"CLAREMONT" CONVERTIBLE MEDIA FIREPLACE
FA931000TX-CHERRY
FA931400TX-IVORY
FA931500TX-BLACK
FA931600TX-BROWN MAHOGANY
For assistance with assembly contact:
FA931700TX-GLAZED PINE
Southern Enterprises Inc.
Customer Service 1-800-633-5096
Assembly Instructions
service@seidal.com
www.seidal.com
Advertisement
Related Manuals for SEI FA931000TX-CHERRY
Summary of Contents for SEI FA931000TX-CHERRY
- Page 1 “CLAREMONT” CONVERTIBLE MEDIA FIREPLACE FA931000TX-CHERRY FA931400TX-IVORY FA931500TX-BLACK FA931600TX-BROWN MAHOGANY For assistance with assembly contact: FA931700TX-GLAZED PINE Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com...
-
Page 2: Parts List
“CLAREMONT” CONVERTIBLE MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. Carefully study the screw diagrams below . - Page 3 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown in actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 4 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions INSERT （A） CAM BOLT & （B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (5) SUPPORT PANELS&(6) SHELF PANEL. FINALLY PLACE (R) COVER IN CAM LOCK. Figure 1 AFTER ASSEMBLED FIGURE 1,INSERT（A）CAM BOLT &（B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (3)FRONT SIDE...
- Page 5 CLAREMONTCONVERTIBLE MEDIA FIREPLACE Assembly Instructions AFTER ASSEMBLED FIGURE 3,INSERT（A）CAM BOLT &（B） WOOD DOWEL TO THE RELATED HOLES,THEN USE （C） CAM LOCK TO (1) CONNECT TOP PANEL . FINALLY PLACE (R) COVER IN CAM LOCK. Figure 4 AFTER ASSEMBLED FIGURE 4,INSERT（A）CAM BOLT &（B） WOOD DOWEL TO THE RELATED HOLES,THEN USE（C）CAM LOCK TO CONNECT (7) BASE .
- Page 6 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions AFTER ASSEMBLED FIGURE 6, USE（K）WOOD SCREW & (Q) HINGE TO CONNECT (10)DOORS . INSERT (P) SHELF HOLDER TO THE RELATED HOLES,THEN PUT (9) ADJUSTABLE SHELF PANELS ON THE （P）SHELF HOLDERS. THEN USE(M) WOOD SCREW AND (I) MAGNET LOCK ON THE RELATED HOLES;...
- Page 7 CLAREMONT CONVERTIBLE MEDIA FIREPLACE Assembly Instructions PUSH (R) INSERT TO THE RELATED PLACE OF MAIN BODY. Figure 10 INSERT THE (L) WOOD SCREW INTO THE RELATED HOLES OF (11) INNER FIXED BAR ,THEN USE SCREWDRIVER TO LOCK IT TIGHTLY. Figure 11...
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
- Page 9 CAUTION CAUTION The top shelf of this cabinet is intended for plasma/LCD televisions having a Max TV size is 42" flat screen and Max weight limit is 70 lb. The top shelf is intended for a flat screen television with a maximum overall width of 46” and supports up to 85lb.
