Before commencing assembly, please read these instructions thoroughly.
Wing Span: 42.0 in / 1060 mm
Wing Area: 578 sq in / 37.3 sq dm
Flying Weight: 4.5 lbs / 2050 g
Fuselage Length: 39.5 in / 1000 mm
Requires : 2-stroke 0.40-0.46 or 4-stroke 0.48 engine
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
* Specifications are subject to change without notice.*
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
www.thewingsmaker.com
GA018PO27811208
Specifications
Specifications
4-channel radio w / 3 standard servos and 1
mini servo

INSTRUCTION MANUAL

40
40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULTIMATE 40 and is the answer not in the manual?

Questions and answers

Related Manuals for The Wings Maker ULTIMATE 40

Summary of Contents for The Wings Maker ULTIMATE 40

  • Page 1: Instruction Manual

    Operating this model without prior preparation may cause injuries. Remember, safety is the most important thing. Always keep this instruction manual at hand for quick reference. * Specifications are subject to change without notice.* THE WINGS MAKER FACTORY PRE-FABRICATED ALMOST-READY-TO-FLY (ARF) SERIES MADE IN CHINA www.thewingsmaker.com...

  • Page 2: Before You Begin

    I N D E X BEFORE YOU BEGIN P. 1 PARTS LIST P. 2 ASSEMBLY P. 3 - 11 SAFETY PRECAUTIONS P. 11 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. Check all parts.

  • Page 3: Parts List

    Parts List 15. BATTERY COVER -- 1 pc. 1. MAIN WING(Lower) -- 1 pair 16. PUSHROD CONECTOR -- 1 set 2. PLYWOOD 5x28x48mm(For Aileron Servo) -- 1 pc. PUSHROD Ø1.8x70mm(For Elevator Servo) -- 1 pc. RING Ø2.3mm--2 pcs STRAPER -- 2 pcs 3.
  • Page 4 Main Wing (Lower) CABANE MOUNT CABANE MOUNT Top View Aileron Servo (Lower) Please use mini servo Plywood 5x28x48mm Ring Completed Aileron Servo (Lower) Straper Fuel Tube Ø6x5mm Pushrod Ø1.8x70mm Clevis Completed TWM PL8210010 CLEVIS WRENCH GA018PO27811208...
  • Page 5 Main Wing (Upper) CABANE MOUNT CABANE MOUNT Bottom View Apply instant type CA glue to both sides of each hinge. Stabilizer & Elevator (Stabilizer) (Main Wing) B=B' Remove coverings for all surfaces in contact before applying A/B epoxy Completed glue. Vertical Fin &...

  • Page 6: Elevator Pushrod

    Tail Landing Gear Screw PA3x12mm Collar 2.1mm 2.1mm Collar PA3x12mm M3x3mm Set Screw Bottom View Elevator Pushrod Screw PB2x8mm TWM PL8210010 CLEVIS WRENCH ≈46mm PB 2x12mm Fuel Tube D6x5mm Horn Pushrod 1.8x465mm Ø Clevis Bottom View Rudder Pushrod Screw PB2x8mm TWM PL8210010 CLEVIS WRENCH ≈28mm...

  • Page 7: Main Landing Gear

    Main Landing Gear Ø58mm Main Wheel Socket Head Screw M3x16mm PM4x38mm M3x16mm PM4x38mm Screw Socket Head Screw KA2.3x8mm Screw Quick Release Nylon Rivet d2XD8mm Plate 1mm Washer d3xD7mm Washer d4xD9mm Collar 4.1mm Bottom View Engine Mount Socket Head Screw M3x20mm Engine Mount PL5111030 Washer...
  • Page 8 Servo Set Set Screw 3x3mm Linkage Connector Washer M2 Nut Throttle Servo. Washer Please refer to attached sheet for linkage connector installation. Engine M3 Nut d3xD7mm Washer Socket Head Screw M3x25mm d3xD7mm Washer Washer d3xD7mm M3x25mm Inverted Mount Installed Engine Position 115mm 4.5 in.

  • Page 9: Radio Equipment

    Radio Equipment Install and arrange the servo as shown in the diagram. Front Throttle Pushwire Ø1.2x300mm Elevator Servo Elevator Servo Fuel Tube Ø6x5mm Receiver Elevator Pushrod Ø1.8x70mm M2 Nut Sponge Straper 10x80x200mm Battery Rudder Pushrod Rudder Servo Throttle Servo Ø1.8x535mm KM 2x8mm Canopy First insert the grommet to the canopy then apply screw.
  • Page 10 Main Wing (Lower) Screw HM4x25mm Washer d4xD15mm PM4x25mm Washer d4xD15mm Bottom View d3xD7mm M3x20mm Main Wing M3x30mm Washer M3 Nylon d3xD7mm Please install in Insert Lock Nut Washer correct direction M3 Nylon Screw PM2x8mm Insert Lock Nut PM2x8mm M2 Nylon Socket Head Screw M3x30mm Insert Lock Nut...
  • Page 11 Ø1mm pilot holes for The Wings Maker tri-horn are pre-drilled. Main Wing Please look for pin-hole marks at under side of control surfaces. Screw PB2x12mm Main Wing (Upper) Horn Clevis Pushrod Ø1.8x145mm Fuel Tube PB2x12mm Ø6x5mm Clevis Horn Main Wing (Lower)

  • Page 12: Control Throws

    Adjust the control throws as shown in the diagram. Control Throws These throws are good for general flying. You can adjust according to your personal preference. Elevator 10mm 10mm Rudder 30mm 30mm Ailerons The ideal C.G. position is 81mm (3.2 in.) behind the leading edge measured at top wing center line.
  • Page 13 Usage of the transparent 3D template This transparent 3D template is used for position guidance of the actual cutting of the pre-painted cowling. Simply cut the transparent 3D template to fit your engine and exhaust pipe, then slide onto the actual cowling and use as template to mark the openings required for final cutting.
  • Page 14 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
  • Page 15 THE WINGS MAKER GA018PO27811208...
