- Page 1 ATEX / IECEx Zone 2 and 22 CSA Class I Division 2 Lumen X7 Quick Start Guide 7" Industry Tablet Type B7-A23-2.../..
- Page 3 CSA Class I Division 2 Document No.: B1-A234-7E0002 / 401725 Revision 0 / Status: 6 June 2016 Proviso: Subject to technical changes. Changes, mistakes and printing errors do not substantiate any claim to damages. Content Page English 1-12 BARTEC GmbH Max-Eyth-Straße 16 Service-mobilecomputing@bartec.de www.bartec.de...
-
Page 5: Basic Information
Atries and material damage can be avoided by circumspect handling and systematically following the instructions. The BARTEC company reserves the right to carry out technical changes at any time. Maintanance and Repairs The pertinent erection and operating... -
Page 6: Scope Of Delivery
Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. Safety and warning information is particularly emphasised in this Quick Start Guide marked by symbols. DANGER describes a directly imminent danger in hazardous areas. If not avoided, death or severe injury will be the consequence. - Page 7 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. 4. Marking, test certificate, and standards Note: Full information in "user manual" ATEX Zone 2 and 22 II 3G Ex ic IIC T5 Gc EPS 16 ATEX 1 037X II 3D Ex ic IIIB T100°C Dc -10 °C ≤...
- Page 8 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. 5. Your Lumen X7 Some tips for using and caring the Lumen X7 Our Lumen X7 series tablet is designed to resist damages from certain rugged conditions. However, to help care for the Lumen X7, please avoid prolonged or extreme exposure to those conditions.
- Page 9 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. 6. Starting the Lumen X7 Before using the Lumen X7, install the Li-Polymer battery by sliding the battery into the Lumen X7. Subject to technical changes. EN 6/12 06/2016...
- Page 10 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. Subject to technical changes. EN 7/12 06/2016...
- Page 11 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. 7. Turn on/Turn off your Lumen X7 Unintended use endangers explosion protection. Risk of fatal injury in an explosive atmosphere! In the case of functional disturbances or damage to the enclosure, the device should be turned off and removed immediately from the potentially explosive atmosphere to a safe place.
-
Page 12: Charge The Battery
I/O cover must be opened. Do not replace or charge the battery in a potentially explosive atmosphere. Only use original accessories from BARTEC. Our warranty does not cover damage to the Lumen X7 caused by other batteries and/or chargers. - Page 13 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. 9. Open/Close the protective I/O cover Open the protective I/O cover outside of the potentially explosive atmosphere. The protective cover must be correctly aligned, the Inputs/Outputs have to be fully covered. Open protective I/O cover Place the Industry Tablet on a flat mat.
- Page 14 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. Plug the adapter into the Power Jack of the Industry tablet. Plug the adapter power cable into the electrical outlet. As soon as the adapter is connected with the outlet, the battery will be charged.
- Page 15 Only insert or replace SIM / Micro SD card outside of the potentially explosive atmosphere. Only use Micro SD cards which have been tested and certified by BARTEC for this purpose. To insert the SIM card and Micro SD card, the protective I/O cover must be opened.
-
Page 16: Eu Declaration Of Conformity
Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/…….. EU Declaration of Conformity... - Page 17 Quick Start 7" Industry Tablet - Lumen X7 Guide Type B7-A23.-2…/……..
- Page 18 Your partner for safety technology. Challenge us! BARTEC GmbH Phone: +49 7931 597-0 Max-Eyth-Str. 16 Fax: +49 7931 597-119 97980 Bad Mergentheim info@bartec.de Germany www.bartec.de...
