- Page 1 403-F-650-521-CAC6.00-ISSUE4.0 SERVICE MANUAL MODEL 403-F EXECUTIVE DESK TELEPHONE EQUIPPED WITH CAC6.00 FIRMWARE Serving the Telephone Industry Since 1930 Communication Equipment 519 W South Park Street & Engineering Company Okeechobee, FL 34972 Voice: 863-357-0798 Fax: 863-357-0006...
-
Page 2: Important Information
ISSUE 4.0 IMPORTANT INFORMATION CUSTOMER Please fill in before you continue. The following information is necessary when calling CEECO for assistance. MODEL NUMBER MODEL 403-F, EQUIPPED WITH CAC6.00 FIRMWARE SERIAL NUMBER DATE MANUFACTURED LOCATION INSTALLED For us to better serve you, please have this information available when calling for technical support. -
Page 3: Table Of Contents
PROGRAMMING CONTINUED…..............8 PROGRAMMING CONTINUED…..............9 TESTING/OPERATION ..................10 TESTING/OPERATION CONTINUED… ............11 SPECIFICATIONS....................12 PARTS LIST ......................13 FCC NOTICE......................14 REPAIR AND RETURN INFORMATION............15 WARRANTY POLICY ..................16 10.0 DIAGRAM......................17 CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 4: Introduction
The CEECO Model 403-F Executive Desk Telephone equipped with a metal button tone dial and CAC6.00 firmware is a microprocessor-based coinless telephone designed to withstand abuse and fraudulent call attempts. The 403-F is designed for special applications where a telephone must be both durable and attractive. -
Page 5: Programming Continued
2=3 min.call timeout 7=20 min.call timeout 3=5 min.call timeout 8=25 min.call timeout 4=10 min. call timeout 9=30 min.call timeout • Be sure to record your selections in the table below for future reference. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 6: Programming Continued
# key must be entered on the keypad when speed dialing. Using the examples above, if only 30, 31, or 32 were entered on the keypad, no speed dialing would occur. However, if #30, #31, or #32 were entered, the CEECO Communication Equipment & Engineering Company PROPRIETARY... - Page 7 ISSUE 4.0 corresponding speed-dial numbers would automatically dial out. This is true for all forty (40) speed-dial locations. CEECO Communication Equipment & Engineering Company PROPRIETARY...
-
Page 8: Programming Continued
#48 __ __ __ __ __ __ __ __ __ __ __ #68 __ __ __ __ __ __ __ __ __ __ __ #49 __ __ __ __ __ __ __ __ __ __ __ #69 __ __ __ __ __ __ __ __ __ __ __ CEECO Communication Equipment & Engineering Company... -
Page 9: Programming Continued
Programming is now completed. Hang up the phone and return the mini- jumpers to the “OFF” position, as depicted on the last page of this manual. Replace the telephone faceplate and fasten it with the security screw. The phone is now ready for Testing/Operation. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 10: Testing/Operation
Please keep in mind that this will not be exact. If this fails, hang up and repeat sections 3.2, 3.3, 3.5, and 3.10 only. If this does not solve the problem, please refer to section 8.2. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 11: Testing/Operation Continued
Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 12: Specifications
Meets EIA standards ENVIRONMENTAL: Temperature 0oC to 50oC Humidity 20%-90% non-condensating. TELEPHONE PANEL: Plastic Desk Model MOUNTING: Flat Horizontal Mount FCC REGISTRATION: BW 88T7-68413-TE-T UL LISTED NO.: 6OF5 RINGER EQUIVALENCE: 0.4A TYPE JACK: RJ11C CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 13: Parts List
701-110 Chrome Keypad 650-521 MCRKII Printed Circuit Board 401-004 Handset 401-010 Modular Line Cord 406-019 Security Screw 403-010 Service Manual CAC6.00 Firmware Accessories: 301-037 Security tool 700-004 LNB Chrome keypad - large number CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 14: Fcc Notice
FCC registration number and ringer equivalence number. These numbers are listed in section 6.0. The FCC further requires that you notify your local telephone company when permanently disconnecting this telephone. CEECO Communication Equipment & Engineering Company PROPRIETARY... -
Page 15: Repair And Return Information
NON-WARRANTY REPAIR CEECO will repair equipment out of warranty for a set charge plus parts. The customer must pay the shipping costs for both directions. RETURN FOR CREDIT Material may be returned for credit only with prior approval. Material authorized for return is subject to a 20% restocking charge based on the manufacturer's list price. -
Page 16: Warranty Policy
ISSUE 4.0 WARRANTY POLICY GENERAL CEECO products are guaranteed to be free of defects in material and workmanship for a period of 12 months from the date of original purchase. CEECO’s obligation under this warranty is limited to repair or replacement of any part found to be defective by CEECO. -
Page 17: 10.0 Diagram
ON position BEFORE programming. When programming is completed, move the mini jumpers to the OFF position. NOTE: Do not leave the mini jumpers in the ON position; this will decrease battery life. CEECO Communication Equipment & Engineering Company PROPRIETARY... - Page 18 ISSUE 4.0 CEECO Communication Equipment & Engineering Company PROPRIETARY...
