Warnings
Frequency inverter overloaded. Check load behavior. Check motor parameters and
...
A0001 A0004
application parameters.
,
A0008 A0010 Overtemperature. Check cooling, fan and ambient temperature.
Max. motor temperature reached, check motoer and sensor.
A0080
Mains phase failure, check mains fuses and supply cable.
A0100
Limit frequency reached, output frequency is limited.
A0400
Input signal at X12.3 is too low. Increase the value.
A0800
Input signal at X12.4 is too low. Increase the value.
A1000
DC link voltage has reached the type- specific minimum.
A4000
- Press ESC to hide an error message. It is displayed again after 10 seconds.
- Press STOP to acknowledge an error message or a warning message. Remove the fault. It is
recommended to check the entered data.
Extended settings of control terminals
Multifunction input
X12.3 P452 1-voltage 0...10 V
X12.4 P562 2-current 0...20 mA
3-digital NPN (active: 0 V)
4-digital PNP (active: 24 V)
5-current 4...20 mA
6-voltage, characteristic
7-current, characteristic
6-: programmable characteristic via P454...457
7-: programmable characteristic via P564...567
Refer to operating instructions manual.
P: Parameter
Digital Input/ Output
X11.6 P558 0-input (default)
1-output
logic switchable digital inputs
X11.4 P559 0-NPN (active: 0 V)
X11.5 1-PNP (active: 24V)
X11.6
X12.1
X12.2
NPN: LOW-switching (on negative signal). Default of P562.
PNP: HIGH-switching (on positive signal). Default of P559.
Applications via control terminals
Enable X11.3
X13.3
Change X11.4
direction of X11.5
rotation
Set motor X12.3
speed
Agile
Quick Start Guide
Multifunction output
X13.6 P550 1-digital MFO1D (P554*)
Default:
1-: signal when output frequency exceeds 3 Hz (P510)
10-: output of voltage proportional to speed.
20-: frequency output 0...24 V proportional to speed
30-: output pule train, scaled by P557.
X12.3 P452 3- digital input NPN (active: 0 V)
X12.4 P562 3- digital input NPN (active: 0 V)
Digital signals at both terminals
Start clockwise by rising edge of the signal
Start anti clockwise by rising edge of the signal
Reference speed: DC 0 ... 10 V at analog input. P452=1-voltage
(default). DC 0 V corresponds to 3,50 Hz (default value of P418).
DC 10 V corresponds to 50 Hz (default value of P419).
