- Page 1 "ALLEGHENY"PETITE FIREPLACE FA9108 – HAND-PAINTED Assembly Instructions For assistance with assembly contact: Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
- Page 2 "ALLEGHENY"PETITE FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage.
- Page 3 "ALLEGHENY"PETITE FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage.
- Page 4 "ALLEGHENY"PETITE FIREPLACE Assembly Instructions INSERT 4PCS WOOD DOWEL (B) AND 8PCS CAM BOLT (A) INTO PREDRILLED HOLES ON END OF LEFT AND RIGHT FRONT PANELS (1&2) AND FIT INTO CORRESPONDING HOLES OF UPPER FRONT PANEL (3) AND BOTTOM FRONT PANEL (4),THEN INSERT...
- Page 5 "ALLEGHENY"PETITE FIREPLACE Assembly Instructions USE 6PCS LONG SOCKET HEXAGON (D) TO ATTACH 6PCS SPRING WASHER (E) AND 6PCS FLAT WASHER (F) TO ASSEMBLE TWO FRAME TOGTHER. Figure 4 INSERT THE FIREBOX FROM THE BACK OF FIREPLACE. MAKE SURE FIREBOX IS PRESSED TIGHTLY AGAINST THE ASSEMBLED UNIT.
- Page 6 Parts will not be available for items arriving fully assembled. Parts will be sent if available from SEI. The fireplace mantel will fit both gel fuel and electric firebox inserts. Depending on the insert ordered only one insert will be included.
