STA-RITE DPC Owner's Manual

STA-RITE DPC Owner's Manual

Sta-rite dpc series portable utility water pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
293 Wright Street, Delavan, WI 53115
Phone: 1-888-782-7483
Fax: 1-800-426-9446
Web Site: Sta-Rite.com
© 2011
DPC
Installation/Operation/Parts
For further operating, installation, or
maintenance assistance:
Call 1-888-782-7483
OWNER'S MANUAL
Portable Utility Water Pump
S930 (5/31/2011)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPC and is the answer not in the manual?

Questions and answers

Related Manuals for STA-RITE DPC

Summary of Contents for STA-RITE DPC

  • Page 1 OWNER’S MANUAL Portable Utility Water Pump 293 Wright Street, Delavan, WI 53115 Phone: 1-888-782-7483 Fax: 1-800-426-9446 Web Site: Sta-Rite.com Installation/Operation/Parts For further operating, installation, or maintenance assistance: Call 1-888-782-7483 © 2011 S930 (5/31/2011)

  • Page 2: Important Safety Instructions

    Safety Important Safety Instructions Electrical Safety The pump is supplied with a 3-conductor grounding SAVE THESE INSTRUCTIONS - This manual contains type cord. Connect only to a properly grounded, important instructions that should be followed during GFCI protected outlet. Do not lift the pump by the installation, operation, and maintenance of the product.

  • Page 3: Limited Warranty

    Retain Original Receipt For Your Records Limited Warranty STA-RITE warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free from defects in material and workmanship for the Warranty Period shown below.

  • Page 4: Installation

    Installation Before You Install Your Pump 5. Start the pump; water should be produced in 10 minutes or less. The time will depend on the Pump clean water only with this pump. depth to water. If no water is produced within NOTICE: This unit is not designed for applications 10 minutes, stop the pump, release all the pressure, involving salt water or brine! Use with salt water or brine...
  • Page 5 Installation Piping damaging seal and possibly causing burns to persons handling pump. Fill pump with water before starting. Both the suction and discharge are tapped for 1-1/4” pipe. If you are using hose or plastic pipe for the suction Burn Hazard. NEVER run pump against closed discharge.

  • Page 6: Maintenance

    Maintenance Draining Installation Of New Seal The pump and piping should always be protected against 1. Clean polished surface of ceramic seat with a freezing temperatures. If there is any danger of freezing, clean cloth. drain the pump and piping. To drain pump, remove the 2.

  • Page 7: Troubleshooting

    Troubleshooting Symptom Probable Cause(s) Corrective Action Make sure pump body is full of water. See priming Pump not properly primed. instructions. Check voltage at motor terminals and at meter when pump is Speed too low. operating. If low, refer to wiring instructions, or check with your Power Company.

  • Page 8: Repair Parts

    Repair Parts Ref. Part Description Qty. Part Number Motor - 1/2 HP 115V/230V - 60 Hz. J218-582A-115-PKG Hex Capscrew - 3/8 - 16x1-1/2” † Water Slinger 17351-0009 Seal Plate Diffuser C3-120 Roll Pin 3/32 x 5/16” U30-522SS Gasket N20-35 Shaft Seal U109-6A Impeller C5-184P...
