Engine Start Function When Key Battery is Dead

If the engine cannot be started due to a dead key battery, the engine
can be started using the following procedure:
1
Continue to depress the brake pedal firmly until the engine has
completely started.
2
Manual transaxle:
Continue to depress the clutch pedal firmly until the engine has
completely started.
3
Verify that the push button start indication light (green) flashes.
The push button start indicator light (green) will flash even if the push but-
ton start is pressed before depressing the clutch pedal (manual transaxle)
or the brake pedal (automatic transaxle). If the clutch pedal is depressed
(manual transaxle) or the brake pedal is depressed (automatic transaxle)
under this condition, the engine can be started by resuming the procedure
following this.
4
Touch the push button start
using the backside of the key
(as shown) while the push but-
ton start indicator light (green)
flashes.
When touching the push button
start using the backside of the key
as shown in the illustration, touch
the push button start with the lock
switch side of the key facing up.
5
Verify that the push button start indicator light (green) turns on.
6
Press the push button start to start the engine.
●
The engine cannot be started unless the clutch pedal is fully depressed
(manual transaxle) or the brake pedal is fully depressed (automatic tran-
saxle).
●
If there is a malfunction with the push button start function, the push button
start indicator light (amber) flashes. In this case, the engine may start, how-
ever, have the vehicle checked at your Toyota dealer as soon as possible.
●
If the push button start indicator light (green) does not illuminate, perform
the operation from the beginning again. If it does not illuminate, have the
vehicle checked at your Toyota dealer.
●
To switch the ignition position without starting the engine, perform the follow-
ing operations after the push button start indicator light (green) turns on.
1
Release the clutch pedal (manual transaxle) or brake pedal (automatic
transaxle).
YARIS iA_OM_OM99N89z_(U)
3-1. Start/Stop Engine
Indicator light
Push button start
Smart Key
145
3
