TABLE OF CONTENTS For your information....... 6 Operation of Reading this manual ....10 each component How to search......11 Pictorial index ......12 3-1. Key information Keys........84 For safety and security 3-2. Opening, closing and locking the doors Side doors ......
Page 3 Driving Interior features 4-1. Before driving 5-1. Using the air conditioning system and defogger Driving the vehicle..... 116 Air conditioning system..172 Cargo and luggage.... 127 5-2. Using the audio system Vehicle load limits ..... 131 Steering wheel audio Trailer towing..... 132 switches......
Page 4 TABLE OF CONTENTS Maintenance and care When trouble arises 6-1. Maintenance and care 7-1. Essential information Cleaning and protecting Emergency flashers... 262 the vehicle exterior..194 If your vehicle has to Cleaning and protecting be stopped in the vehicle interior... 197 an emergency....
Page 5 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..306 Fuel information ....317 Tire information ....320 8-2. Customization Customizable features ..333 Items to initialize....335 For owners Reporting safety defects for U.S. owners......338 Seat belt instructions for Canadian owners (in French) .......
Page 6: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available on the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 7 SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recordings Your Toyota is equipped with several sophisticated computers that will record certain data, such as: •...
Page 8: Event Data Recorder
EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 9 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 10: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 11: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 355 Searching installation ■ position • Pictorial index....P. 12 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 352 Searching by title ■ • Table of contents .....P. 2...
Page 12: Pictorial Index
Pictorial index Pictorial index ■ Exterior The illustration represents the 5-door models and may differ from the body shape of the 3-door models. Side doors ........P. 89 Locking/unlocking .
Page 13 Pictorial index Wipers ........P. 149, 152 Precautions against winter season .
Page 14: Instrument Panel
Pictorial index ■ Instrument panel Engine switch........P. 136 Starting the engine .
Page 15 Pictorial index Multi-information display ......P. 78 Parking brake ........P. 143 Applying/releasing .
Page 16 Pictorial index ■ Switches Outside rear view mirror switches ....P. 111 Instrument panel light control dial ..... P. 77 Tire pressure warning reset switch .
Page 17 Pictorial index Audio remote control switches ..... P. 180 Cruise control switch ......P. 158 VSC OFF switch .
Page 18 Pictorial index ■ Interior SRS airbags ........P. 34 Floor mats.
Page 19 Pictorial index Inside rear view mirror ......P. 109 Sun visors ........P. 190 Vanity mirrors.
Page 20 Pictorial index...
Page 21: For Safety And Security
For safety and security 1-1. For safe use Before driving...... 22 For safety drive ....24 Seat belts ......26 SRS airbags......34 Front passenger occupant classification system ..46 Safety information for children ......52 Child restraint systems..53 Installing child restraints..
Page 22: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 23 When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
Page 24: For Safety Drive
1-1. For safe use For safety drive For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 25 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ●...
Page 26: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 27 1-1. For safe use Fastening the rear center seat belt Take out the plate, and then pull the seat belt. Push the plate into the buckle in Plate “B” Plate “A” the order of plate “A” and plate “B” until a clicking sound is heard.
Page 28 1-1. For safe use Releasing and stowing the rear center seat belt To release the hooked buckle “B”, push the buckle release button. To release the hooked plate “A”, insert the plate “B”, the key into the hole on the buckle. When releasing the seat belt, retract it slowly.
Page 29 1-1. For safe use Seat belt pretensioners (front seat) The pretensioners help the seat belts to quickly restrain the occu- pants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal col- lision. The pretensioners do not activate in the event of a minor frontal impact, a minor side impact, a rear impact or a vehicle rollover.
Page 30 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seats and always use a seat belt and/or an appropriate child restraint system. ●...
Page 31 ● If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer.
Page 32 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 33 1-1. For safe use WARNING ■ Using a seat belt extender ● Do not wear the seat belt extender if you can fasten the seat belt without the extender. ● Do not use the seat belt extender when installing a child restraint system because the belt will not securely hold the child restraint system, increas- ing the risk of death or serious injury in the event of an accident.
Page 34: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 35 1-1. For safe use SRS airbag system components Curtain shield airbags Driver seat cushion airbag Side impact sensors (front) Driver’s seat belt buckle switch Side airbags Driver knee airbag Side impact sensors (rear) Front impact sensors SRS warning light Airbag sensor assembly Driver airbag Front passenger...
Page 36 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors, etc. shown in the system compo- nents diagram above.
Page 37 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 38 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not allow the front seat occupants to hold items on their knees.
Page 39 1-1. For safe use WARNING ■ SRS airbag precautions ● Do not attach anything to areas such as a door, windshield glass, side door glass, front or rear pillar, roof side rail and assist grip. ● Do not attach any heavy, sharp or hard objects such as keys and accessories to the key.
Page 40 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 41 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising, etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 42 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags, SRS curtain shield airbags may also deploy if a seri- ous impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 43 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS side and curtain shield airbags) The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body other than the passenger compartment.
Page 44 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 45 1-1. For safe use ● The surface of the seats with the side airbag is scratched, cracked, or other- wise damaged. ● The portion of the front pillars, rear pil- lars or roof side rail garnishes (padding) containing the curtain shield airbags inside is scratched, cracked, or other- wise damaged.
Page 46: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classi- fication system. This system detects the conditions of the front passenger seat and activates or deactivates the devices for front passenger. SRS warning light Seat belt reminder light “AIR BAG OFF”...
Page 47 1-1. For safe use Conditions and operations in the front passenger occupant clas- sification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Side airbag on the front passenger seat Activated...
Page 48 1-1. For safe use Child restraint system with infant ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights OFF” Indicator/ SRS warning light warning light Seat belt reminder light flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag in the front Devices...
Page 49 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ warning light SRS warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag in the front Devices...
Page 50 1-1. For safe use WARNING ■ Front passenger occupant classification system precautions Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 51 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
Page 52: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 53: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 54 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing — Infant seat/ Forward facing — Convertible   convertible seat seat Booster seat ...
Page 55 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 56 1-1. For safe use WARNING ■ Child restraint precautions ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front and rear pillars or roof side rails from which the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the child restraint system.
Page 57: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Page 58 1-1. For safe use Installation with LATCH system Type A  Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto LATCH anchors. If the child restraint has a top tether strap, the top tether strap should...
