- Page 1 PLRRR18U OWNER’S MANUAL Mobile Audio System PLL Synthesizer Stereo Radio MP3/WMA Player Automatic Memory Storing Preset Equalization USB/MICRO SD Interface www.pyleaudio.com...
-
Page 2: Table Of Contents
CONTENTS Installation ........... 3 Wiring Connection ......5 Operation ..........6 Location of keys ........6 Switching on/off the unit ......7 Sound adjustment ......... 7 Loudness ..........7 Display information ....... 7 Liquid crystal display ......7 ESP function ......... 7 Reset function ........ -
Page 3: Installation
INSTALLATION the unit chassis). For details, refer to Notes: the following illustrated installation Choose the mounting location methods. where the unit will not interfere Installation Opening with the normal driving function This unit can be installed in any of the driver. dashboard that has the same Before installing the unit, connect dimensions of opening as shown... - Page 4 INSTALLATION...
-
Page 5: Wiring Connection
WIRING CONNECTION ISO CONNECTION... -
Page 6: Operation
OPERATION LOCATION OF KEYS 11. TF slot 12. 9/ 2 INT 13. 0/ DISP 3 RPT 14. Reset button 15. PUSH/SEL/PWR 5 DIR- 16. MODE 4 RDM 17. 8/ 6 DIR+ 18. 7/BAND AUX IN 19. AS/PS 10. USB interface... -
Page 7: Switching On/Off The Unit
OPERATION SWITCHING ON/OFF THE UNIT The unit can be connected to a portable Press PWR button (15) to turn on/off the audio player through the AUX IN jack (9). unit. When the unit is on. Press and hold it RESET FUNCTION for 2 seconds to turn off the unit. -
Page 8: Automatic Memory Storing& Program Scanning
OPERATION mode and “AUTO” appears on the MONO mode. In STEREO mode you display. can receive a FM stereo signal. In MONO AUTOMATIC MEMORY STORING & mode the stereo station will be PROGRAM SCANNING switched to monochrome. Sometimes - Automatic memory storing when the signal is noisy you can Press AS/PS button (19) for 2 seconds change to MONO mode. -
Page 9: Selecting Directory Up/Down
Searching From Directory OPERATION Press 4RDM button (7) to play all files Press AS/PS button for three times. in random order. Press again to cancel The unit searches file from the folder the function. by 8 buttons or rotating the SELECTING DIRECTORY VOL knob. - Page 10 OPERATION When you insert a TF card in the card interface, the unit will search the MP3/WMA files in the card and start to play. The operation is the same with the USB operation described above. If in another mode. You can also press MOD button to select SD mode.
-
Page 11: Remote Control
REMOTE CONTROL HANDSET(OPTIONAL) FUNCTION KEY & CONTROL 1. POWER Power ON/OFF Button 2. MODE Mode Button (S,T,U,7,For MP3/WMA Operation) 3. TUNE/SKIP Tune/SKIP Down Button(V,W,X,8 For MP3/WMA Operation) 4. 7/BND Band Select Button(When pressed shortly) 5. SCN Scanning Button(D,E,F,2 For MP3/WMA Operation) 6. -
Page 12: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 7" (W) x 6.2" (D) x 3.9"(H) Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power Version V : 4x60 watts Current Drain... -
Page 13: Trouble Shooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult support@pyleaudio.com. Symptom Cause Solution The car ignition switch is power supply No power. not on. connected to the car accessory circuits, but the engine is not moving, switch the ignition key to “ACC”.
