- Page 1 ATEX / IECEx Zone 2 and 22 UL Class I Division 2 Lumen X7 User Manual 7" Industry Tablet Type B7-A23.-2.../..
- Page 3 Revision 0 / Status: 23 March 2016 Proviso: Subject to technical changes. Changes, mistakes and printing errors do not substantiate any claim to damages. Content Page English 1-61 BARTEC GmbH Contact: Max-Eyth-Straße 16 Phone: +49 7931 597-0 Service-mobilecomputing@bartec.de Download: 97980 Bad Mergentheim...
-
Page 4: Table Of Contents
7" Industry Tablet - Lumen X7 Table of content Type B7-A23.-2…/…….. Basic Safety Information................................1 Information on this User Manual ........................1 1.1.1 Languages ................................. 2 1.1.2 Changes in the document ..........................2 1.1.3 Registered trademarks ............................2 Handling the product ............................2 Intended use .............................. - Page 5 7" Industry Tablet - Lumen X7 Table of content Type B7-A23.-2…/…….. Operation ....................................29 Final inspection ..............................29 Care and cleaning ............................29 6.2.1 Care ................................. 29 6.2.2 Cleaning ................................29 6.2.3 Suitable materials for cleaning ......................... 30 Operation, recommendations and requirements ..................... 31 6.3.1 Basic safety and health protection requirements .....................
- Page 6 - empty -...
-
Page 7: Basic Safety Information
The BARTEC company reserves the right to carry out technical changes at any time. In no event will BARTEC company be responsible or liable for indirect or consequential damages resulting from the use or application of this User Manual. -
Page 8: Languages
1.1.2 Changes in the document BARTEC reserves the right to change the content of this document without notification. No warranty is assumed for the correctness of the information. In cases of doubt, the German safety instructions apply because it is not possible to rule out errors of translation or printing. -
Page 9: Unintended Use
7" Industry Tablet - Lumen X7 Basic Safety Information Type B7-A23.-2…/…….. It is used exclusively in combination with devices which comply with the requirements placed on the overvoltage category I. The admissible operating data of the device used must be considered. 1.3.2 Unintended use Any other use is unintended and may lead to damage and accidents. -
Page 10: Servicing
7" Industry Tablet - Lumen X7 Basic Safety Information Type B7-A23.-2…/…….. 1.6.1 Servicing No constant servicing will be necessary if operated correctly under consideration of the assembly instructions and environmental conditions. See Chapter “Service, inspection, repair” in this respect. 1.6.2 Inspection According to EN/IEC 60079-17 and EN/IEC 60079-19, the operator of electrical systems in potentially explosive atmospheres is obliged to have these inspected by an electrician... -
Page 11: Co-Applicable Documents - Set Of Documents
Cases of disaster through the impact of foreign bodies and force majeure. − The BARTEC company grants a warranty period of three years starting from the date of delivery from the Bad Mergentheim factory on the Industry Tablets (exception: battery 6 months). -
Page 12: Definition Of Terms
7" Industry Tablet - Lumen X7 Basic Safety Information Type B7-A23.-2…/…….. 1.10 Definition of terms A few abbreviations are used in the documentation. Non Incendive => is used as generic term for Zone 2 and Division 2 version Lumen X stands for the entire explosion-protected product series 1.11 Configuration... -
Page 13: Product Description
Lumen X7 Lumen X7 Industry Tablets are tough tablets with 7" display, which have been designed for use in the industrial environments and especially developed by BARTEC for use in potentially explosive atmospheres. The Lumen X7 Industry Tablet is based on the ARM Cortex-A7 Quad Core processor running at 1.5 GHz. - Page 14 7" Industry Tablet - Lumen X7 Product Description Type B7-A23.-2…/…….. Position Designation Description 7” touch screen Display and data input medium of the tablet Home button Returns to home screen Menu button Opens a list of actions that the user can do on the current screen Return button Returns to the previous screen...