Page 59 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint sys- tem on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 60 1-1. For safe use While pushing child restraint system down into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 61 1-1. For safe use Fully extend the shoulder belt and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 62 1-1. For safe use Booster seat ■ Place the child restraint sys- tem on the seat facing the front of the vehicle. Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the...
Page 63 1-1. For safe use Child restraint systems with a top tether strap Remove the luggage cover. (P. 188) Remove the head restraint. (P. 104) Secure the child restraint system using the LATCH anchors or a seat belt. Open the anchor bracket cover, latch the hook onto the anchor bracket and tighten the top tether strap.
Page 64 1-1. For safe use WARNING ■ When installing a booster seat To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to the child. (P. 29) ■...
Page 65 1-1. For safe use WARNING ■ When installing a child restraint system ● Ensure that the belt and plate are securely locked and the seat belt is not twisted. ● Shake the child restraint system left and right, and forward and backward to ensure that it has been securely installed.
Page 66: Exhaust Gas Precautions
Keep the back door closed. ● If you smell exhaust gases in the vehicle even when the back door is closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking ●...
Page 67: Theft Deterrent System
1-2. Theft deterrent system  Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 68 1-2. Theft deterrent system ■ Certifications for the engine immobilizer system U.S.A.  FCC ID: PSIRI-43BTY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 69: Theft Prevention Labels (Except Canada)
1-2. Theft deterrent system Theft prevention labels (except Canada) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recov- ery of parts from stolen vehicles. Do not remove under penalty of law.
Page 70 1-2. Theft deterrent system...
Page 71: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......72 Gauges and meters .... 76 Multi-information display ..78...
Page 72: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster, cen- ter panel and dashboard inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 73 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Electric power steering Brake system warning system warning light light (P. 272) (P. 273) (Except Canada) 1, 3 Brake system warning Slip indicator light (P.
Page 74 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : If equipped : The light flashes to indicate that the system is operating and come on to indicate a malfunction.
Page 75 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 76: Gauges And Meters
2. Instrument cluster Gauges and meters Tachometer (if equipped) Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge (if equipped) Displays the quantity of fuel remaining in the tank. Display change button P. 79 Multi-information display Presents the driver with a variety of driving-related data.
Page 77 2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Brighter Darker ■ The meters and display illuminate when The engine switch is in the “ON” position. NOTICE ■ To prevent damage to the engine and its components On vehicles with a tachometer, do not let the indicator needle of the tachom- eter enter the red zone, which indicates the maximum engine speed.
Page 78: Multi-Information Display
2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data including the clock. Display contents Type A Type B   Type C  Clock (P. 80) Outside temperature display (P. 81) Shift position and gear step position indicator (P. 139) Drive information (P.
Page 79: Drive Information
2. Instrument cluster Changing the display Items displayed can be switched by pressing the display change button. Drive information Odometer ■ Displays the total distance the vehicle has been driven. Trip meters ■ Displays the distance the vehicle has been driven since the meter was last reset.
Page 80 2. Instrument cluster Average fuel consumption ■ Displays the average fuel consumption since the function was reset. • The function can be reset by pressing and holding the display change button when the average fuel consumption is displayed. • Use the displayed average fuel consumption as a reference. Instantaneous fuel consumption ■...
Page 81 2. Instrument cluster Outside temperature display The temperature display shows temperatures within the range of -40°F (-40°C) and 122°F (50°C). Display ■ In the following situations, the correct outside temperature may not be displayed, or the display may take longer than normal to change: ●...
Page 82 2. Instrument cluster...
Page 83: Operation Of Each Component
Operation of each component 3-1. Key information Keys ........84 3-2. Opening, closing and locking the doors Side doors......89 Back door......94 3-3. Adjusting the seats Front seats ......98 Rear seats......101 Head restraints....104 3-4. Adjusting the steering wheel and mirrors Steering wheel ....
Page 84: 3-1. Key Information
3-1. Key information Keys The keys The following keys are provided with the vehicle. Vehicles without an engine immobilizer system (type A)  Master keys Key number plate Vehicles without an engine immobilizer system (type B)  Master key (with a wireless remote control function) Operating the wireless remote con- trol function (P.
Page 85 3-1. Key information Vehicles with an engine immobilizer system (type B)  Master keys Operating the wireless remote con- trol function (P. 89) Key number plate Vehicles with an engine immobilizer system (type C)  Master keys Operating the wireless remote con- trol function (P.
Page 86 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 87 If the wireless remote control function does not operate, the battery may be depleted. Replace the battery when necessary. ■ Customization that can be configured at your Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features: P. 333) ■...
Page 88 3-1. Key information NOTICE ■ To prevent key damage Observe the following: ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
Page 89: Side Doors
3-2. Opening, closing and locking the doors Side doors Unlocking and locking the doors from the outside The vehicle can be locked and unlocked using the keys, wireless remote control or door lock switches. ◆ Wireless remote control (if equipped) Type A ...
Page 90 3-2. Opening, closing and locking the doors ◆ Keys Turning the key operates the doors as follows: Driver’s door ■ Locks all the doors Unlocks all the doors Turning the key unlocks the driver’s door. Turning the key again unlocks the other doors. Front passenger’s door ■...
Page 91 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switch Unlocks all the doors Locks all the doors ◆ Inside door lock buttons Locks the doors Unlocks the doors The front doors can be opened by pulling the inside handle even if the inside door lock but- ton is in the lock position.
Page 92 3-2. Opening, closing and locking the doors Rear door child-protector lock (5-door models only) The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent children from opening the rear doors.
Page 93 3-2. Opening, closing and locking the doors WARNING ■ To prevent an accident Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
Page 94: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Unlocking and locking the back door ◆ Door lock switch P. 91 ◆ Wireless remote control (if equipped) P.
Page 95 3-2. Opening, closing and locking the doors ■ Operation signals (vehicles with a wireless remote control) P. 90 ■ Security feature (vehicles with a wireless remote control) P. 90 ■ Luggage compartment light The luggage compartment lights turn on when the back door is opened. WARNING Observe the following precautions.
Page 96 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended.
Page 97 Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the back door. ● Do not place your hand on the damper stay or apply lateral forces to it.
Page 98: 3-3. Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Driver’s seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (if equipped) Front passenger’s seat  Seat position adjustment lever Seatback angle adjustment lever Seatback lock release lever (3-door models only)
Page 99 3-3. Adjusting the seats Moving front passenger’s seat for rear seat entry (3-door models only) Getting in or out the vehicle ■ For easy access to the rear seat, use the seatback lock release lever or seatback angle adjustment lever. When the seatback lock release lever or seatback angle adjustment lever is used, the seat’s original position is memorized, so the seat may be returned to that original position.
Page 100 3-3. Adjusting the seats WARNING ■ When adjusting the seat position ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat. ● Do not put your hands under the seat or near the moving parts to avoid injury.
Page 101: Rear Seats
3-3. Adjusting the seats Rear seats The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Stow the rear seat belt buckles as shown. Stow the seat belts. Center: P. 28 Outer: Use the seat belt hang- ers to prevent the belts from being tangled.
