- Page 1 Digital/Analog Megohmmeter Model 1026 USER MANUAL EGOH ETER ODEL 1026 Ω Ω LOCK HOLD - 250V Ω 4000 - 500V Ω Ω - 1000V Ω Ω Ω 600V CA III 1000V 1000V CA II GlobalTestSupply www. .com uality Products Online at:...
- Page 2 Statement of Compliance ® ® Chauvin Arnoux , Inc. d.b.a. AEMC Instruments certifies that this instrument has been calibrated using standards and instruments traceable to international standards. We guarantee that at the time of shipping your instrument has met its published specifications.
-
Page 3: Limited Warranty
Limited Warranty The Megohmmeter, Model 1026, is warranted to the owner for a period of 1 year from the date of original purchase against defects in manufacture. ® This limited warranty is given by AEMC Instruments, not by the distributor from whom it was purchased. -
Page 4: Table Of Contents
General ..................5 Electrical ..................6 Safety ................... 6 Ordering Information ..............7 Display Features ................. 7 Model 1026 Features ................8 Functions .................... 9 Function ................9 Function ................9 Low Ohm and Continuity Function ..........9 Megohm Insulation Resistance Test Function ......10 Manual Mode .............. -
Page 5: Warning
Digital Megohmmeter Model 1026 Warning These safety warnings are provided to ensure the safety of personnel and proper operation of the instrument. Read the following safety information carefully before attempting to operate or service the meter. Safety is the responsibility of the operator! ... -
Page 6: International Electrical Symbols
1k to 4000M. It has 3 test voltages of 250, 500 and 1000V. In addition, the Model 1026 has an ohmmeter range to measure from 0.1 to 4000 with an audible tone for continuity measurement under 40. A voltmeter (safety check) with a range from 0 to 600V AC or DC is available when turned on. -
Page 7: General Specifications
Digital Megohmmeter Model 1026 General Specifications: Display: 3" x 1.7" (76 x 42mm) Big LCD panel with 40 segments analog bar indication. Over Range Indication: - O L - “ ” will be shown on the LCD Panel when out of range measurement is made. -
Page 8: Electrical Specifications
Digital Megohmmeter Model 1026 Electrical Specifications: AC Voltage Range Resolution Accuracy 600V 0.1V ± (1.5% rdg + 5 dgts) DC Voltage Range Resolution Accuracy 600V 0.1V ± (1% rdg + 3 dgts) Ohms (Autoranging) Range Resolution Accuracy 400 0.1... -
Page 9: Ordering Information
Digital Megohmmeter Model 1026 Ordering Information: Megohmmeter Model 1026 ..........Cat. #2117.72 Accessories: Replacement Test Leads with alligator clips ....Cat.# 2121.53 Soft Carrying Case............Cat.# 2117.73 Set of 5 fuses 0.5A 600V (fast blow) 1/2 x 3/8 ....Cat.# 2117.74... -
Page 10: Model 1026 Features
Digital Megohmmeter Model 1026 Model 1026 Features: EGOH ETER ODEL 1026 LOCK HOLD " &" ∞ Ω Ω " Ω Ω LOCK HOLD - 250V Ω 4000 - 500V Ω Ω & - 1000V Ω Ω Ω 600V CA III... -
Page 11: Functions
MegOhm Insulation Resistance Test Function: Warning: Do not test insulation on a live sample and make sure it is fully discharged before each test. The Model 1026 is equipped with function which may be used to check if the sample is live. AC/DC Turn the function selector to desired test voltage range. -
Page 12: Manual Mode
Digital Megohmmeter Model 1026 Connect the black test lead to the (–) terminal and the red one to the (+) terminal. Typically, the (+) is connected to ground side of sample, if available, and if testing to reference to ground. Connect the test lead to sample. -
Page 13: Maintenance
Digital Megohmmeter Model 1026 Maintenance Warning: For maintenance only use original factory replacement parts. To avoid electrical shock, do not attempt to perform any servicing unless you are qualified to do so. Do not perform any service while the megohmmeter is connected to any circuit. -
Page 14: Repair And Calibration
Digital Megohmmeter Model 1026 Repair and Calibration To guarantee that your instrument complies with the factory specifications, we recommend that the megohmmeter be submitted to our factory service center at one-year intervals for recalibration, or as required by other standards. - Page 15 GlobalTestSupply www. .com uality Products Online at: sales@GlobalTestSupp...
- Page 16 ® ® Chauvin Arnoux , Inc. d.b.a AEMC Instruments 15 Faraday Drive • Dover, NH 03820, USA www.aemc.com 99-MAN 100220 v7 05/12 GlobalTestSupply www. .com uality Products Online at: sales@GlobalTestSupp...
