Leckey Mygo Max User Instructions page 5

Check parts
Congratulations on purchasing your
Mygo Max System. All of the parts will be
contained in polythene bags with each one
clearly labelled. Carefully remove them from
the boxes and check all the parts you have
ordered.
Keep polythene bags away from
children.
Some of the accessories will need to be
assembled before you attach the seat to the
base you have purchased.
Multi-tool
A number of adjustments will require the use
of the multi-tool, which is supplied with each
seat and can be found in the back pocket of
the seat.
7.1 Setting the
footrests
Open up the angle of the leg supports by
unscrewing the knobs (A), shown, and set to
the maximum width. Open the socket caps
(B) and slide in the calf supports. Set to the
desired position, with the footplates facing
forward and retighten the socket cap bolts
with the multi-tool.
Always make sure the foot plate is
attached firmly.
A
B
7.2 Attaching the
seating system to the
Hi-low chassis
Adjust the height of the chassis to its
maximum to reduce risk of back strain while
attaching the seat unit. Refer to Section 11
on how to adjust the height of the chassis
you have purchased.
First release the safety locking pin at the
front of the seat. To do this pull the pin out
and rotate through 90 degrees. Carefully lift
the seat and place it into the chassis. At the
rear of the underside of the seat you will see
a receiving channel. Place this securely over
the tube towards the back of the chassis.
Pull the handle at the front of the seat unit up
and then pivot the seat forward and down.