Page 102 3-3. Adjusting the seats Pull the seatback lock release knob and fold the seatback down. Each seatback may be folded sep- arately. Returning the rear seatbacks Lift up the seatback until it locks. Remove the outside seat belt from the seat belt hanger. WARNING ■...
Page 103 3-3. Adjusting the seats WARNING ■ After returning the rear seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure that the seatback is securely locked in position by lightly pushing it back and forth.
Page 104: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Adjusting the front seats and rear center seat head restraints Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button ■...
Page 105 3-3. Adjusting the seats ■ Installing the front seats and rear center seat head restraints Align the head restraint with installation holes and push it down to the lock posi- tion. Press and hold the lock release button when lowering the head restraint. Lock release button...
Page 106 3-3. Adjusting the seats WARNING ■ Head restraint precautions Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. ● Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 107: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel. After adjustment, pull the lever up to secure the steering wheel. Horn To sound the horn, press on or close to the...
Page 108 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. ■...
Page 109: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 110 3-4. Adjusting the steering wheel and mirrors WARNING ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 111: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure Manually-adjustable type  Adjust the mirror up, down, in or out by pushing the mirror surface. Power-adjustable type  To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the...
Page 112 3-4. Adjusting the steering wheel and mirrors Folding the mirrors Push the mirror back in the direc- tion of the vehicle’s rear. ■ Mirror angle can be adjusted when (power-adjustable type) The engine switch is in the “ACC” or “ON” position. ■...
Page 113: Opening And Closing
3-5. Opening and closing the windows Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing Opening One-touch opening (driver’s window only) : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 114 3-5. Opening and closing the windows ■ The power windows can be operated when The engine switch is in the “ON” position. ■ Operating the power windows after turning the engine The power windows can be operated for approximately 45 seconds even after the engine switch is turned to the “ACC”...
Page 115: Driving
Driving 4-1. Before driving 4-3. Operating the lights and wipers Driving the vehicle..... 116 Headlight switch....144 Cargo and luggage ... 127 Fog light switch ....147 Vehicle load limits ..... 131 Windshield wipers Trailer towing..... 132 and washer ..... 149 Dinghy towing (vehicles Rear window wiper with an automatic...
Page 116: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 136 Driving Vehicles with an automatic transmission  With the brake pedal depressed, shift the shift lever to D. (P. 139) Release the parking brake.
Page 117 4-1. Before driving Stopping Vehicles with an automatic transmission  With the shift lever in D, depress the brake pedal. If necessary, set the parking brake. If the vehicle is to be stopped for an extended period of time, shift the shift lever to P or N.
Page 118 4-1. Before driving Vehicles with a manual transmission  While depressing the clutch pedal, depress the brake pedal. Set the parking brake. (P. 143) Shift the shift lever to N. (P. 141) If parking on a hill, shift the shift lever to 1 or R and block the wheels as needed.
Page 119 The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 120 4-1. Before driving ■ Eco-friendly driving (vehicles with an automatic transmission) During Eco-friendly acceleration opera- tion (Eco driving), Eco Driving Indicator Light will turn on. When the accelerator pedal is depressed excessively, and when the vehicle is stopped, the light turns off. Eco Driving Indicator Light will not operate in the following conditions: ●...
Page 121 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not drive the vehicle over or stop the vehicle near flammable materials. The exhaust system and exhaust gases can be extremely hot. These hot parts may cause a fire if there is any flammable material nearby.
Page 122 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces ● Sudden braking, acceleration and steering may cause tire slippage and reduce your ability to control the vehicle. ●...
Page 123 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 124 4-1. Before driving WARNING ● Do not attach adhesive discs to the windshield or windows. Do not place containers such as air fresheners on the instrument panel or dashboard. Adhesive discs or containers may act as lenses, causing a fire in the vehi- cle.
Page 125 4-1. Before driving NOTICE ■ When driving the vehicle Vehicles with an automatic transmission  ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 126 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function ●...
Page 127: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 128 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Calculation formula for your vehicle...
Page 129 4-1. Before driving As shown in the example above, if the number of occupants increases, the cargo and luggage load will be reduced by an amount that equals the increased weight due to the additional occupants. In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 130 4-1. Before driving WARNING ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
Page 131: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 132: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the...
Page 133: Dinghy Towing (Vehicles With An Automatic Transmission)
4-1. Before driving Dinghy towing (vehicles with an automatic transmission) Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with the four wheels on the ground.
Page 134: Dinghy Towing (Vehicles With A Manual Transmission)
4-1. Before driving Dinghy towing (vehicles with a manual transmission) Your vehicle can be dinghy towed in a forward direction (with 4 wheels on the ground) behind a motor home. Towing your vehicle with 4 wheels on the ground To prevent damage to your vehicle, perform the following procedures before towing: Shift the shift lever to N.
Page 135 4-1. Before driving NOTICE ■ Dinghy towing direction Do not tow the vehicle backward. Doing so may cause serious damage. ■ To prevent the steering from locking Ensure the engine switch is in the “ACC” position.
Page 136: 4-2. Driving Procedures
4-2. Driving procedures Engine (ignition) switch Starting the engine Check that the parking brake is set. Check that the shift lever is set in P (automatic transmission) or N (manual transmission). Firmly depress the brake pedal (automatic transmission) or brake pedal and clutch pedal (manual transmission).
Page 137 ■ If the engine does not start (vehicles with an engine immobilizer system) The engine immobilizer system may not have been deactivated. (P. 67) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 138 Do not crank the engine for more than 30 seconds at a time. This may overheat the starter and wiring system. ● Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately.
Page 139: Automatic Transmission
4-2. Driving procedures  Automatic transmission Shifting the shift lever While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 140 4-2. Driving procedures ■ Downshift restriction The maximum allowable speeds are as follows. Downshifting Maximum speed mph (km/h) D3 84 (135) 32 53 (85) 2L 25 (40) ■ AI-SHIFT AI-SHIFT automatically selects the suitable gear according to driver perfor- mance and driving conditions. AI-SHIFT automatically operates when the shift lever is in the D position.
Page 141: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 142: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operation instructions Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
Page 143: Parking Brake
4-2. Driving procedures Parking brake Operation instructions To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button. Except Canada Canada...
Page 144: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. Operation instructions Turning the end of the lever turns on the lights as follows: Type A  Vehicles with daytime run- ning light system: The daytime running lights turn on.
Page 145 4-3. Operating the lights and wipers Type B  Vehicles with daytime run- ning light system: The daytime running lights turn on. (P. 146) The side marker, park- ing, tail, license plate, daytime running lights (if equipped) (P. 146) instrument panel lights turn on.
Page 146 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 147: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operation instructions Type A  Turns the front fog lights Turns the front fog lights ...
Page 148 4-3. Operating the lights and wipers Type B  Turns the front fog lights Turns the front fog lights ■ Fog lights can be used when The headlights are on in low beam.