- Page 15 7" Industry Tablet - Lumen X7 Product Description Type B7-A23.-2…/…….. Rear view Position Designation Description LED auxiliary light Provides lighting while using the camera Rear Camera 5 MP autofocus camera captures photos and videos Optional Barcode Barcode scanner for reading 1D/2D barcode is not available as certified version for use in hazardous locations.
-
Page 16: Purpose Of Use
7" Industry Tablet - Lumen X7 Product Description Type B7-A23.-2…/…….. Purpose of use The Lumen X7 Industry Tablets are handheld electrical devices. They serve the purpose of entry, processing and (radio) transmission of data within potentially explosive atmospheres. The Lumen X7 Industry Tablet is used exclusively in combination with devices which comply with the requirements placed on the overvoltage category I. -
Page 17: Technical Data
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. Technical Data Explosion protection NI ATEX Zone 2 and 22 Type B7-A234-2…/…….. Lumen X7 Labelling II 3G Ex ic IIC T5 Gc II 3D Ex ic IIIB T100°C Dc -10 °C ≤ Ta ≤ +50 °C Test certificate EPS 15 ATEX 1 037 X Standards... -
Page 18: Applicable Standards
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. X - labelling (special conditions of use for secure operation within the potentially explosive atmosphere) The ambient temperature range is -10 °C to +50 °C.* The device must be protected from impact with high impact energy, from intense ... - Page 19 7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. Safety specification - Specific Absorption Rate (SAR) Human exposure to radio frequency fields from hand- held and body-mounted wireless communication devices – Human models, instrumentation and procedures – Part EN 62209-2:2010 2: Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body...
-
Page 20: Features
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. Features 3.3.1 Performance features Processor ARM® Cortex™-A7 Quad Core 1.5 GHz 1 GB Mobile DDR2 Main memory 16 GB eMMC Extension slot Micro SD card slot supports up to 32 GB It is not allowed to insert or change the card inside the potentially explosive atmosphere! Lumen X7 interfaces... -
Page 21: User Environment
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. 3.3.3 User environment Operating temperature -20 °C to +50 °C / -4 °F to +122 °F in battery mode Operating temperature -20 °C to +60 °C / -4 °F to +140 °F In AC modus, only outside potentially explosive atmosphere Operating temperature... -
Page 22: Voice And Data Transmission Bluetooth
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. 3.3.6 Voice and data transmission Bluetooth Bluetooth-Verbindungen connections are realised with the assistance of ARM® Cortex™-A7 Quad Core 1.5 GHz processor. Bluetooth Version 2.1 or 3.0 + EDR Aerial internal 3.3.7 Audio DANGER... -
Page 23: Nfc (Near Field Communication)
Battery DANGER Do not replace or charge the battery in a potentially explosive atmosphere. Danger to life in a potentially explosive atmosphere! Use original BARTEC/Winmate accessories only. Do not open, disassemble, puncture, or crush the battery. Do not leave or store the Lumen X7 Industry Tablet in an area which is near a ... -
Page 24: External Interfaces
The external interfaces "Micro USB Type B (OTG Host, data exchange and charging), Pogo Pin (charging in docking station)" may only be used outside the potentially explosive range with accessories specified by the manufacturer. Only use original BARTEC/Winmate accessories. Product labelling Subject to technical changes. - Page 25 7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. Description of the external interfaces Warning Camera Type plate Battery type B7-A2Z0-0027 Front side Rear side Subject to technical changes. EN 19/61 03/2016...
