3.2 Specifications:

Protocols : IEEE802.3 10Base-T,IEEE 802.3u 100Base-TX IEEE802.3x
Cables: 10Mbps:3,4,5 CAT twisted pairs. 100Mbps:CAT5 Twisted pair;
Number: 5xRJ45
VLAN: supports port-VLAN and TAG VLAN
Panel: PWR,SYS,LNK/ACT,100M,FDX
Dimension:
Store and forward: full wire speed
MAC table:1K
Buffer:64K
Certification: CE MARK

3.3 Environment and power:

Environment Temp:０~５０ centigrade
Humidity: 5% ~ 95%
Power consumption: く 5W
Power: 100-240VAC，50-60Hz

4. Mechanical structure and indicators

LEDs provide all of information and status of interface of Ethernet switch.
LED
PWR
SYS
LNK / ACT
100M
139.5Wmm x 77Dmm x 28Hmm
LNK/ACT
SYS 100M
PWR FDX
1 2 3 4 5
状态 条件
Fixed on Power is on
Flashing The system is active
Fixed on Link is ok
Flashing Data traffic is working
Fixed on 100Mbps
Off 10Mbps
5
