Pro-Form PFIVEL74514.0 User Manual page 8

STEP 4
Fasten right footplate (60R) with carriage
bolts (52) from the right footplate support bar
and secure it with washers (57), spring (58)
and knobs (59) tightly. Do the same for the
left pedal.
STEP 5
Ⅰ.Secure Handle Bar (23L+R) with 2xM8Allen
Bolt (3),Curved washer (13) and Nut(22).
Ⅱ. Connect two cables : hand pulse cable
(9) and connecting cable (121),then connect
the upper computer cable to the computer
(1) .Sit the computer (1) onto its bracket and
secure in place using the 4 screws(2) previ-
ously removed.
Ⅲ. Secure the computer rack( 4) with 2
screws (5)
Now your machine is ready for use.
60L
1
23L
2 3
8
52
60R
57
58
59
121
9
13 22
4 5
23R
