Manually configuring MAC address entries
With dynamic MAC address learning, a switch does not distinguish between illegitimate and legitimate
frames, which can invite security hazards. For example, if a hacker sends frames with a forged source
MAC address to a port different from the one where the real MAC address is connected to, the switch will
create an entry for the forged MAC address, and forward frames destined for the legal user to the hacker
instead.
To improve the port security, you can bind specific user devices to the port by manually adding static
MAC address entries to the MAC address table of the switch.

Types of MAC address table entries

A MAC address table can contain the following types of entries:
• Static entries, which are manually added and never age out.
Dynamic entries, which can be manually added or dynamically learned and may age out.
•
Blackhole entries, which are manually configured and never age out. Blackhole entries are
•
configured for filtering out frames with specified source or destination MAC addresses. For example,
to block all packets destined for a specific user for security concerns, you can configure the MAC
address of this user as a blackhole MAC address entry.
To adapt to network changes and prevent inactive entries from occupying table space, an aging
mechanism is adopted for dynamic MAC address entries. Each time a dynamic MAC address entry is
learned or created, an aging time starts. If the entry has not updated when the aging timer expires, the
switch deletes the entry. If the entry has updated before the aging timer expires, the aging timer restarts.
NOTE:
A static or blackhole MAC address entry can overwrite a dynamic MAC address entry, but not vice versa.

MAC address table-based frame forwarding

When forwarding a frame, the switch adopts the following forwarding modes based on the MAC
address table:
Unicast mode: If an entry is available for the destination MAC address, the switch forwards the
•
frame out the outgoing interface indicated by the MAC address table entry.
Broadcast mode: If the switch receives a frame with the destination address being all ones, or no
•
entry is available for the destination MAC address, the switch broadcasts the frame to all the
interfaces except the receiving interface.

Configuring the MAC address table

The MAC address table configuration tasks include:
Manually configuring MAC address table entries
•
• Configuring the aging timer for dynamic MAC address entries
Configuring the MAC learning limit on ports
•
These configuration tasks are all optional and can be performed in any order.
