FIGURE 4 – 2
Directional Adjustment, Tilt and Vertical
Base
Linear
Adjustment
Loosen the locking knob, rotate the PTT and
Camera/Lens assembly to the desired position,
and re-tighten the knob. The Camera Assembly
can also be moved along the linear axis by this
method. The complete directional adjustment
must be done in conjunction with Figure 4-2 on
page 19.
FIGURE 4 – 3
Camera Rotation
20
PTT Bracket
Locking
Knob