Page 149: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operate the lever as follows to operate the wipers. Type A  Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer/wiper dual operation The wipers will automatically oper-...
Page 150 4-3. Operating the lights and wipers Type B  Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer/wiper dual operation The wiper will automatically operate a couple of times after the washer squirts. ■...
Page 151 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 152: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Operation instructions Turning the end of the lever turns on the rear window wiper and washer. Vehicles without intermittent rear wiper (Type A)  Normal window wiper operation Washer/wiper dual oper- ation Washer operation...
Page 153 4-3. Operating the lights and wipers Vehicles without intermittent rear wiper (Type B)  Normal window wiper operation Washer/wiper dual oper- ation Washer operation Vehicles with intermittent rear wiper (Type A)  Intermittent window wiper operation Normal window wiper operation Washer/wiper dual oper- ation Washer/wiper dual oper-...
Page 154 Do not operate the switch continually as the washer fluid pump may over- heat. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
Page 155: Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Turn the engine switch to the “LOCK” position and ensure that all the doors and windows are closed. ●...
Page 156 Do not top off the fuel tank. ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 157 4-4. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’s painted surface.
Page 158: Using The Driving Support
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 159 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 160 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 161 4-5. Using the driving support systems WARNING ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 162: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supple- mentary and should not be relied upon too heavily when operat- ing the vehicle.
Page 163 4-5. Using the driving support systems When the TRAC/VSC systems are operating The slip indicator will flash while the TRAC/VSC systems are oper- ating. Disabling the TRAC system If the vehicle gets stuck in mud, dirt or snow, the TRAC system may reduce power from the engine to the wheels.
Page 164 ■ When the “TRAC OFF” indicator comes on even if the VSC OFF switch has not been pressed TRAC system cannot be operated. Contact your Toyota dealer. ■ Sounds and vibrations caused by the ABS, brake assist, TRAC and VSC systems ●...
Page 165 The EPS system should return to normal within 10 minutes. ■ If the slip indicator comes on It may indicate a malfunction in the systems. Contact your Toyota dealer. WARNING ■ The ABS does not operate effectively when ●...
Page 166 The ABS, TRAC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension...
Page 167: Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 168 4-6. Driving tips When driving the vehicle Accelerate the vehicle slowly, keep a safe distance between you and the vehicle ahead, and drive at a reduced speed suitable to road con- ditions. When parking the vehicle Park the vehicle and move the shift lever to P (automatic transmis- sion) or 1 or R (manual transmission) without setting the parking brake.
Page 169 4-6. Driving tips ■ Tire chain installation Observe the following precautions when installing and removing chains: ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the rear tires.
Page 170 Repairing or replacing snow tires (vehicles with a tire pressure warn- ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 171: Interior Features
Interior features 5-1. Using the air conditioning system and defogger Air conditioning system ..172 5-2. Using the audio system Steering wheel audio switches ......180 AUX port/USB port.... 181 5-3. Using the interior lights Interior lights list ....182 •...
Page 172: Air Conditioning System
5-1. Using the air conditioning system and defogger Air conditioning system Air conditioning controls Vehicles without a cooling and dehumidification on/off button  Air outlet selector dial Rear window defogger switch Fan speed control dial Outside/recirculated air mode button Temperature control dial...
Page 173 5-1. Using the air conditioning system and defogger Vehicles with a cooling and dehumidification on/off button  Rear window defogger switch Air outlet selector dial Fan speed control dial Outside/recirculated air mode button Temperature control dial Cooling and dehumidification on/off button...
Page 174 5-1. Using the air conditioning system and defogger Adjusting the temperature setting ■ Vehicles without the button  Turn the temperature control dial clockwise to increase the temper- ature. Vehicles with the button  To adjust the temperature setting, turn the temperature control dial clockwise (warm) or counterclockwise (cool).
Page 175 5-1. Using the air conditioning system and defogger Other functions ■ ● Switching between outside air and recirculated air modes (P. 175) ● Defogging the windshield (P. 175) ● Defogging the rear window and outside rear view mirrors (P. 176) Other functions Switching between outside air and recirculated air modes ■...
Page 176: Air Outlets
5-1. Using the air conditioning system and defogger Defogging the rear window and outside rear view mirrors ■ Vehicles with a rear window defogger  Defogger is used to defog the rear window. Press The defogger will automatically turn off after a period of time. Vehicles with rear window and outside rear view mirror defoggers ...
Page 177 5-1. Using the air conditioning system and defogger Adjusting the position, opening and closing the air outlets ■ Front center outlets  Direct air flow to the left or right, up or down. Turn the knob to open or close the vent. Front side outlets ...
Page 178 5-1. Using the air conditioning system and defogger ■ Fogging up of the windows ● Vehicles with the button: The windows will easily fog up when the humidity in the vehicle is high. Turning on will dehumidify the air from the outlets and defog the windshield effectively.
Page 179 5-1. Using the air conditioning system and defogger WARNING ■ To prevent the windshield from fogging up Do not set the air outlet selector dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 180: 5-2. Using The Audio System
5-2. Using the audio system  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 181: Aux Port/Usb Port
5-2. Using the audio system  AUX port/USB port This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Connecting using the AUX port/USB port Open the cover and connect the portable audio device.
Page 182: 5-3. Using The Interior Lights
5-3. Using the interior lights Interior lights list Interior light (P. 182) Personal lights (P. 183) Interior light Door position...
Page 183: Personal Lights
5-3. Using the interior lights Personal lights ■ Illuminated entry system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are opened/ closed. ■ To prevent the battery from being discharged ●...
Page 184: 5-4. Using The Storage Features
5-4. Using the storage features List of storage features Glove box (P. 185) Bottle holders (P. 186) Cup holders (P. 185) Auxiliary box (P. 187) WARNING ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may result in the following when cabin temperature becomes high: ●...
Page 185: Glove Box
5-4. Using the storage features Glove box Pull up the lever to open the glove box. WARNING ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
Page 186: Bottle Holders
5-4. Using the storage features WARNING ■ Items unsuitable for the cup holders ● Do not place anything other than cups or aluminum cans in the cup hold- ers. Other items may be thrown out of the holders in the event of an acci- dent or sudden braking, causing injury.
Page 187: Auxiliary Box
5-4. Using the storage features Auxiliary box Type A Type B   Open the cover. Type C  WARNING ■ Caution while driving (Type B) Keep the auxiliary boxes closed. In the event of sudden braking, an acci- dent may occur due to an occupant being struck by an open auxiliary box or the items stored inside.
Page 188: Luggage Compartment Features
5-4. Using the storage features Luggage compartment features Luggage cover The luggage cover can be removed by the following procedure: Unhook the cords and return the luggage cover to horizontal position. Lift the luggage cover and pull it toward you to remove it.
Page 189 5-4. Using the storage features Deck board (if equipped) Deck board height adjustment ■ Upper position Lower position The lower position can be used when the deck board is placed on the luggage floor cover. Removing the deck board ■ Lift up the deck board and pull it toward you to remove it.
Page 190: Using The Other Interior Features
5-5. Using the other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 191: Power Outlet
