Excel Mobil User Manual page 13

Folding the footplate away
Go to the front of the wheelchair and get a hold of the footplate, photo 3 at

the front side;
Fold the footplate in the direction of the footrest.

Fold down the footplate
Go to the front of the wheelchair and get a hold of the footplate, photo 3 at

the front side;
Fold down the footplate.

Removing the footrest from the wheelchair
Stand in front of the wheelchair;

Push the black adjustment lever away from you, photo 4;

You now can swing away the footrest;

Swing away the footrests 90ᵒ to the outside of your wheelchair and pull the

complete footrest straight upwards from the receiving tube.
Photo 3
Photo 4
