478
6-2. Flat Tire
3
Turn the wing bolt and jack
screw counterclockwise.
■

To secure the jack

1
Insert the wing bolt into the
jack with the jack screw
pointing to the right side and
turn the wing bolt clockwise
to temporarily tighten it.
2
Turn the jack screw in the
direction shown in the figure.
3
Turn the wing bolt completely
to secure the jack.
If the jack is not completely secured, it could rattle while driving. Make
sure the jack screw is sufficiently tightened.
4
Return the trunk board to its original position.
Verify that the trunk board is securely installed.
■
Maintenance
• Always keep the jack clean.
• Make sure the moving parts are kept free from dirt or rust.
• Make sure the screw thread is adequately lubricated.
YARIS iA_OM_OM99N89z_(U)
Jack screw
Wing bolt
Jack screw
Wing bolt