-
Page 26: Laser Labels
7" Industry Tablet - Lumen X7 Technical Data Type B7-A23.-2…/…….. Laser labels The accessible laser radiation is in the visible spectral range (630 nm to 680 nm). It is not dangerous to the eye for short term exposure (up to 0.25 s). In the case of laser devices of class 2, the eye is not in danger from incidental short term exposure to laser radiation, i.e. -
Page 27: Transport And Storage
Replace the battery if the operating time has shortened considerably. The standard warranty period for all BARTEC batteries is six months, whereby it is irrelevant whether the battery was acquired separately or was contained in the scope of the delivery of the Industry Tablet. -
Page 28: Commissioning
− 1 x USB cable (Type A to micro Type B) − 1 x Quick Start Guide − 5.1.1 Optional accessories Authorized accessories from BARTEC For the Ex area: Replacement battery − Hand strap − 1 x capacitive stylus −... -
Page 29: Requirements In Potentially Explosive Atmosphere
7" Industry Tablet - Lumen X7 Commissioning Type B7-A23.-2…/…….. For the non-Ex area: USB network adapter for EU, UK, US and AUS − USB cable (Type A to micro Type B) − Micro USB Host cable (OTG) − Micro SD card −... -
Page 30: Handling Accessories
Accessories Only install or replace accessories outside the potentially explosive atmosphere. − User accessories exclusively which have been tested or certified by BARTEC for this − purpose. The end user can replace the battery, SIM card, micro SD card, hand strap, and −... -
Page 31: Open/Close Protective I/O Cover
Only insert or replace the SIM / micro SD card outside of the potentially explosive atmosphere. Only use SIM / micro SD cards which have been tested and certified by BARTEC for this purpose. 1. Place the Industry Tablet on its front (display facing downwards) on a flat mat. -
Page 32: Insert Battery
7" Industry Tablet - Lumen X7 Commissioning Type B7-A23.-2…/…….. 5.4.3 Insert battery DANGER In potentially explosive atmospheres, battery latches must be locked. Danger to life exists! Check the locking of the battery latches carefully. Work steps: Only install or replace the battery outside the potentially explosive atmosphere. 1. -
Page 33: Turn On And Off The Lumen X7 Industry Tablet
7" Industry Tablet - Lumen X7 Commissioning Type B7-A23.-2…/…….. LED Status Description The Industry Tablet is not charging or not properly connected Solid red Low battery Solid green Charging in progress 5.4.5 Turn On and Off the Lumen X7 Industry Tablet Work steps: Turn the device on The device may be power supplied either via the adapter or the battery. -
Page 34: Remove/Replace Screen Protector
Do not use any sharp objects to remove the screen protector! The screen protector can be ordered from BARTEC. The installation instructions for the screen protector forms part of the scope of delivery. Parts number: B7-A2Z0-0030 screen protector, 1 piece. -
Page 35: Operation
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Operation The operator using an electric system in a potentially explosive environment must keep the accompanying operation equipment in good condition, operate and monitor it correctly and conduct the requisite services and repairs. Before operation the devices it must be checked that all components and documents are available. -
Page 36: Suitable Materials For Cleaning
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. ATTENTION Devices and accessories can be destroyed if handled incorrectly! Generally separate the charger from the power supply. Only clean the interface contacts if the battery has been removed. There should be no residue, e.g. -
Page 37: Operation, Recommendations And Requirements
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Operation, recommendations and requirements 6.3.1 Basic safety and health protection requirements Consult your local health and safety officer to ensure that you are acquainted with the safety regulations in your company which serve to protect employees at the workplace. 6.3.2 Ergonomic recommendation The following recommendations should be considered for everyday work at the... - Page 38 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Road traffic safety Do not take any notes and do not use the device when driving. Making a list of to-dos or browsing through the address book when driving has a negative effect on safe driving. When driving on the road, you must primarily think of your safety and that of other road users.
