- Page 1 MANUAL ENGLISH Live Mini Ordercode: D3236 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Mini Live Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................2 Connection with the mains ............................4 Return Procedure ................................4 Claims ....................................4 Features ....................................5 Accessories ..................................5 Rear Panel Description ..............................5 Connection Examples .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● 2x LIVE mini column speaker ● 2x LIVE 12 active sub ●... - Page 4 Mini Live Before connecting or disconnecting the power cord, make certain the ON / OFF switch is in the OFF position. Before switching on or off make certain the sound system’s amplifiers are off or turned down: this will avoid signal peaks, which are annoying and sometimes dangerous (particularly for speaker enclosures).
-
Page 5: Connection With The Mains
Mini Live Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE BLACK SILVER NULL... -
Page 6: Features
Another advantage of the Live mini is its weight and size. With only 20Kg on the active sub and 7 kg on the column this set can be transported and set up by one person. The active sub has a built- in DSP with 2 sound presets and a limiter network that protects the complete system. -
Page 7: Connection Examples
Mini Live Thru audio signal connector: This is a male XLR-type connector that produces exactly the same signal that is connected to the main input jack or a mix of input 1 and input 2. ON-OFF main power switch Input AC power socket with main fuse Input 2 on combo connector Input 1 on combo connector RCA input... -
Page 8: Frequency Response Diagram
Mini Live Frequency Response Diagram Preset LIVE Preset Entertain Productcode: D3236... -
Page 9: Connection Cables
Mini Live Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 10: Technical Specifications
Mini Live Technical Specifications Subwoofer Subwoofer 1 x 12” Frequency response -6 dB 40Hz-500Hz Total amplifier power 700W Class-D@ 4 ohm Amplifier, subwoofer 1 x 350W/Class D @4Ω Amplifier, satellite/mid- 1 x 350W/Class D @4Ω high unit Axial sensitivity 1W@1m 96dB Thermal DC / Overload / Digital Electronic Protections... -
Page 11: Dimensions
Mini Live Dimensions Troubleshooting This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit operates properly, do not carry out following steps. - Page 12 ©2014 DAP Audio...
