airmaster CV 80 Operator's Manual page 40

Product information according to "Commission Regulation (EU) No 1253/2014, Annex V - Information requirements for
NRVUs as referred to in Article 4(2)".
a) Manufacturer
b) Model
c) Typology
d) Type of drive installed
e) Type of heat recovery system
f) Thermal efficiency
g) Nominal flow rate
h) Electric power input
i) Internal specific fan power (SFP
j) Face velocity
k) Nominal external pressure (∆p
l) Internal pressure drop of ventilation
components (∆p )
s, int
m) Internal pressure drop of non-ventilation
components (∆p )
s, add
n) Static efficiency
of fans
o) Maximum external leakage rate
Maximum internal leakage rate
p) Energy performance of the filters
q) Filter alarm signal
r) Sound power level (L )
WA
s) Disposal
Specific requirements 2016/2018
Thermal efficiency
Internal specific fan power (SFP
a) Manufacturer
b) Model
c) Typology
d) Type of drive installed
e) Type of heat recovery system
f) Thermal efficiency
g) Nominal flow rate
h) Electric power input
i) Internal specific fan power (SFP
j) Face velocity
k) Nominal external pressure (∆p
l) Internal pressure drop of ventilation
components (∆p )
s, int
m) Internal pressure drop of non-ventilation
components (∆p )
s, add
n) Static efficiency
of fans
o) Maximum external leakage rate
Maximum internal leakage rate
p) Energy performance of the filters
q) Filter alarm signal
r) Sound power level (L )
WA
s) Disposal
Specific requirements 2016/2018
Thermal efficiency
Internal specific fan power (SFP
Airmaster
AM 300
Non-residential ventilation unit / Bidirectional ventilation unit
Variable speed drive (VSD)
Recuperative heat exchanger / Counterflow heat exchanger
82 %
0,060 m³/s
216 m³/h
0,06 kW
) 1040 W/(m³/s)
int
0,289 W/(m³/h)
1,0 m/s
) 20 Pa
s, ext
201 Pa
Water Comfort Heater:
10 Pa
37 %
2 % @ 400 Pa
2 % @ 250 Pa
108 kWh/a, Class A+
See description in Operator's Manual
40 dB(A)
Se See description in Operator's Manual, www.airmaster-as.com
>67%/>73%
) 1641/1361 W/(m³/s)
int_limit
Airmaster
AM 1000
Non-residential ventilation unit / Bidirectional ventilation unit
Variable speed drive (VSD)
Recuperative heat exchanger / Counterflow heat exchanger
80 %
0,264 m³/s
950 m³/h
0,23 kW
) 771 W/(m³/s)
int
0,214 W/(m³/h)
0,8 m/s
) 20 Pa
s, ext
194 Pa
Water Comfort Heater:
10 Pa
55 %
2 % @ 400 Pa
2 % @ 250 Pa
261 kWh/a, Class A+
Se See description in Operator's Manual
40 dB(A)
Se See description in Operator's Manual, www.airmaster-as.com
>67%/>73%
) 1550/1270 W/(m³/s)
int_limit
AM 500 AM 800
82 % 84 %
0,110 m³/s 0,167 m³/s
396 m³/h 600 m³/h
0,12 kW 0,11 kW
1011 W/(m³/s) 664 W/(m³/s)
0,281 W/(m³/h) 0,184 W/(m³/h)
0,8 m/s 1,0 m/s
20 Pa 20 Pa
195 Pa 111 Pa
Water Comfort Heater: Water Comfort Heater:
10 Pa 10 Pa
40 % 39 %
2 % @ 400 Pa 2 % @ 400 Pa
2 % @ 250 Pa 2 % @ 250 Pa
206 kWh/a, Class A+ 330 kWh/a, Class A+
40 dB(A) 40 dB(A)
>67%/>73% >67%/>73%
1634/1354 W/(m³/s) 1686/1406 W/(m³/s)
AM 1200 DV 1000
84 % 81 %
0,264 m³/s 0,290 m³/s
950 m³/h 1044 m³/h
0,17 kW 0,36 kW
491 W/(m³/s) 638 W/(m³/s)
0,136 W/(m³/h) 0,177 W/(m³/h)
0,8 m/s 1,0 m/s
20 Pa 100 Pa
85 Pa 140 Pa
Water Comfort Heater: Undisclosed
10 Pa
38 % 47 %
2 % @ 400 Pa 2 % @ 400 Pa
2 % @ 250 Pa 2 % @ 250 Pa
450 kWh/a, Class A+ 403 kWh/a, Class A+
40 dB(A) 47 dB(A)
>67%/>73% >67%/>73%
1670/1390 W/(m³/s) 1577/1297 W/(m³/s)
40
AM 900
90 %
0,173 m³/s
623 m³/h
0,17 kW
638 W/(m³/s)
0,177 W/(m³/h)
1,0 m/s
20 Pa
137 Pa
Water Comfort Heater:
10 Pa
38 %
5 % @ 400 Pa
5 % @ 250 Pa
428 kWh/a, Class A+
40 dB(A)
>67%/>73%
1864/1584 W/(m³/s)
