……………………………………………………… Testing obligations……………………………………………………… Intended purpose of use……………………………………………….. Transport profiles………………………………………………………... Inappropriate use………………………………………………………… Operator qualification…………………………………………………… Product description……………………………………………………… General sketch of the T80 chair…………………………………………... - Page 2 The following notified body: TÜV AUSTRIA SERVICES GMBH (IDF no.: 0408) was employed for: EU type testing, test report no..: TÜV-A/MHF/MG 10-01044 Responsible for the documentation: Lippe Lift- und Anlagenbau GmbH (Documentation Dept.) Weststrasse 48, D-32657 Lemgo Lemgo, 1/3/2010 _______________________ F.-W.
-
Page 3: General
General The rating plate provides the most important information about the platform lift. Type of machine Type description Year of manufacture Serial number Loading capacity of the platform Dead weight of the platform Manufacturer Field for details of the importer/dealer Operating manual chair STG 3/15 Version: 12.0 (02/2010) - Page 4 The T80 chair lift is equipped with many sensory surfaces. Here is an overview: 1 = integrated in the safety circuit (further travel is not possible if activated) 2 = direction-related power-off (the lift can travel in the opposite direction)
-
Page 5: Technical Data
In the case of longer distances covered, the number of start-ups should be reduced accordingly (and linearly). The T80 chair lift may be only operated if danger due to falling objects (such as flower pots) is ruled out. -
Page 6: Inappropriate Use
The continuous sound pressure level is less than 70 dB (A). We recommend that you take out a service contract. This guarantees the technically optimum condition of your T80 chair lift by means of regular maintenance. The maintenance interval is at least once per year. -
Page 7: General Sketch Of The T80 Chair
Item Designation Hood Armrests, foldable Key switch control element (I-0-II) Emergency stop button Main switch Seat, foldable Footrest, foldable Emergency call Safety belt Enable button Charging circuit breaker (at the rear of the chair) Frame side contact (at both sides) Sensitive hood contact Operating manual chair STG 7/15... -
Page 8: Safety
Safety and special instructions ! ATTENTION ! Although your lift complies with the latest safety regulations, it is essential to follow the safety instructions below: Put the lift into operation only after reading the operating instructions and adhere to the operating instructions. Never exceed the permissible loading capacity. - Page 9 Do not make any unnecessary movements on the chair, such as rocking or swinging. In the case of interior and exterior installations, brief or permanent flooding of the lift is forbidden. Remove dirt from the lift with a little polish or a damp cloth, not with a water jet.
-
Page 10: Operation
Deep discharge protector All T80 chair lifts are equipped with an acoustic deep discharge protector. This acoustic signal generator is intended to protect the batteries against deep discharge. If the battery voltage drops below 22 V, a beep sounds at intervals of approx. 5 seconds. In this case you should drive immediately to the next charging station –... -
Page 11: Fetching And Sending The Chair
If the T80 chair lift reaches one of the middle stations, it stops there. If the T80 chair lift is to drive on, then the external control must be released briefly and then actuated again immediately, so that the chair lift continues to drive. -
Page 12: What To Do In The Event Of An Unexpected Standstill
! The chair lift must be folded up so that it does not block the stairway (see 4.4). The T80 chair lift stops automatically at a middle station; if you wish to travel further, briefly release the key and then turn it again immediately. -
Page 13: Options/Extras
Pull off the hood including the backrest in an upward direction Options/extras Depending upon needs, the T80 chair lifts can be equipped with the following extras Visual warning signal A visual signal (flashing orange light on the hood) is activated each time the chair lift moves. -
Page 14: In The Event Of A Malfunction
In the event of a malfunction Malfunction Possible cause Remedial action Lift does not function at Is the key on the control unit set Set the key switches correctly to -I- or -II- and are the others (see 4.4 or 4.5) set to -0- or removed? Are all EMERGENCY STOP Unlock the EMERGENCY... -
Page 15: Services
Services performed on your T80 chair lift at a glance Installed on: Serial no.: Installed by: TÜV acceptance on: Date Service performed Signature Operating manual chair STG 15/15 Version: 12.0 (02/2010)
