Machine Specification - Rotabroach SMARTPUMA1 Original Manual

Issue 5
3) SPECIFICATION
Maximum hole cutting capacity in .2/.3C steel = 30mm dia. x 25mm deep
Arbor bore = 19.05mm (3/4") dia.
Model
SMARTPUMA1
SMARTPUMA3
Model
Electro Magnet
SMARTPUMA1
SMARTPUMA3
Total Normal Full Load
Overall Height (maximum extended)
Dimensions
Height (minimum)
Width (including Hand wheel)
Length Overall (including Guard)
Magnet Footprint
Net Weight
Stroke With Arbor
With Drill chuck
No Load
Speed
Tractive Force of Magnet at 20º C (25mm min. plate thickness)
The use on any material less than 25mm thick will progressively reduce the
magnetic performance. If possible substitute material should be positioned under
the magnet and work piece to equate to a suitable material thickness. If this is not
possible an alternative secure method of restraining the machine MUST be used.
Maximum hand/arm vibration magnitude (measured at handle during operation in
accordance with ISO5349 using a 22mm dia. cutter through 13mm mild steel plate.
Estimate of vibration exposure. Operation 30 holes @ 1 minute/hole.
Average noise level during cutting at operators ear position.
Suitable only for a single phase 50-60 Hz A.C. power supply
Do not use your magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
RD4329 Safety Strap
RD4088 4mm A/F Tee Handled Hexagon Key
Original version
Voltage (V)(AC)
110V 50-60Hz
230V 50-60Hz
Voltage (V)(DC)
110
230
(magnet + motor)
All voltages
DO NOT USE ON D.C. SUPPLY
WARNING: THIS APPLIANCE MUST BE EARTHED!
List of Contents with Magnetic Dill Unit
Normal Full Load
Normal Full Load
Amps (A)
0.45
0.225
L
Check
List
YES/NO
YES/NO
6
Nov 2014
Watts (W)
800
800
Watts (W)
45
45
845
410mm
360mm
170mm
250mm
165mm x 80mm
11.20kgs
30mm max
65mm
600rpm
8000N
2.95 m/s²
0.39 m/s² A(8)
Max. 88.3 dB(A)
PA
L Max. 101.3dB(A)
WA
