LB3202 Colibri
1. Plan the installation. In particular, the Brita filter (A) supplied must be used regardless
of mains or tank fill.
2. It must be located between the mains water/Flojet pump outlet and the rear machine
water inlet. If your machine has a metal base cabinet, provision is built in for mounting
the filter via 2 screws prefitted.
For example, the following shows a Brita filter unit (B) installed between the Flojet out-
let (C) and coffee machine inlet (A):
If your machine is not fitted with a base cabinet, the filter must be located in a suitable
place such as below the counter or a nearby cupboard. It can be mounted in any orienta-
tion.
