Machine Specification - Rotabroach SMARTPANTHER1 Manual

Issue 3
3) Specification
Maximum hole cutting capacity in .2/.3C steel = 40mm dia. x 52mm deep
Arbor bore = 19.05mm (3/4") dia.
Motor Unit Smartpanther1
(Nominal values)
Smartpanther3
Electro Magnet Smartpanther1
Smartpanther3
Total Normal Full Load
Overall Height (maximum extended)
Dimensions
Width (including Hand wheel)
Length Overall (including Guard)
Magnet Footprint
Nett Weight
Stroke
No Load speed All voltages
Tractive Force of Magnet at 20º C (25mm min. plate thickness)
The use on any material less than 25mm thick will progressively reduce
the magnetic performance. If possible substitute material should be
positioned under the magnet and work piece to equate to a suitable
material thickness. If this is not possible an alternative secure method of
restraining the machine MUST be used. Failure to do so may result in
personal injury.
Maximum hand/arm vibration magnitude (measured at handle during
operation in accordance with ISO5349 using a 22mm dia. cutter through
13mm mild steel plate.
Estimate of vibration exposure. Operation 30 holes @ 1 minute/hole.
Average noise level during cutting at operators ear position.
Ear defenders must be worn when operating this machine.
Suitable only for a single phase 50-60 Hz A.C. power supply.
Do not use the magnetic drill on the same structure when arc welding is in progress.
D.C. current will earth back through the magnet and cause irreparable damage.
WARNING: THIS APPLIANCE MUST BE EARTHED!
NB: ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE.
List of Contents with Magnetic Dill Unit
RD4329 Safety Strap
RD4088 4mm A/F Tee Handled Hexagon Key
RD4152 3mm Hexagon key
Original version
110v 50-60Hz
230v 50-60Hz
110v 50-60Hz
230v 50-60Hz
(magnet + motor)
DO NOT USE ON D.C. SUPPLY
- 5 -
1100W
1100W
45W
45W
1145
510 mm
180 mm
265 mm
165mm x 80mm
14.6 kg
85mm
270-610 rpm
800kg
2.892 m/s²
0.13 m/s² A(8)
L Max. 88.4 dB(A)
PA
L Max. 101.4dB(A)
WA
Check List
YES/NO
YES/NO
YES/NO
March 2012