5-5. Using the other interior features Power outlet Please use as a power supply for electronic goods that use less than 12 VDC/10 A (power consumption of 120 W). Open the lid. ■ The power outlets can be used when The engine switch is in the “ACC”...
Page 192: Assist Grips
5-5. Using the other interior features Assist grips An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING ■ Assist grip Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 193: Maintenance And Care
Maintenance and care 6-1. Maintenance and care Cleaning and protecting the vehicle exterior..194 Cleaning and protecting the vehicle interior... 197 6-2. Maintenance Maintenance requirements ....200 General maintenance..202 Emission inspection and maintenance (I/M) programs......205 6-3. Do-it-yourself maintenance Do-it-yourself service precautions .....
Page 194: Maintenance And Care Cleaning And Protecting
6-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 195 6-1. Maintenance and care ■ Aluminum wheels (if equipped) ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical clean- ers. Use the same mild detergent and wax as used on the paint. ●...
Page 196 6-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 197: Cleaning And Protecting The Vehicle Interior
6-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 198 6-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 199 6-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 200: Maintenance Maintenance Requirements
■ Repair and replacement It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war-...
Page 201 Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 202: General Maintenance
“Owner’s Warranty Information Booklet” or “Owner’s Manual Supplement/Sched- uled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment...
Page 203: Vehicle Interior
6-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly Accelerator pedal (without uneven pedal effort or catching). Automatic transmis- • When parked on a slope and the shift lever is in P, sion “Park” mecha- is the vehicle securely stopped? nism •...
Page 204: Vehicle Exterior
6-2. Maintenance Items Check points • Do the seat belts operate smoothly? Seat belts • The seat belts should not be damaged. Seats • Do the seat controls operate properly? • Does the steering wheel rotate smoothly? • Does the steering wheel have the correct amount Steering wheel of free play? •...
Page 205: Emission Inspection And Maintenance (I/M) Programs
The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situations: ●...
Page 206: 6-3. Do-It-Yourself Maintenance
• Rag or paper towel (P. 218) • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- life hybrid organic acid technology Except Canada ...
Page 207 6-3. Do-it-yourself maintenance Items Parts and tools Fuses • Fuse with same amperage rating as original (P. 243) • Bulb with same number and wattage rating as origi- Light bulbs • Phillips-head screwdriver (P. 248) • Flathead screwdriver • Wrench Radiator and ...
Page 208 6-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing and tools away from the moving fan and engine drive belt.
Page 209: Hood
6-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 210 6-3. Do-it-yourself maintenance WARNING ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 211: Positioning A Floor Jack
6-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safety. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 212 6-3. Do-it-yourself maintenance NOTICE ■ When raising your vehicle Do not jack the vehicle at the suspen- sion. The suspension may be damaged. Suspension Front...
Page 213: Engine Compartment
6-3. Do-it-yourself maintenance Engine compartment Fuse boxes (P. 243) Condenser (P. 218) Engine oil filler cap Electric cooling fan (P. 215) Engine coolant reservoir Battery (P. 219) (P. 216) Brake fluid reservoir Engine oil level dipstick (P. 218) (P. 214) Radiator (P.
Page 214 6-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 215 6-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 216: Engine Coolant
Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
Page 217 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. WARNING ■...
Page 218 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If any of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 219 6-3. Do-it-yourself maintenance WARNING ■ When filling the reservoir Take care as brake fluid can harm your hands and eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 220 6-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, observe the following before recharging: ● If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable. ●...
Page 221: Washer Fluid
6-3. Do-it-yourself maintenance WARNING ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 222 6-3. Do-it-yourself maintenance WARNING ■ When adding washer fluid Do not add washer fluid when the engine is hot or running as washer fluid contains alcohol and may catch fire if spilled on the engine, etc. NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid.
Page 223: Tires
6-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 224 6-3. Do-it-yourself maintenance Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recommends that tire rotation is carried out at the same interval as tire inspection. Front Vehicles with P195/50R16 tires:...
Page 225 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. Have the ID code registered by your Toyota dealer.
Page 226 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with a tire pressure warning...
Page 227 6-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
Page 228 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ● When operating the tire pressure warning reset switch, the tire pressure warning light does not blink 3 times.
Page 229 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 230 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 231: Tire Inflation Pressure
6-3. Do-it-yourself maintenance Tire inflation pressure The recommended cold tire infla- tion pressure and tire size are dis- played on the tire and loading information label. (P. 315)
Page 232 6-3. Do-it-yourself maintenance Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the gauge gradations. If the tire inflation pressure is not at the recommended level, adjust the pressure.
Page 233 Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 234 6-3. Do-it-yourself maintenance WARNING ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: ●...
Page 235: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 236 6-3. Do-it-yourself maintenance ■ When replacing wheels (vehicles with a tire pressure warning sys- tem) The wheels of your vehicle, except for the compact spare tire, are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure.
Page 237 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 238: Air Conditioning Filter
6-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch to the “LOCK” position. Open the glove box and slide off the damper. Push in each side of the glove box to disconnect the upper claws.
Page 239 6-3. Do-it-yourself maintenance Remove the filter cover. Remove the air conditioning fil- ter and replace it with a new one. The “UP” marks shown on the fil- ter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 240: Wireless Remote Control Battery
6-3. Do-it-yourself maintenance  Wireless remote control battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Lithium battery CR2016 Replacing the battery Type A  Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a tape.
Page 241 6-3. Do-it-yourself maintenance Type B  Remove the cover. To prevent damage to the key, cover the tip of the screwdriver with a tape. To prevent the buttons from being disassembled, face the button sur- face downward. Remove the module. Open the case cover and remove the depleted battery.
Page 242 6-3. Do-it-yourself maintenance ■ Use a CR2016 lithium battery ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. ● Replace only with the same or equivalent type recommended by the manu- facturer. ●...
Page 243: Checking And Replacing Fuses
6-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch to the “LOCK” position. Open the fuse box cover.
Page 244 6-3. Do-it-yourself maintenance Engine compartment: type C fuse box  Pull the rubber strip on the edge to unhook it from the cover, and then push the tabs in and lift the cover off. Remove the battery terminal cover and then the fuse box cover.
Page 245 From Type A to E: Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type F: Contact your Toyota dealer. Type A Type B ...
Page 246 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 248) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. ■ If there is an overload in a circuit The fuses are designed to blow, protecting the wiring harness from damage.
Page 247 6-3. Do-it-yourself maintenance NOTICE ■ Before replacing fuses Have the cause of electrical overload determined and repaired by your Toy- ota dealer as soon as possible.
Page 248: Light Bulbs
Toy- ota dealer. For more information about replacing other light bulbs, contact your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 316)
