Inverter-Type - BONFIGLIOLI agl 402 Quick Start Manual

Voorhout • Groningen • Weert • Hoogerheide

Inverter-type

Determine the type of frequency inverter.
Verify that the rated input voltage corresponds to the local power supply.
Verify that the recommended motor shaft power of the frequency inverter corresponds to
the rated power of the motor.
[1] Labeling for Functional Safety (if applicable). Please check the Application manual
"Functional Safety".
[2] Labeling for UL508c (if applicable).
Specifier Frame size
-01 1
-02 1
-03 1
-05 1
1
-07 1
-09 1
-11 1
-13 1
-15 2
-18 2 2
-19 2
-19 3
-21 3
3
-22 3
-23 3
05/2013
Type designation
AGL-402-05 1
Rated
input voltage
202 230 V
402 400 V
Recommended motor shaft at specified power supply
AGL 402: AC 3x400 V
--
0.25 kW
0.37 kW
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
3.0 kW
4.0 kW
5.5 kW
5.5 kW
7.5 kW
9.2 kW
11.0 kW
29
T I elsto.eu
+31(0)88 7865800
Recommended
motor shaft power
Part number & Serial number
Warning! Electrostatic sensitive
components
Warning! High leakage current
Warning! Dangerous voltage
Risk of electric shock.
Warning! Hot surfaces.
AGL 202: AC
3x230 V
0.18 kW
0.25 kW
0.37 kW
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
3.0 kW
4.0 kW
--
5.5 kW
7.5 kW
--
--
Quick Start Guide
Frame-size
AGL 202: AC
1x230 V
0.09 kW
0.12 kW
0.18 kW
0.25 kW
0.37 kW
0.55 kW
0.75 kW
1.1 kW
1.5 kW
2.2 kW
--
3.0 kW
3.0 kW
--
--
Agile
