local monitor output features

talkback mono
—TALK TO MONO
The system output is added to the mono
TALKBACK
The level of the
TALKBACK
section.
MASTER
main left/right to mono—
The left and right post-fader signals are summed together as a
MAIN
mono signal and are routed to the mono bus.The summed left and right
signals automatically combine with any signals that are assigned directly to
the mono bus to make up the mono output.
The mono output consists exclusively of signals assigned directly to
the mono bus. Signals that appear at the
appear at the mono output.
signal/peak
LED—SIG/PEAK
This dual-color LED responds to the pre-fader mono signal. It illumi-
LED
nates green with varying brightness in proportion to the audio signal.
When the signal approaches clipping, either pre or post fader, the LED illu-
minates red.
signal is set by the
TALKBACK
L/R TO MONO
left and right faders do not
MAIN
master HS module
output.
MASTER
level control in the