Page 249 6-3. Do-it-yourself maintenance Rear ■ Back-up lights Rear turn signal lights License plate lights Stop/tail and rear side marker lights Replacing light bulbs Headlights and daytime running lights (if equipped) ■ Reflector type  Unplug the connector. Remove the rubber cover.
Page 250 6-3. Do-it-yourself maintenance Release the bulb retaining spring. Remove the bulb. When installing a new bulb, align tabs of the bulb with the cutouts of the mounting hole. To install, reverse the steps listed. Projector type  Turn the bulb base counter- clockwise.
Page 251 6-3. Do-it-yourself maintenance Replace the light bulb, and install the bulb base. Align the 3 tabs on the light bulb with the mounting and insert. Turn and secure the bulb base. Shake the bulb base gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting.
Page 252 6-3. Do-it-yourself maintenance Partly remove the fender liner. Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise and remove. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 253 6-3. Do-it-yourself maintenance Turn and secure the bulb. Install the connector. Shake the bulb base gently to check that it is not loose, turn the front fog light, on once and visually confirm that no light is leaking through the mounting. When installing the fender liner, install by starting and the directions reversed.
Page 254 6-3. Do-it-yourself maintenance Front turn signal lights/parking lights ■ Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed.
Page 255 6-3. Do-it-yourself maintenance Stop/tail and rear side marker lights, and rear turn signal lights ■ Open the back door and remove the cover. To prevent damaging the vehi- cle, wrap the screwdriver with a tape. Turn the bulb base counter- clockwise.
Page 256 6-3. Do-it-yourself maintenance Turn and secure the bulb base. Stop/tail and rear side marker lights Rear turn signal light Install the cover. License plate light ■ Remove the cover. Insert a properly sized screw- driver into the hole of the cover, and ply off the cover as shown in the illustration.
Page 257 6-3. Do-it-yourself maintenance Install the new bulb. Install the cover. Insert a properly sized screw- driver into one of the holes, push the screwdriver until click- ing sound is heard. Repeat for the other hole. Make sure that the cover is secured by pressing on the entire cover.
Page 258 Back-up light ■ Turn the bulb base counter- clockwise. Remove the light bulb When installing, reverse the steps listed. Lights other than the above ■ If the high mounted stoplight has burnt out, have it replaced by your Toyota dealer.
Page 259 ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water have built up on the inside of the lens.
Page 260 6-3. Do-it-yourself maintenance...
Page 261: When Trouble Arises
When trouble arises 7-1. Essential information Emergency flashers ..262 If your vehicle has to be stopped in an emergency ....263 7-2. Steps to take in an emergency If your vehicle needs to be towed ......265 If you think something is wrong ......
Page 262: Emergency Flashers
7-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 263: If Your Vehicle Has To Be Stopped In An Emergency
7-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 264 7-1. Essential information WARNING ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 265: Steps To Take In
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 266 7-2. Steps to take in an emergency Towing with a wheel-lift type truck From the front From the rear   Release the parking brake. Use a towing dolly under the front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the illustration.
Page 267 7-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 50 miles (80 km) at under 18 mph (30 km/h).
Page 268 7-2. Steps to take in an emergency Tighten down the towing eyelet securely using a wheel nut wrench or hard metal bar. Securely attach cables or chains to the towing eyelet. Take care not to damage the vehicle body. Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to the “ON”...
Page 269 7-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with the front wheels raised or with all four wheels raised off the ground.
Page 270: If You Think Something Is Wrong
7-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal) ●...
Page 271: Fuel Pump Shut Off System
7-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 272: If A Warning Light Turns On Or A Warning Buzzer Sounds
 Immediately stop the vehicle in a safe place and con- (Canada) tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Page 273 Indicates a malfunction in: • The electronic engine control system; (Except Canada) • The electronic throttle control system; • The electronic automatic transmission control system.  Have the vehicle inspected by your Toyota dealer (Canada) immediately. SRS warning light Indicates a malfunction in: •...
Page 274 Warning light Warning light/Details/Actions Cruise control indicator Indicates a malfunction in the cruise control system.  Have the vehicle inspected by your Toyota dealer (Yellow) immediately. Open door warning light (warning buzzer) Indicates that one or more of the doors is not fully closed.
Page 275 7-2. Steps to take in an emergency Warning light Warning light/Details/Actions Maintenance required reminder light (except Canada) Indicates that maintenance is required according to the driven distance on the maintenance schedule. Illuminates for about 3 seconds and then flashes for about 15 seconds approximately 4500 miles (7200 km) after the reminder light has been reset.
Page 276 The malfunction indicator lamp will go off after several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. ■ When the tire pressure warning light comes on (vehicles with a tire pressure warning system) Check the tire inflation pressure and adjust to the appropriate level.
Page 277 If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel housings ● If non-genuine Toyota wheels are used (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 278 Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled. (Customizable features P. 333) However, Toyota recommends that the seat belt reminder buzzer be operational to alert the driver and front passenger when seat belts are not fastened.
Page 279 7-2. Steps to take in an emergency WARNING ■ Maintenance of the tire (vehicles with a tire pressure warning sys- tem) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 280 7-2. Steps to take in an emergency WARNING Your vehicle has also been equipped with a TPMS (tire pressure warn- ing system) malfunction indicator to indicate when the system is not operating properly. The TPMS (tire pressure warning system) malfunc- tion indicator is combined with the low tire pressure telltale (tire pressure warning light).
Page 281: If You Have A Flat Tire
7-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 223 WARNING ■ If you have a flat tire Do not continue driving with a flat tire.
Page 282 7-2. Steps to take in an emergency Location of the spare tire, jack and tool bag Location ■ Jack Tie-down belt Spare tire Wheel nut wrench Tool bag Towing eyelet Jack handle Luggage floor cover...
Page 283 7-2. Steps to take in an emergency WARNING ■ Using the tire jack Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 284 7-2. Steps to take in an emergency Taking out the jack Move the driver’s seat to the front most position and remove the cover. Take out the jack. For tightening For loosening Taking out the spare tire Lift the deck board and pull it toward you to remove it. (P. 189) Remove luggage floor...
Page 285 7-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 286 7-2. Steps to take in an emergency Turn the tire jack portion hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel. They indicate the jack point positions. Raise the vehicle until the tire is slightly raised off the ground.
Page 287 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the...
Page 288 7-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 289 7-2. Steps to take in an emergency Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 76 ft·lbf (103 N·m, 10.5 kgf·m) Do not use other tools or any additional leverage other than your hands, such as a hammer, pipe or your foot.
Page 290 7-2. Steps to take in an emergency Lay the flat tire on the luggage floor so that the outer side of the tire wheel faces toward the rear of the vehicle. Detach the rear center head restraint from the seat and release the belt. Pass the belt through the center hole of the flat tire wheel.
Page 291 7-2. Steps to take in an emergency ■ The compact spare tire ● The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall. Use the compact spare tire temporarily, and only in an emergency. ●...
Page 292 7-2. Steps to take in an emergency WARNING ■ When using the compact spare tire ● Remember that the compact spare tire provided is specifically designed for use with your vehicle. Do not use your compact spare tire on another vehicle. ●...
Page 293 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 294: If The Engine Will Not Start