-
Page 39: Information On The Use Of Wireless Devices
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. The “Mobile Communication Industry” requests you to give safety priority when using your device/telephone. 6.3.4 Information on the use of wireless devices Heed all warnings referring to the use of wireless devices. 6.3.4.1 Safety in aircraft Switch off the wireless device when asked to do so by the ground staff and by employees... -
Page 40: Led Devices
If you use LED for the camera flash, keep the camera flash LED at least 317 mm (12.5 inch) away from a person’s eyes. Otherwise serious damage may be caused to the eyes. Devices from BARTEC/Winmate equipped with LED devices comply with the following guidelines: IEC 62471:2006-07 for LED safety. −... -
Page 41: Operating Frequency - Fcc And Ic
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Operating frequency - FCC and IC 5 GHz only Use in the UNII-Band 1 (Unlicensed National Information Infrastructure) in the range of 5150-5250 MHz is restricted to indoor rooms. The failure to heed this rule leads to the illegal operation of the device. - Page 42 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Declaration in accordance with the FCC regulations, Part 15.21 Changes which have not been explicitly approved by the party responsible for compliance with the regulations can lead to the expiry of the operating authorization for this device. Radio transmission devices (Part 15) This device satisfies the requirements of Part 15 of the FCC Guidelines.
-
Page 43: Electromagnetic Fields
Portable devices have been specially tested for operation in direct body proximity. Use exclusively belt clips, holsters and similar accessories which have been tested and approved by BARTEC to ensure compliance with the FCC regulations. Belt clips, holsters and similar accessories of third manufacturers may not satisfy the FCC requirements for the recommended maximum values for electromagnetic fields and should not therefore be used. -
Page 44: Use The Android 4.2 Operating System
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Use the Android 4.2 Operating System 6.6.1 Wake up the phone If you do not use the phone for a while, the screen dims and then darkens to conserve the battery. Work steps: 1. -
Page 45: Use The Touch Screen
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.6.2 Use the touch screen Simply touch the icon, symbol, or onscreen button using your finger. Tap and hold Touch an item using your finger and not lifting it until an action occurs. -
Page 46: Personalize The Home Screen
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.6.4 Personalize the home screen The user can add application icons, shortcuts, widgets, and other items to any part of the Home screen where there is free space. The user can also change the wallpaper. Change the wallpaper Work steps: and select Settings, select Display and then tap Wallpaper. - Page 47 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Remove an item Work steps: 1. Tap and hold the element (a) you want to remove (here the clock item). The launcher icon (b) will change into a Remove icon. 2. Drag the item you want to remove to the Remove icon. When the item turns red, release yout finger.
- Page 48 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Status and notification icons The status bar appears at the top of every screen. On the left are notification icons (d) and on the right are status icons (e), along with the current time. Notification The following icons indicate that you have received notification.
-
Page 49: Use The On-Screen Keyboard
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.6.5 Use the On-Screen Keyboard The user will be able to enter text using the On-Screen Keyboard. Some applications will launch the keyboard automatically. In others, the user needs to touch a text field where the user wants to enter text to launch the keyboard. -
Page 50: Set The Display
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 3. Drag the selection tab to expand or reduce the range of the selected text. Work steps: Cut or copy text Select the text that should be cut or copied and then should be pasted. Tap on the key to remove the selected text from the text field. -
Page 51: Set The Audio Profile
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Work steps: and then tap Settings. 1. Tap 2. Tap Display and then tap Brightness. The following options for Brightness will be offered: Automatic Tap Automatic Brightness to adjust the brightness Brightness automatically Economical... -
Page 52: Set Language And Keyboard
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.6.10 Set language and keyboard Use the language and keyboard settings to select the language for the text on your Industry Tablet and for configuring the On-Screen Keyboard, including words that you add to its dictionary. - Page 53 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Change the keyboard language The current keyboard language is displayed on the space key and the user can switch languages. Work steps: Tap the keyboard icon located on the top right. There are four input options: Tap Hardware-physical keyboard to use Hardware-physical keyboard...
