Camera/Lens
and PTT
Assembly are
not shown for
clarity reasons.
Power Input
Cable
Make sure the cables are not crimped or chafed
when feeding them through the bottom hole.
Close the side entry hole with the ½ NPT plug.
FIGURE 3 - 2
Bottom Entry Wiring Connections
BNC Connector, see Note 3.8
Power Cable to Camera Board
15
Video
Cable
VRB