7-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 136), consider each of the follow- ing points: The engine will not start even though the starter motor operates normally.
Page 295 ● The battery may be discharged. (P. 297) ● There may be a malfunction in the steering lock system (vehicles with a smart entry & start system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 296: If The Shift Lever Cannot Be Shifted From P (Vehicles With An Automatic Transmission)
(a sys- tem to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 297: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 298 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. ■...
Page 299 7-2. Steps to take in an emergency WARNING ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: ● Make sure each jumper cable is connected to the correct terminal and that it is not unintentionally in contact with anything other than the intended ter- minal.
Page 300: If Your Vehicle Overheats
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the “FULL” and “LOW” lines on the reservoir.
Page 301 (The fan may not operate in freezing temperatures.) If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 302 7-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Add coolant slowly after the engine has cooled down sufficiently. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■ To prevent damage to the cooling system Observe the following precautions: ●...
Page 303: If The Vehicle Becomes Stuck
7-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P (automatic transmission) or N (manual transmission).
Page 304 7-2. Steps to take in an emergency WARNING ■ When attempting to free a stuck vehicle If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 305 Vehicle specifications 8-1. Specifications Maintenance data (fuel, oil level, etc.) ..306 Fuel information ....317 Tire information ....320 8-2. Customization Customizable features ..333 Items to initialize ....335...
Page 306: 8-1. Specifications
8-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 155.5 in. (3950 mm) Overall width 66.7 in. (1695 mm) Overall height 59.4 in. (1510 mm) Wheelbase 98.8 in. (2510 mm) 58.5 in. (1485 mm) Front 57.5 in. (1460 mm) Tread 57.9 in.
Page 307 8-1. Specifications Vehicle identification Vehicle identification number ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toy- ota. It is used in registering the ownership of your vehicle. This number is stamped under the front passenger’s seat.
Page 308 8-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown.
Page 309 8-1. Specifications Engine Model 1NZ-FE Type 4-cylinder in line, 4-cycle, gasoline 2.95  3.33 in. (75.0  84.7 mm) Bore and stroke Displacement 91.3 cu.in. (1497 cm 68 — 90 lbf (300 — 400 N, 31 — 41kgf) Vehicles without an air conditioning system ...
Page 310: Lubrication System
Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 311: Cooling System
(Reference) Manual transmission  5.0 qt. (4.7 L, 4.1 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non- borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 312: Ignition System
: The fluid capacity is the reference quantity. If replacement is necessary, contact your Toyota dealer. NOTICE ■ Transmission fluid type Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of the transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission.
Page 313 Please be aware that depending on the particular characteristics of the gear oil used or the operating conditions, idle sound, shift feeling and/or fuel effi- ciency may be different or affected. Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil LV” to achieve optimal perfor- mance.
Page 314 8-1. Specifications Brakes Rear drum brakes  3.2 in. (81 mm) Min. Pedal clearance Rear disc brakes  3.3 in. (84 mm) Min. Pedal free play 0.04 — 0.24 in. (1 — 6 mm) Brake pad wear limit 0.04 in. (1.0 mm) Brake lining wear limit 0.04 in.
Page 315 8-1. Specifications Tires and wheels 15-inch tires  Tire size P175/65R15 84H Driving under normal conditions Front: Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold Rear: tire inflation pressure) 33 psi (230 kPa, 2.3 kgf/cm or bar) Never exceed the maximum cold tire inflation pressure indicated on the tire sidewall.
Page 316 8-1. Specifications Light bulbs Light Bulbs Bulb No Type Headlights and daytime running lights (if equipped) Type A 9003 60/55 Type B — Front fog lights (if equipped) — Front side marker lights — Front turn signal lights/ Exterior 7444NA 28/8 parking lights Rear turn signal lights...
Page 317: Fuel Information
In very few cases, driveability problems may be caused by the brand of gaso- line you are using. If driveability problems persist, try changing the brand of gasoline. If this does not correct the problem, consult your Toyota dealer. ■...
Page 318 Non-recommendation of the use of gasoline containing MMT Some gasoline contains an octane enhancing additive called MMT (Methylcy- clopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 319 8-1. Specifications ■ If your engine knocks ● Consult your Toyota dealer. ● You may occasionally notice light knocking for a short time while accelerat- ing or driving uphill. This is normal and there is no need for concern. NOTICE ■...
Page 320: Tire Information
8-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire ...
Page 321 8-1. Specifications Tire size (P. 322) DOT and Tire Identification Number (TIN) (P. 322) Location of treadwear indicators (P. 223) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Uniform tire quality grading For details, see “Uniform Tire Quality Grading”...
Page 322 8-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
Page 323 8-1. Specifications Tire dimensions ■ Section width Tire height Wheel diameter Tire section names Bead Sidewall Shoulder Tread Belt Inner liner Reinforcing rubber Carcass Rim lines Bead wires Chafer...
Page 324 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 325 8-1. Specifications Traction AA, A, B, C ■ The traction grades, from highest to lowest, are AA, A, B and C, and they represent the tire’s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete.
Page 326 8-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation parked for three hours or more, or has not pressure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which Maximum inflation...
Page 327 8-1. Specifications Tire related term Meaning Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb. (2.3 kg) in excess of the standard items which they Production options replace, not previously considered in curb...
Page 328 8-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between compo- Bead separation...
Page 329 8-1. Specifications Tire related term Meaning The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same...
Page 330 8-1. Specifications Tire related term Meaning The linear distance between the exteriors of the sidewalls of an inflated tire, including ele- Overall width vations due to labeling, decorations, or protec- tive bands or ribs A tire intended for use on passenger cars, multipurpose passenger vehicles, and trucks, Passenger car tire that have a gross vehicle weight rating...
Page 331 8-1. Specifications Tire related term Meaning A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in Snow tire ASTM F-1805-00, Standard Test Method for Single Wheel Driving Traction in a Straight Line on Snow-and Ice-Covered Surfaces, and...
Page 332 8-1. Specifications : Table 1 — Occupant loading and distribution for vehicle normal load for various designated seating capacities Designated seating Occupant distribution Vehicle normal load, capacity, Number of in a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10...
Page 333: Customization
Toyota dealer. Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Wireless remote control (P. 85, 89) ■ Customized...
Page 334 8-2. Customization Seat belt reminder buzzer (P. 274) ■ Customized Function Default setting setting Vehicle speed linked seat belt reminder buzzer WARNING ■ During customization As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 335: Items To Initialize
8-2. Customization Items to initialize The following items must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Maintenance required After the maintenance reminder light P.
Page 336 8-2. Customization...
Page 337: For Owners
For owners Reporting safety defects for U.S. owners......338 Seat belt instructions for Canadian owners (in French) ....... 339 SRS airbag instructions for Canadian owners (in French) ......341...
Page 338: Reporting Safety Defects For U.s. Owners
National Highway Traffic Safety Administration (NHTSA) in addi- tion to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800- 331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 339: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 340 AVERTISSEMENT ■ Port de la ceinture de sécurité ● Ne pas passer la sangle diagonale sous le bras. ● Faites toujours passer votre ceinture de sécurité au plus bas sur vos hanches et bien dans l’axe. ■ Dommages et usure de la ceinture de sécurité Inspectez les ceintures de sécurité...
