- Page 1 ATEX/IECEx Zone 2/22 UL Class I Division 2 Installation Instruction RFID UHF Add-On Modul Type B7-A2Z0-0032...
- Page 3 Installation Instruction - Translation RFID UHF Add-On Module Type B7-A2Z0-0032 ATEX/IECEx Zone 2/22 UL Class I Division 2 Document No.: B1-A2Z0-7N0002 / 403699 Status: 8. August 2016 Reservation: Technical data subject to change without notice. Changes, errors and misprints may not be used as a basis for any claim for damages.
-
Page 4: Basic Information
Injuries and material damage can be avoided by circumspect handling and systematically following the instructions. The BARTEC company reserves the right to carry out technical changes at any time. Maintenance and Repairs The pertinent erection and operating provisions for electrical systems must be observed! Repairs to explosion-protected devices may only be performed by authorised personnel with original spare parts and according to the state of the art. -
Page 5: Safety Instructions
The assembly/dismantling must be conducted by qualified personnel authorised and trained to install electrical components in potentially explosive areas. The use in areas other than those specified or alteration of the product releases BARTEC from liability for defects and further liability. Modifications and changes to the module are not permitted. -
Page 6: Special Conditions For Safe Use
The apparatus shall be protected against mechanical impact, excessive UV-light and strong charge generating processes. In combination with BARTEC accessory 03-9849-0130 (hand strap) the device is only suited for gas group IIA. Um = 60 V shall never be exceeded. The user is responsible for meeting this condition. - Page 7 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Device / system specifications Supported standards EPC Global GEN2 (ISO1800-6C) with DRM optional: IP-X and ISO 18000-6B Frequency range Dual band 902 to 928 MHz 865 to 867.5 MHz Nominal reading range up to approx.
- Page 8 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Introduction The intrinsically safe combination of the Agile X tablet PC system and the RFID UHF Add-On Module enables the fast easy and secure reading and writing of RFID transponders in a potentially explosive atmosphere in Zone 2/2 and Division 2.
- Page 9 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Installation of RFID UHF Add-On Module Only assemble/dismantle the RFID UHF Add-On Module outside the potentially explosive atmosphere. Only use the RFID UHF Add-On Module for the purpose that they have...
- Page 10 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Fasten the RFID UHF Add-On Module using the six screws supplied. Torque: 3 Nm. Visual inspection of the RFID UHF Add-On Module to ensure correct positioning and assembly. Switch the Agile X on using the "ON/OFF"...
- Page 11 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Setting up / activating the RFID UHF Add-On Module Switching the Agile X on. (1) Press the ON/OFF button for three seconds. Activating the RFID UHF Add-On Module. (2) Click on "Hottab" on the start screen to start the application.
-
Page 12: Downloading And Installing The Driver
Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 Downloading and installing the driver Downloading the driver 1. If the driver for the virtual COM connector is not included in the system image of the tablet PC, a new "M6Exx" device is shown in the device manager under "Other... - Page 13 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 3. In "Update Driver Software" window, click on the "Browse my computer for driver software" option. 4. Click on the "Browser" button and manually switch to the driver folder. Confirm selection with "OK".
- Page 14 Installation Instruction RFID UHF Add-On Module (Translation) Type B7-A2Z0-0032 6. In the "Windows Security" window, confirm the installation using the "Install" button. 7. At the end of the installation, Windows reports that the driver has been successfully installed. Close "Update Driver Software"...
- Page 16 Your partner for safety technology. Challenge us! BARTEC GmbH Max-Eyth-Str. 16 Phone: +49 7931 597 0 info@bartec.de Germany 97980 Bad Mergentheim Fax: +49 7931 597 119 www.bartec.de...
