Crest Audio X-Eight HS Owner's Manual page 123

rear panel features
left, right, and mono output XLR 's
This group of three balanced male XLR jacks carries the left,
right and mono output signals. These outputs are controlled by the
left, right and mono output faders.
see—left, right, and mono masters
hearing assist output
This single balanced male XLR carries a mono signal that is made up of
a sum of the left and right
depressed, the center/mono output signal is included with the summed left
and right signal that appears at this jack.
This output does not have a designated level control.The summed signal is
derived after the left, right and mono (when the
depressed) faders.
MASTER
left and right alternate output XLR 's
This pair of balanced male XLR connectors carries the left and right
signals.These outputs are controlled by the
ALT OUT
see—left and right alternate output, front-panel description
left and right monitor output XLR 's
carries the left and right
XLR OUT
controlled by the
MONITOR
see—monitor, front-panel description
outputs.When the
MASTER
LCR TO OUT
ALT OUT
signals.These outputs are
MONITOR
level control.
master RT module
switch is
LCR TO OUT
switch is
level control.
