DURA-JET
O
W
N
E
R '
INSTALLATION, OPERATION & PARTS
MODELS
3/4 HP
(2-Speed)
JSAYDL
TM
PUMP
S
M
A
N
U
1 HP
1 HP
(2-Speed)
JSAEL
JSAYEL
JSAEL-2A
A
L
1-1/2 HP
JSAFL
JSAEFL
JSAYFL
S196 (Rev. A)
Advertisement
Table of Contents
Related Manuals for STA-RITE DURA-JET JSAYDL
Summary of Contents for STA-RITE DURA-JET JSAYDL
- Page 1 Customer Suppport: (800) 831-7133 Sta-Rite®, Dura-Jet™ and Pentair Water Pool and Spa® is a trademark and/or a registered trademark of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United States and/or other countries. Teflon® is a registered trademark of E.I. Du Pont De Nemours and Company Corporation.
-
Page 2: Table Of Contents
DURA-JET SP A PUMP To avoid unneeded service calls, prevent possible injuries, and get the most out of your pump, READ THIS MANUAL CAREFULLY! The Sta-Rite ‘JS’ Series Tub Pump: • Is designed to circulate hot water in spas and hot tubs. •... -
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Always follow basic safety pre- cautions with this equipment, in- cluding the following. To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. This pump is for use with permanently installed pools and may also be used with hot tubs and spas if so marked. -
Page 4: Installation
INST ALLA TION Installation and wiring of pump should only be done by qualified, licensed personnel. Pump mount must: Be Solid - Level - Rigid - Vibration free. (To reduce vibration and pipe stress, bolt pump to mount.) Be installed with pump suction inlet below water level at all times (this al- lows pump to prime). -
Page 5: Electrical
Hazardous voltage. Can shock, burn, or cause death. Ground pump before connecting to power supply. BONDING MOTOR NAMEPLATE GREEN GROUND SCREW MOTOR CANOPY THROUGH BOLTS 499 0993 Figure 1A: Typical ground screw and bonding lug locations. Motor Terminal Board Connections SINGLE DUAL VOLTAGE... - Page 6 TABLE I - RECOMMENDED CIRCUIT BREAKER SIZE AND WIRING DATA FOR 60 Hz MOTORS Model Motor Volts Single Speed Pumps: JSACL-A JSADL-2A JSAEL-2A JSAFL-A 1-1/2 115/230 JSAEFL-A 1-1/2 115/230 JSADL-230A JSAEL-230A Two Speed Pumps: JSAYDL-A 3/4-1/8 JSAYDL-LA 3/4-1/8 JSAYEL-A 1-1/6 JSAYEL-LA 1-1/6 JSAYFL-LA...
-
Page 7: Operation
Hazardous suction. Can trap hair or body parts, causing severe injury or death. Do not block suction. Too much heat can cause nausea, dizziness, fainting, or death. Check temperature. before using tub. OPERA TION Priming Pump: NEVER run pump dry! Running pump dry may damage seals, causing leakage and flooding! Fill pump with water before starting motor. - Page 8 Hazardous voltage. Can shock, burn, or cause death. Disconnect power before working on pump or motor. Figure 2 Figure 3 Figure 4 Figure 5 Pump should only be serviced by qualified personnel. To avoid dangerous or fatal electrical shock hazard, disconnect power to motor before working on pump or motor! No lubrication or regular maintenance are needed.
-
Page 9: Storage/Winterizing
Figure 6 Start Here Figure 7 – Torque Sequence 5. Screw impeller onto shaft until it seats against shaft shoulder. Work slinger over end of impeller sleeve so it rides on sleeve (Figure 6). 6. Remount front plate; using pattern, shown in Figure 7, torque bolts to 30 inch-lbs. - Page 10 Draining Pump: 1. Close all valves on suction and return piping. 2. Remove drain plug in bottom of front plate. 3. Drain all piping and storage tanks exposed to freezing temperatures. 4. Be sure no airlocks are holding water in system. 5.
-
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE Read and understand safety and operating instructions in this manual before doing any work on pump! A. PUMP DOES NOT OPERATE 1. Check GFCI for proper operation according to GFCI manufacturer’s in- structions. 2. Check for plugged impeller. Follow disassembly/assembly instructions under “Pump Service”, Page 8. -
Page 12: Repair Parts List
1161 0695 Description Motor Slinger Seal Plate “O” Ring Seal Impeller Front Plate Pipe Plug Drain Plug Screw, 1/4-20x1-3/4 “O” Ring, Adapter, Union Collar, Union • Nameplate • Decal - ”For Use with Pools and Spas” • Voltage Label - 230V(-230A) •... - Page 16 *S196* S196 (Rev. A) 04-15-10...
