Compass Model Odin90 Assembly Manual page 9

5
Rotor,Washout & Swashplate/
M3x12 Cap Head Bolt
x2
M3x5 Set Screw x2
M3x3 Set Screw x2
M3 Nylon Lock Nut
x1
M3x25 Cap Head Bolt
x1
Use Threadlock
P a ddle Insert
F ly Ba r F ro m t h i s s id e
N o T h re a d
Thrust Bearing Direction
Main grips are factory preassembled, in case of reassem-
bling, be sure to note correct placement of large/small I.D.
washers during assembly.
,
M 3 x 2 5 C a p H e ad
B o l t
M 3 x 1 2 C ap He a d
B o l t
M 3 x 3 S e t S cr ew
W a s ho ut L in k
Main Shaft
T h r e a d
T h r e a d
T h r e a d
.
Adjust so that each side has exactly the same length
0
10
M3x 3 Se t Sc r e w
3 mm Nyl on nu t
Paddle
Apply Grease Here
Larger ID
Main Grip
(IN)
20 30 40
Pad d l e I n s e r t
Smaller ID
(OUT)
