In general, the SmartNode will connect to the network via the WAN (DSL) port. This enables the SmartNode to

offer routing services to the PC hosts on LAN (ETH 0/)) port. The SmartNode 4650 ADSL2+ Series provides an

auto-MDX feature for both Ethernet ports, so you can use a straight-through or cross-over cable to connect to a

host or a switch (see

figure

Network

You can check the connection with the ping command from the SmartNode to another host on the

local LAN.

172.16.1.99(if-ip)[eth_dsl]#ping <IP Address of the host>

If the WAN address is

Note

the default gateway. (For information on configuring the default gateway, refer to section "Set IP

addresses" in Appendix C, "Command Summary" of the SmartNode Series SmartWare Software Config-

uration Guide.)

SmartNode 4654 & 4658 ADSL2+ Quick Start Guide

2).

Straight-through wired

or crossover cable

WAN (DSL)

Figure 2.

Connecting the SmartNode to the network

set to DHCP, to ping a device outside your local LAN you must first configure

LAN

LAN (ETH 0/0)
