matrix level control features

matrix 1–4 levels—left, right, and mono
These level controls mix the left, right and mono signals into the cor-
responding matrix.
external matrix 1–4 input levels controls
These level controls are used to mix the external
into the corresponding matrix.The external
located on the rear-panel of the
MTX 1-to-all
This switch routes the signal from the external
the external input-level controls 1–4. This way, a single external
MATRIX
input can be added to each of the four matrices.
When this switch is down, the external
disabled.
MATRIX
input connectors are
MATRIX
module.
MASTER
MATRIX
input jacks 2, 3 and 4 are
MATRIX
master RT module
input signals
input-1 jack to
6
p. 103