-
Page 54: Usb Debugging Setting
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.6.11 USB debugging setting To permit debugging tools on a computer to communicate with the user’s Industry Tablet via USB connection. Work steps 1. Tap and then tap System settings. 2. Tap { } Developer options and then tap USB debugging to allow USB debugging. If the USB is connected, there will be a symbol in the notification icons on the bottom right. -
Page 55: Connection To Mobile Networks And Devices
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Connection to mobile networks and devices When users assemble their Industry Tablet with a SIM card from the service provider, their phone is configured to use their provider networks for voice calls and for transmitting data. -
Page 56: Connect To Wi-Fi Networks
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.7.3 Connect to Wi-Fi networks Turn on the Wi-Fi and connect to a Wi-Fi network Work steps: 1. Tap and then tap Settings. 2. Tap Wireless & networks and then select Wi-Fi to turn it on. 3. -
Page 57: Connection To Bluetooth Devices
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 2. Input the Network SSID (name of the network) (a). 3. If the network is secured, tap the security menu (b) and then tap the type of security deployed on the network. Enter any required security credentials. 4. -
Page 58: Connection / Disconnection Via Usb
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Connection / disconnection via USB DANGER Non certified accessories endanger explosion protection. Danger to life exists in potentially explosive atmospheres! The external Micro USB Type B interface (OTG Host, data exchange, and ... - Page 59 7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. When the device is connected as USB storage, the screen indicates that USB storage is in use and user will receive a notification. Disconnect Lumen X7 Work steps: 1. Tap the notification panel and then tap USB connected. 2.
-
Page 60: Use The Camera
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.10 Use the camera The Industry Tablet is equipped with a 5 MP camera on the rear side, which the user can use to capture photos or video. Make sure that the protective lens cover is clean before taking pictures. A dirty lens cover can cause blurry pictures. -
Page 61: Record A Video
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.10.3 Record a video Work steps: 1. Tap to switch from camera to video mode. 2. Point the lens to record the scene where you want to start. 3. Tap the Record icon to start the video recording. -
Page 62: Daten Mit Punkt Zu Punkt (P2P) Verbindung Übertragen
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. 6.11.2 Daten mit Punkt zu Punkt (P2P) Verbindung übertragen 1. There are two NFC capable devices required. 2. Enable NFC on the receiver device. 3. Enable NFC function on Lumen X7 as described in chapter 6.11.1. 4. -
Page 63: Use Read / Write Function
7" Industry Tablet - Lumen X7 Operation Type B7-A23.-2…/…….. Example 3: Kontaktdaten 6.11.3 Use Read / Write Function The RFID HF/NFC Reader supports following protocols: ISO 14443-A (read) − ISO 14443-B (read) − ISO 15693 (read) − ISO 18092 (read/write) −... -
Page 64: Faults And Troubleshouting
7” Industry Tablet - Lumen X7 Faults and troubleshooting Type B7-A23.-2…/…….. Faults and Troubleshouting DANGER Danger to life exists in potentially explosive atmospheres! Examine defective devices and any accessories only outside the potentially explosive atmosphere. Troubleshooting Problem Solution - Check that the external power supply is connected The battery does not and that the replaceable battery is inserted charge. -
Page 65: Service, Inspection, Repair
7” Industry Tablet - Lumen X7 Disposal Type B7-A23.-2…/…….. Service, Inspection, Repair Service, inspection, and repair of Lumen X7 Industry Tablets may be conducted exclusively by trained and qualified staff! The staff who is familiar with the service, inspection, and repair of Lumen X7 Industry Tablets, has been informed about the risks and has the qualifications necessary for this work. -
Page 66: Disposal
Please read through the handling guidelines for the RMA process before you send in a defective device for repair. Then complete the RMA form (Return Merchandise Authorization), sign it and send it to our "Returns Centre". services@bartec.de E-Mail: Fax: +49 7931 597-119 We cannot guarantee the processing within the contractually agreed period for any returns received by us without RMA number. -
Page 67: Accessories
12.1 Links All original Winmate documents refer to the non-explosion-protected version. Please heed the safety information in the BARTEC manuals when using original Winmate documents. The explosion-protected Lumen X7 series from BARTEC and the non-explosion- protected Winmate E430RM4 series do not differ in terms of software. - Page 68 Your partner for safety technology. Challenge us! BARTEC GmbH Max-Eyth-Str. 16 Phone: +49 7931 597-0 info@bartec.de Germany 97980 Bad Mergentheim Fax: +49 7931 597-119 www.bartec.de...