Page 341: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian own- ers (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English.
Page 342 ◆ Coussins gonflables SRS frontaux Coussins gonflables SRS conducteur/passager avant Participent à la protection de la tête et du thorax du conducteur et du passager avant contre les chocs avec les éléments de l’habita- Coussin gonflable SRS de genoux conducteur Contribue à...
Page 343 Composition du système de coussins gonflables SRS Coussins gonflables rideau Coussin gonflable d’assise de siège Capteurs d’impact latéral (avant) Contacteur de boucle de cein- ture de sécurité conducteur Coussins gonflables latéraux Coussin gonflable de genoux Capteurs d’impact latéral conducteur (arrière) Capteurs d’impact avant Témoin d’alerte SRS Boîtier électronique de cous-...
Page 344 Votre véhicule est équipé de COUSSINS GONFLABLES INTELLI- GENTS (ADVANCED AIRBAGS) conçus selon les normes de sécu- rité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique de coussins gonflables (ECU) utilise les informa- tions reçues des capteurs, etc. détaillés dans le schéma ci-dessus de composition du système pour commander le déploiement des cous- sins gonflables.
Page 345 AVERTISSEMENT ■ Précautions avec les coussins gonflables SRS Respectez les précautions suivantes concernant les coussins gonflables SRS. À défaut, des blessures graves, voire mortelles, pourraient s’ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité...
Page 346 Installez dans un siège de sécurité enfant les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité. Toyota recommande vivement que tous les nourrissons et enfants soient installés dans les sièges arrière du véhicule et convenablement attachés.
Page 347 AVERTISSEMENT ■ Précautions avec les coussins gonflables SRS ● Ne pas laisser un enfant rester debout devant le coussin gonflable SRS pas- sager avant ni assis sur les genoux du passager avant. ● Ne pas laisser les occupants des sièges avant voyager avec un objet sur les genoux.
Page 348 AVERTISSEMENT ■ Précautions avec les coussins gonflables SRS ● Ne rien fixer aux portes, à la vitre de pare-brise, aux vitres latérales, aux montants avant et arrière, au rail latéral de toit et à la poignée de maintien. ● Ne pas attacher à la clé des objets lourds, pointus ou très durs, comme d’autres clés par exemple.
Page 349 Modification et élimination en fin de vie des éléments du système de coussins gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d’intervenir sur votre véhicule ou de procéder à l’une des modifica- tions suivantes. Les coussins gonflables SRS peuvent ne pas fonctionner correctement ou se déployer (se gonfler) accidentellement, provoquant...
Page 351: Index
Index What to do if... (Troubleshooting) ....352 Alphabetical index ..... 355...
Page 352 Toyota dealer. The doors cannot be locked, unlocked, opened or closed You lose your keys ● If you lose your keys, new genuine keys can be made by your Toyota dealer. (P. 86) The doors cannot be locked or unlocked ●...
Page 353 What to do if... (Troubleshooting) If you think something is wrong The engine does not start ● Vehicles with a manual transmission: Did you turn the key while firmly depressing the clutch pedal? (P. 136) ● Vehicles with an automatic transmission: Is the shift lever in P? (P.
Page 354 What to do if... (Troubleshooting) A warning buzzer sounds during driving ● The seat belt reminder light is flashing Is the driver wearing the seat belts? (P. 274) ● The parking brake indicator is on Is the parking brake released? (P. 272) Depending on the situation, other types of warning buzzer may also sound.
Page 355: Alphabetical Index
Alphabetical index Alphabetical index Anchor brackets ......58 Anti-lock Brake System A/C ..........172 (ABS) ........162 Air conditioning filter ..... 238 Function........ 162 Manual air conditioning Warning light......273 system ........ 172 Assist grips......192 ABS (Anti-lock Brake Audio input ......181 System) ........
Page 356 Alphabetical index Back door Care ........194, 197 Back door........ 94 Aluminum wheels ....195 Luggage compartment Exterior ......... 194 light........95 Interior ........197 Back-up lights Seat belts......198 Replacing light bulb ....258 Chains ........168 Wattage ........ 316 Child restraint system....
Page 357 Alphabetical index Clock........... 80 Clutch ........313 Defogger Condenser........ 218 Outside rear view mirrors ..176 Coolant ........216 Rear window......176 Capacity........ 311 Windshield ......175 Checking....... 216 Dimensions ......306 Preparing and checking Display before winter....... 167 Drive information ....79 Cooling system......
Page 358 Alphabetical index Engine “ACC” position ...... 136 Eco Driving Indicator Light..120 Compartment......213 Electric Power Steering Engine switch ....... 136 (EPS)........162 Hood ........209 Function ........ 162 How to start the engine..136 Warning light......273 Identification number .... 308 Emergency flashers ....
Page 359 Alphabetical index Fuel Capacity........ 310 Flat tire........281 Fuel gauge......76 Floor mats ........22 Fuel pump shut off system ... 271 Fluid Information......317 Automatic transmission..312 Refueling ......155 Brake ........314 Type......156, 310 Clutch........313 Warning light......274 Washer .........
Page 360 Alphabetical index Gas station information ..368 Identification ......307 Gauges ........76 Engine ........308 Glove box ......... 185 Vehicle........307 Ignition switch (engine switch)...... 136 Illuminated entry system ..183 Hazard lights Immobilizer system ....67 Switch ........262 Indicators ........
Page 361 Alphabetical index Keyless entry LATCH anchors ......58 Wireless remote control ..85 Lever Keys ..........84 Auxiliary catch lever....209 Engine switch......136 Hood lock release lever ..209 If you lose your keys ....86 Shift lever...... 139, 141 Ignition switch .......
Page 362 Alphabetical index Maintenance Odometer ........79 Do-it-yourself maintenance... 206 Maintenance data ....306 Engine oil......310 Maintenance requirements ... 200 Manual transmission oil ..313 Malfunction indicator lamp..273 Opener Manual transmission....141 Back door ....... 94 Oil ......... 313 Fuel filler door.......
Page 363 Alphabetical index Parking brake......143 Radiator........218 Operation ......143 Rear seat ........101 Parking brake engaged Folding down the rear warning buzzer ....272 seatbacks ......101 Personal lights......183 Rear side marker lights... 144 Switch ........183 Light switch......144 Wattage ........
Page 364 Alphabetical index Shift lever ......139, 141 Automatic transmission ..139 Seat belt reminder light... 274 If the shift lever cannot Seat belts........26 be shifted from P ....296 Child restraint system Manual transmission..... 141 installation ......57 Shift lock system..... 296 Cleaning and maintaining Side airbags .......
Page 365 Alphabetical index Switches Audio remote control Tachometer ........ 76 switches......180 Tail lights........144 Cruise control switch..... 158 Light switch......144 Door lock switches....91 Replacing light bulbs .... 255 Emergency flashers switch ... 262 Wattage ........ 316 Engine switch......136 Theft deterrent system Fog light switch .....
Page 366 Alphabetical index Tools ......... 282 Top tether strap ......63 USB port........181 Towing Emergency towing ....265 Dinghy towing ....133, 134 Vanity mirrors ......190 Towing eyelet......267 Vehicle data recordings....7 Trailer towing ......132 Vehicle identification Traction control .......
Page 367 Alphabetical index Washer ......149, 152 Checking....... 221 Warning buzzers Preparing and checking Brake system ......272 before winter ...... 167 Key reminder ......137 Switch ......149, 152 Open door......274 Washing and waxing....194 Seat belt reminder ....274 Weight ........
Page 368: Gas Station Information
GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 209 P. 155 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 209 P. 155 P. 315 Fuel tank capacity 11.1 gal. (42 L, 9.2 Imp.gal.) (Reference) Unleaded gasoline, Octane Rating 87 Fuel type (Research Octane Number 91) or higher...

This manual is also suitable for:

2015 yaris

Toyota Yaris 2016 Owner's Manual

1 For Safety and Security

1-1. for Safe Use

Theft Deterrent System

2 Instrument Cluster

Instrument Cluster Warning Lights and

Operation of each Component

3-1. Key Information

3-3. Adjusting the Seats

Opening and Closing

4 Driving

4-1. before Driving

4-2. Driving Procedures

Refueling

Using the Driving Support

Driving Tips

Interior Features

5-1. Using the Air Conditioning

5-2. Using the Audio System

5-3. Using the Interior Lights

5-4. Using the Storage Features

Using the Other Interior Features

6 Maintenance and Care

Maintenance and Care Cleaning and Protecting

Maintenance Maintenance Requirements

6-3. Do-It-Yourself Maintenance

7 When Trouble Arises

7-1. Essential Information

Steps to Take in

8-1. Specifications

Customization

9 For Owners

Quick Links

Need help?

Questions and answers

Related Manuals for Toyota Yaris 2016

Summary of Contents for Toyota Yaris 2016
